- Page 1 KVM switch and rackmount screen technology User Manual 17” FHD 1080p LCD DF117 1U Dual Slide LCD Console Drawer Options : - SDI - HDMI - Display Port - DC power Designed and manufactured by Austin Hughes UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
- Page 2 Intentionally Left Blank UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
- Page 3 ■ Re-position or relocate the receiving antenna. ■ Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
-
Page 4: Table Of Contents
Contents < Part. 1 > DF117 Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations Keyboard / Mouse Specifi cations P.10 On-screen Display Operation ( OSD ) P.13 < Part. 3 >... - Page 5 fi rst, not directly on the parts you are cleaning. Gently wipe the surface. Use as little pressure as possible. Wait until your monitor is completely dry before plugging it in and powering it up. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
-
Page 6: Package Content
< Part 1 > < 1.1 > Package Content DF117 unit X 1 - CX-6A 6ft DVI-D console cable X 1 ( Alternative : CB-6A 6ft VGA console cable ) - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 7 < 1.2 > Dimension DF117 Front View Rear View AC Input 100~240V Power VGA DVI-D Side View UNIT : mm 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 441.6 x 650 x 44 mm...
-
Page 8: Installation
Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. Step Complete the installation ■ Fix the LCD console drawer into the rack. M6 screw, cage nut & cup washer x 8 are provided. UM-CV-751-DF117-Q220V1 www.austin-hughes.com... - Page 9 < 1.3 > Installation - How to Use the Dual Slides DF117 ■ Press the handle button and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
- Page 10 < 1.3 > Installation - How to Use the Dual Slides ■ Flip down the front panel. ■ Press the handle button and gently push back the drawer into the rack. ■ Return the LCD console drawer to park position. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
-
Page 11: Connection
< 1.4 > Connection to USB Server via CX-6A cable DF117 LCD Console Drawer DVI-D AC Input 100~240V POWER CX-6A DVI-D console cable USB server DVI-D < 1.4 > Connection to external KVM via CX-6A cable LCD Console Drawer DVI-D... - Page 12 Before attempting to connect anything to the LCD console drawer, we suggest turning off the power to all devices. Apply power to connected devices again only after the LCD console drawer is receiving power. The company is not responsible for damage caused in this way. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
-
Page 13: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations DF117 Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 1920 x 1080 Brightness ( typ. ) Contrast Ratio ( typ. ) - Page 14 * In some circumstances, if the user connects the LCD to PC via HDMI port or video and audio signals, the LCD may display incorrectly on a full screen. If so, please adjust the display card setting on display size to fi x the issue. UM-CV-751-DF117-Q220V1 www.austin-hughes.com...
-
Page 15: Keyboard / Mouse Specifi Cations
< 2.2 > Keyboard / Mouse Specifi cations DF117 G keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS... - Page 16 How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts. Dashboard Increase volume Eject disc Rewind Command Play / Pause UM-CV-751-DF117-Q220V1 P.11 www.austin-hughes.com...
- Page 17 < 2.2 > SUN Keyboard / Mouse Options DF117 S keyboard integrated with touchpad Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
-
Page 18: On-Screen Display Operation ( Osd )
: To adjust the vertical position of the video Clock : To auto adjust H. Size of the screen Phase : To fi ne tune the screen. Picture size : FULL SCREEEN / 4:3 / 5:4 / 16:10 UM-CV-751-DF117-Q220V1 P.13 www.austin-hughes.com... - Page 19 On-screen Display Operation ( OSD ) DF117 Color Color temperature : User / Warm / Cool / 5400k mode and Red / Green / Blue color balance Sharpness : Adjust the image from weak to sharp : Adjust the screen hue value...
- Page 20 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
-
Page 21: Options
< 3.2 > Options : DF117 DP Option - Display Port ( DP 1.0, HDCP 1.3 ) AC Input 100~240V HDMI Option - HDMI ( HDMI 1.4, HDCP 1.4 ) HDMI AC Input 100~240V BNC Option - Composite ( BNC ) - Page 22 4.16A 4.16A 4.16A 6.25A Effi ciency DC power For DC power option : ( 1 ) If the unit with LCD, earthing may be required ( 2 ) DC option excludes AC power adapter and power cord. UM-CV-751-DF117-Q220V1 P.17 www.austin-hughes.com...
-
Page 23: Kvm Integration
(W x D x H) (W x D x H) 441.6 x 650 x 44 mm 595 x 860 x 140 mm 12.9 kg 18.9 kg DF117 with KVM 17.4 x 25.6 x 1.73" 23.4 x 33.9 x 5.5” 28.4 lb 41.6 lb UM-CV-751-DF117-Q220V1 P.18... - Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2020 Austin Hughes Electronics Ltd. All rights reserved. UM-CV-751-DF117-Q220V1 P.19 www.austin-hughes.com...
