Summary of Contents for CyberView ER2 Series
- Page 1 User Manual 2U Dual Slide LCD Keyboard Drawer 15", 17" 19" creen ize ER2 Series ERS (2U) Series - 2U 17" 19" creen ER2S Shallow Series...
-
Page 2: Table Of Contents
Contents Chapter 1 Getting Started Important Safeguards............1 Regulatory Notice..............2 Package Contents...............3 Before Installation...............4 Unpacking................4 Optional Accessories............4 Peripheral Products.............5 Structure Diagram...............5 How to Install “One Man” Installation Slides....6-7 1.10 How to Use The Slides............8 1.11 How to Use The Dual Slide..........9 1.12 Series (Single console) ......10... - Page 3 Contents Chapter 4 Optional Specifi cation KVM Options..............19 DVI-D Input Option............19 BNC + S-Video Option............19 Audio Option..............20 DC ower Options............21 Touchscreen Options............21 Chapter 5 Troubleshooting ............22 Chapter 6 Dimensions ..............23...
-
Page 4: Important Safeguards
Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 5: Regulatory Notice
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice. -
Page 6: Package Contents
Chapter 1 1.3 Package Contents LCD keyboard drawer x 1 pc CB-6 USB 2-in-1 KVM cable x 1 pc (for “S” series) CE-6 Combo 4-in-1 KVM cable x 1 pc (for RKP series) User manual (As of Sept 2011, all user manuals will be download-only. Physical copies are available upon request) Power cord x 1 pc Auto switch power adapter ( for external power version) x 1 pc Mounting bracket x 2 pcs... -
Page 7: Before Installation
Chapter 1 1.4 Before Installation ■ It is very important to locate the LCD Keyboard Drawer in a suitable environment. ■ The surface for placing and fi xing the LCD Keyboard Drawer should be stable and level or mounted into a suitable cabinet. -
Page 8: Peripheral Products
Chapter 1 1.7 Peripheral Products Item Model No. Description Matrix Cat 6 16 ort KVM Matrix IP Cat 6 16 ort KVM Matrix Cat 6 KVM Matrix Cat 6 32 ort KVM Matrix IP Cat 6 32 ort KVM Matrix DB-15 8 ort KVM Matrix IP DB-15 8 ort KVM Matrix DB-15 KVM Matrix DB-15 16 ort KVM... -
Page 9: How To Install "One Man" Installation Slides
Chapter 1 1.9 How to Install "One Man" Installation Slides Installing into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■... - Page 10 Chapter 1 1.9 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
-
Page 11: How To Use The Slides
Chapter 1 1.10 How to Use the Slides For keyboard drawer only ■ A black arrow release button is located on the outside of each slide in the keyboard drawer. (shown in Figure 1). Figure 1. ■ Pull and hold the black arrow button on either side of the LCD keyboard drawer to unlock. -
Page 12: How To Use The Dual Slide
Chapter 1 1.11 How to Use the Dual Slide ■ Gently pull the handle toward the front of the lower keyboard drawer (shown in Figure 4). Figure 4. Slide the handle toward the front of keyboard drawer. ■ Push the handle toward the front of the upper LCD drawer (shown in Figure 5). -
Page 13: Use Cb-6 To Connect To Server Via Usb Interface
Chapter 1 1.12 ERS (2U) Series (Single console) - Use CB-6 to connect to server via USB interface Figure 8. Example of connecting CB-6 2-in-1 USB KVM cable to server via USB interface 1.13 ERS (2U) Series (Single console) - Use CB-6 to connect to KVM via USB interface CB-6 KVM Cable Figure 9. -
Page 14: Use Ce-6 To Connect To Server Via Ps/2 Interface
Chapter 1 1.14 ER2 Series (Single console) - Use CE-6 to connect to server via PS/2 interface Figure 10. Example of connecting CE-6 4-in-1 Combo KVM cable to server via PS/2 interface 1.15 ER2 Series (Single console) - Use CE-6 to connect to KVM via PS/2 interface... -
Page 15: Use Ce-6 To Connect To Server Via Usb Interface
Chapter 1 1.16 ER2 Series (Single console) - Use CE-6 to connect to server via USB interface Figure 12. Example of connecting CE-6 4-in-1 Combo KVM cable to server via USB interface 1.17 ER2 Series (Single console) - Use CE-6 to connect to KVM via USB interface CE-6 KVM Cable Figure 13. -
Page 16: On- Creen Display Operation
Chapter 2 2.1 On-Screen Display Operation 15" LCD membrane 17" & 19" LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen... -
Page 17: On- Creen Menu
Chapter 2 2.2 On-Screen Menu OSD Confi guration Page Image: To open the brighness, contrast, color temp, red, green, and blue controls Geometry: To open the auto adjust, H position, V position, phase and clock controls Video: To open the colour, tint, sharpness, noise reduction, DCDi and TV Setup controls Audio: To open volume, bass, treble, balance, AVL and mute controls... -
Page 18: Chapter 2 Operation
Chapter 3 3.1 Specifi cations Item Description Form Factor rackmount on slide-out rails LCD Manufacturer Series Diagonal Size 15" TFT 17" TFT 19" TFT 17" TFT 19" TFT 1152 x 900 (Direct) 1152 x 900 (Direct) Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024 1280 x 1024 (Native) -
Page 19: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse eries Supporting layouts keyboard integrated with keyboard integrated with touch pad track ball P.16... -
Page 20: Keyboard & Mouse
Chapter 3 3.2 Keyboard & Mouse eries Supporting layouts ■ Incorporates S keys including Stop, Cut, Paste, Compose, Copy and Help ■ 104 key notepad keyboard with full numerical pad and SUN function ■ USB interface ■ Incorporates S keys including Stop, Cut, Paste, Compose, Copy and Help ■... -
Page 21: How To Use Keyboard
Chapter 3 ■ ■ Press the Fn/Num button to switch the color the Num LED. Num LED in Off mode Num LED in Green color Keypad behaves as a normal key pad mode administration command mode Three Audio / Display keys are located in the upper-right corner of the NS keyboard: ■... -
Page 22: Kvm Options
Chapter 4 4.1 KVM Options Our KVM is designed to seamlessly integrate into the rear of our full range of LCD drawer solutions: ■ ■ ■ ■ ■ Please ask your supplier for full KVM details 4.2 DVI-D Option 3-in-1 VGA KB mouse console port Internal power version... -
Page 23: Audio Option
Chapter 4 4.4 Audio Option Speaker 3-in-1 VGA KB mouse Power Audio console port Internal power version External power version ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.20... -
Page 24: Dc Ower Options
Chapter 4 4.5 DC Power Options Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA 50 mA - Full load 4950 mA 2450 mA 1220 mA Output rating... -
Page 25: Chapter 5 Troubleshooting
Chapter 5 5.1 Troubleshooting 1. Is an interference signal appearing on the LCD normal when shutting down the computer? In rare cases, interference may appear on the monitor. This may be caused by signal rate of VGA card and is considered normal. -
Page 26: Chapter 6 Dimensions
Chapter 6 6.1 Dimensions Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 442 x 600 x 88 mm 581 x 753 x 216 mm 18 kg 24 kg ER2-17 17.4 x 23.6 x 3.5" 22.9 x 29.6 x 8.5"... - Page 27 Blank page...
- Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2010 Austin Hughes Electronics Ltd. and Eclipse Rackmount, Inc. All rights reserved. CV-RKP2-1010V8...
