- Page 1 SECURITY FLOODLIGHT INSTALLATION MANUAL LHT0090 LHT0091 LHT0152...
- Page 2 TOP VIEW 200º SIDE VIEW 2.5m Less sensitive More sensitive...
- Page 3 Supplier means the authorised distributor or retailer that sold you the Goods in New Zealand or Australia; and Goods means the Simx product accompanied by this warranty and purchased in New Zealand or Australia. The benefits provided to you under the following warranty are in addition to any other rights and remedies available to you under the law: 1.
-
Page 4: General Information
SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the lamp will illuminate for a user-determined time period. An integral daylight sensor ensures night-only operation. PARTS INCLUDED - Luminaire c/w PIR Sensor unit. - Instruction manual. -
Page 5: Installation
SECTION THREE INSTALLATION Mark position of the fixing holes. (Fig C) Drill the holes. Insert the wall plugs into the holes. PASS THE CABLE THROUGH THE WALL BRACKET BEFORE SECURING WALL BRACKET TO THE WALL. Pierce the grommet and pass the cable through the wall bracket. Allow approximately 70mm of cable to pass through the grommet. -
Page 6: Operation And Testing
CONNECTION DIAGRAM Mains Supply Isolation Switch The diagram below also shows the required connections for the addition of slave luminaires. When adding slaves, be sure not to exceed the maximum switchable load (see Technical Specifications). SECTION FOUR OPERATION AND TESTING WALK TEST PROCEDURE The sensor will rotate from left to right, and tilt forward or backward. - Page 7 TEST MODE - 3 LEDS PARTIALLY VISIBLE The lamp will now illuminate for approximately 5 seconds every time movement is detected. Walk across the detection area approximately 5 metres from the unit. Each time you are detected the lamp will illuminate. Now stand still until the lamp extinguishes (this should take approx. 5 seconds) Start moving again, when you are detected again the lamp will illuminate.
-
Page 8: Technical Specifications
Manual Control Mode is indicated by the permanent illumination of a single red LED in the top of the sensor head. To switch the unit back into Sensor Control Mode, flick the internal wall switch/circuit breaker off/on once within 1 second. The unit will return to Sensor Control Mode. This is indicated by the return of the left to right scrolling LED's as described in Sensor Control Mode above. -
Page 9: Troubleshooting Guide
In the event of the cover glass shattering, do not replace with normal household glass. Contact the Simx helpline for replacement details. If you experience problems refer to Troubleshooting Guide. If problems still exist, do not immediately return the unit to store. - Page 10 PROBLEM SOLUTION J PIR sensor will not operate at Check that the power is switched ON at the circuit breaker/internal wall switch. all. Turn OFF the power to the unit and check the wiring connections as per the diagram (see previous section 3). Ensure no connections are loose.
- Page 11 Dusk/Dawn Sensor “on” time control MOVEMENT TIMER Time Control Adjuster (factory set to 1 hr min) DUSK TIMER Lens Mask Restrict long detection Restrict short detection Restrict RHS detection Restrict LHS detection...
- Page 12 Place this edge against wall and use diagram to estimate incoming cable length INCOMING WIRE TEMPLATE Use this diagram to estimate incoming cable length...
