Ph: +64 9 259 1660 | Technical Support Ph: +64 9 259 1662
Email: sales@simx.co.nz | www.simx.co.nz
Pub1244 iss02 08/14
Simx reserves the right to alter technical specifications without prior warning
INSTALLATION INSTRUCTIONS
Model: Mightylite 15 Watt and 24 Watt Floodlight
Thank you for purchasing this SIMX floodlight. This light is suitable for outdoor use and requires
a 220 – 240V AC power supply. Please read this manual thoroughly before use and retain for
future reference.
LHT0230: MIGHTYLITE 15W Black LED Floodlight
LHT0231: MIGHTYLITE 15W White LED Floodlight
TECHNICAL SPECIFICATIONS
Voltage:
220 - 240V AC
Rated Load:
15 Watts
Luminous Flux:
930 lumens
Light Beam Angle:
75°V - 99°H
Working Temperature:
-30° to +50° C
Ingress Protection:
IP65 with gland - IP44 with rear grommet
Construction:
Polycarbonate UV stabilised & Alloy
!
IMPORTANT
This product is suitable for use only with a supply voltage of 220-240V AC 50Hz.
All electrical work must be carried out in accordance with local and national electrical codes as
applicable. We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed on the
circuit for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety. Young children
should be supervised to ensure that they do not play with the appliance.
There are no user servicable parts in this light fitting.
Any changes or modifications made or attempted to this product, without the prior written approval of
the manufacturer, will void any and all stated warranties.
LHT0232: MIGHTYLITE 24W Black LED Floodlight
LHT0233: MIGHTYLITE 24W White LED Floodlight
24 Watts
1530 lumens
74°V - 93°H
