INSTALLATION INSTRUCTIONS
CHAMELEON FLOOD
LHT1096 - LHT1097
Single 20W LED Colour-Select & Dimmable Floodlight
Thank you for purchasing this Chameleon LED light fitting.
This product is suitable for outdoor use. A 230V AC power
supply is required and installation should be completed by a
registered electrician.
TECHNICAL SPECIFICATIONS
Power Source
Rated Load
Lumens
Colour Temperature
IP Rating
Mounting
Construction
Safety
Warranty
REPLACEMENT PARTS
Remote Controller
!
IMPORTANT
This product is suitable for use only with a supply voltage of 220-240V AC, 50/60Hz.
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed in the circuit
for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
Any changes or modifications made or attempted to this product, or product installed contrary to these
installation instructions without the prior written approval of the manufacturer, will void any and all stated
warranties. The light source of this luminaires is not replaceable; when the light source reaches its end of
life, the whole luminaire must be replaced
220-240V AC
20W
1300 - 1500 lm
3000K/4000K/5000K
IP65
Wall or ceiling
Aluminium alloy, heat tempered
glass lens
Class I
3 years
LHT1108
Advertisement
Related Manuals for SImx CHAMELEON LHT1096
Summary of Contents for SImx CHAMELEON LHT1096
- Page 1 INSTALLATION INSTRUCTIONS CHAMELEON FLOOD LHT1096 - LHT1097 Single 20W LED Colour-Select & Dimmable Floodlight Thank you for purchasing this Chameleon LED light fitting. This product is suitable for outdoor use. A 230V AC power supply is required and installation should be completed by a registered electrician.
- Page 2 INTRODUCTION The Chameleon Flood colour select and dimmable floodlight is an effective light source allowing you to select between warm, cool and natural white colour temperatures. The remote controller also allows dimming of the light output. Wall or ceiling mounted, this reliable modern light offers the adaptability to create the right ambiance regardless of application around your home.
- Page 3 INSTALLATION We strongly recommend this light fitting is installed by a registered electrician Switch off the power supply before commencing any electrical work. Use the mounting bracket to mark the position of screw holes on the mounting surface. Drill screw holes to depth of 3cm (approx) and fit wall plugs (not supplied). Care should be taken to avoid drilling or screwing into concealed electrical wiring/plumbing.
- Page 4 During this period if the product has a defect of this nature it will be repaired or replaced free of charge by SIMX with the same item, or a similar one of higher specification.
