- Page 1 SECURITY FLOODLIGHT INSTALLATION MANUAL E-644 (LHT0096) E-645 (LHT0097) E-646 (LHT0098)
-
Page 2: Top View
TOP VIEW 120º SIDE VIEW 2.5m Time Lens Mask Less sensitive Restrict long detection Restrict short detection More Restrict RHS detection Restrict LHS detection sensitive... - Page 3 During this period if the product has a defect of this nature it will be repaired or replace free of charge by SIMX LTD with the same item, or a similar one of higher specification. ON CONDITION THAT:- The product has been bought by the user.
-
Page 4: General Information
SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the lamp will illuminate for a user-determined time period. An integral daylight sensor ensures night-only operation. PARTS INCLUDED - Luminaire c/w PIR Sensor unit. - Instruction manual. -
Page 5: Installation
SECTION THREE INSTALLATION *** IMPORTANT *** Switch off the electricity at the fuse box by removing the relevant fuse or switching off the circuit breaker before proceeding with the installation. After choosing a suitable location (see previous section) install the unit as follows: Note: This unit is suitable for wall or eave mounting. -
Page 6: Operation And Testing
SECTION FOUR OPERATION AND TESTING WALK TEST PROCEDURE The sensor will rotate from left to right, and tilt forward or backward. Adjust the sensor to point in the required direction. The unit can be set up in daylight or at night. The adjustment knobs are factory set. Lux is set to the 'Moon"... -
Page 7: Technical Specifications
IP44 (suitable for outdoor use) If you experience problems refer to Troubleshooting Guide. If problems still exist, do not immediately return the unit to store. Telephone the Simx Customer Helpline NZL: 64 9 259-1662 Weekdays 9.00am - 5.00pm Email: sales@simx.co.nz Website: www.simx.co.nz... -
Page 8: Troubleshooting Guide
SECTION SIX TROUBLESHOOTING GUIDE SOLUTION PROBLEM o Lamp stays ON all the time at The unit may be suffering from false activation. Cover the night. sensor lens completely with a thick cloth. This will prevent the sensor from "seeing" anything. If the unit now switches off after the set time duration and does not re-activate, this indicates that the problem was caused by false activation.
