SImx LHT0192 Installation Instructions

PRODUCT COMPLIANCES
Product complies with:
AS/NZS60598.1:2003 AS/NZS60598.2.5:2002
EN60529 and relevant amendments.
MANUFACTURERS EXTENDED WARRANTY
This product is guaranteed by SIMX Ltd for 12 MONTHS from the date of purchase against faulty
materials or workmanship which affects its designed ability to operate. During this period if the
product has a defect of this nature it will be repaired or replaced free of charge by SIMX with the
same item, or a similar one of higher specification. ON CONDITION THAT:
The buyer returns it to the seller from whom it was bought, freight paid.
The product has been bought by the user. ie a receipt/sales invoice is produced as proof of purchase.
The product has not been misused or handled carelessly, installed in anyway contrary to the installation
instructions, or installed in any unusually exposed or harsh environmental conditions.
This guarantee excludes liability for discolouration of paint or plastic, or any user replaceable parts.
It does not confer any rights other than those expressly set out above and does not cover any claims
for consequential loss or damage.
Our Goods come with guarantees that cannot be excluded under the Australian and New Zealand
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the Goods
repaired or replaced if the Goods fail to be of acceptable quality and the failure does not amount
to a major failure.
Distributed by: Simx Limited
Ph: +64 9 259 1660 | Technical Support Ph: +64 9 259 1662
Email: sales@simx.co.nz | www.simx.co.nz | www.simxlighting.com.au
Simx reserves the right to alter technical specifications without prior warning.
PUB1208 iss02
INSTALLATION INSTRUCTIONS
Model: Eco-Flood Halogen Floodlight
Thank you for purchasing this SIMX floodlight. This light is suitable for sheltered outdoor permanent
use and requires a 220/240VAC power supply. Please read this manual thoroughly before installation
and retain for future reference.
TECHNICAL SPECIFICATIONS
220-240 VAC
Power Source:
50Hz
Power Frequency:
Class I
Protection Class:
IP44
Ingress Protection:
Stainless Steel
Mounting Screws:
!
IMPORTANT
This product is suitable for use only with a supply voltage of 220-240V AC 50Hz.
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed on the circuit
for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
Any changes or modifications made or attempted to this product, without the prior written approval of the
manufacturer, will void any and all stated warranties.
Range:
LHT0192 Eco-Flood Black 400watt
LHT0193 Eco-Flood White 400watt
LHT0195 Eco-Flood White 120watt
Order Code: LHT0192, LHT0193
400watt max 1.7A max
Rated Load:
R7s Linear Halogen 117mm
Lamp Type:
Order Code: LHT0195
120watt max 0.70A max
Rated Load:
R7s Linear Halogen 78mm
Lamp Type:
