INSTALLATION INSTRUCTIONS
Mightylite Solar
LED PIR Floodlight with Solar Panel
Thank you for purchasing this SIMX LED PIR Floodlight with Solar Panel. This light is
suitable for outdoor use. Please read this manual thoroughly before use and retain
for future reference.
Model
Description
LHT0346
Mightylite 28W LED PIR with Solar Panel
LHT0347
Mightylite 16W LED PIR with Solar Panel
Sensor Type: Passive IR.
Detection Range: 10 - 12 metres.
Detection Angle: 120°.
Colour Temp: 5700k Natural White.
KIT CONTENTS
16W - 1 x 8 Ah Rechargeable Battery
28W - 1 x 12 Ah Rechargeable Battery
16W - 1 x 36 Wh Solar Panel
28W - 1 x 60 Wh Solar Panel
!
IMPORTANT
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
We strongly recommend that this light fitting is installed by a registered electrician.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Young children should be supervised to ensure that
they do not play with the appliance.
Any changes or modifications made or attempted to this product, without the prior written approval of the
manufacturer, will void any and all stated warranties.
Ingress Protection: Rated to IP65.
Construction: Alloy Polycarbonate.
Warranty: 2 Years fitting, 1 Year battery.
Battery Charge: 4-8 hours.
KIT CONTENTS - HARDWARE KIT BAG
1 x Mightylight Remote Control
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SImx LHT0346
Summary of Contents for SImx LHT0346
- Page 1 INSTALLATION INSTRUCTIONS Mightylite Solar LED PIR Floodlight with Solar Panel Thank you for purchasing this SIMX LED PIR Floodlight with Solar Panel. This light is suitable for outdoor use. Please read this manual thoroughly before use and retain for future reference.
- Page 2 HOW IT WORKS The Mightylite Solar Floodlight uses a digital controller with default setting options, the unit is fully automatic and ready for use. This unit has a range of locked functions. To enable more features, please refer to the ‘Using the Remote Control’ section of this manual.
- Page 3 FIXING TO A WALL (Fig 1) Mark off the position using the bracket as a guide. Drill two fixing holes for each bracket, taking into account the length of cable from the solar panel and light fitting. Secure the brackets to the wall. Mount the solar panel onto its fixing bracket (which should be located above the light fitting), and set it to the appropriate angle and tighten.
- Page 4 ELECTRICAL SETUP NOTE: The unit will not operate correctly unless it is fully charged. When charging the Mightylite Solar, the charge LED should flash red. If the charge LED is flashing orange, this indicates a battery fault or the battery may not be connected correctly. Remove the battery, clean the contacts with a non metallic cloth and carefully slide the battery back on.
- Page 5 USING THE REMOTE CONTROL The Mightylite Solar Floodlight’s remote control gives you control over the floodlight’s functioning from a distance. Before using the remote control, remove the plastic tab by pulling it downwards and out of the unit. (You can dispose of the tab). Note: Because the floodlight changes its settings to optimize output as battery level decreases, the remote control works best when the light’s battery is fully charged.
- Page 6 # of Remote # of Flashes Function Button Pushes Courtesy Light is enabled—low-level courtesy light until the PIR is triggered, then up to full brightness. Courtesy Light is disabled. (No light after PIR time-out.) PIR Trigger Duration is long: >65% battery—60s of light 35 –...
- Page 7 STANDARD OPERATION ACCORDING TO BATTERY CONDITION WARNING - IMPORTANT LI-ION BATTERY WARNING Take great care when handling the battery. Lithium-ion cells and battery packs may get hot, explode or ignite and cause serious injury if exposed to extreme conditions. Be sure to follow the safety warnings listed below: •...
- Page 8 MANUFACTURERS EXTENDED WARRANTY This luminaire and solar panel are guaranteed by SIMX Ltd for 24 MONTHS from the date of purchase against faulty materials or workmanship which affects its designed ability to switch and operate. The battery in this kit is guaranteed for 12 months from date of purchase.
