INSTALLATION INSTRUCTIONS
ROBO LED
LHT1083
Single 18W LED PIR Floodlight
Thankyou for purchasing this Robo LED light fitting.
This product is suitable for sheltered exterior locations. It requires a 230V AC power
supply to operate and should be installed by a registered electrician.
TECHNICAL SPECIFICATIONS
Power Source
Rated Load
Lumens
Colour Temperature
Detection range (approx)
Fixed Time on Adjustment
Protection Rating
Mounting
Construction
Safety
Warranty
!
IMPORTANT
This product is suitable for use only with a supply voltage of 220-240V AC, 50/60Hz.
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed in the circuit
for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Young children should be
supervised to ensure that they do not play with the appliance.
Any changes or modifications made or attempted to this product, or product installed contrary to these
installation instructions without the prior written approval of the manufacturer, will void any and all stated
warranties.
The light source of this luminaires is not replaceable; when the light source reaches its end of
life, the whole luminaire must be replaced
220-240V AC
18W
1100 lm
4000K
Max. 10 metres at 270°scan
3(±1) minutes.
IP44
Wall
UV-stabilised polycarbonate
Class I
3 years
Advertisement
Table of Contents
Related Manuals for SImx LHT1083
Summary of Contents for SImx LHT1083
- Page 1 INSTALLATION INSTRUCTIONS ROBO LED LHT1083 Single 18W LED PIR Floodlight Thankyou for purchasing this Robo LED light fitting. This product is suitable for sheltered exterior locations. It requires a 230V AC power supply to operate and should be installed by a registered electrician.
- Page 2 INTRODUCTION The Robo LED Light incorporates a PIR (passive infrared) sensing device which continuously scans a preset detection zone and immediately switches the light on when it detects movement in that area. This floodlight can be set to then follow the movement of the subject in the detection zone automatically. While there is movement within range of the unit the light will remain on.
- Page 3 INSTALLATION We strongly recommend this light fitting is installed by a registered electrician Switch off the power supply before commencing any electrical work. Unscrew the fixing screw at base, press top button down to release and remove the rear cover. Remove the cable anchorage.
- Page 4 During this period if the product has a defect of this nature it will be repaired or replaced free of charge by SIMX with the same item, or a similar one of higher specification.
