SImx LHT0214 Installation Instructions

INSTALLATION INSTRUCTIONS
Model: Flood LED
Thank you for purchasing this SIMX floodlight. This luminaire is suitable
for outdoor permanent use and requires a 220V-240V AC power supply.
Please read this manual thoroughly before installation and retain for
future reference.
Dimensions
A = 276mm height
B = 64mm depth
C = 220 width
TECHNICAL SPECIFICATIONS
Flood LED 30W
Lamp Wattage
Current load
Power Factor
LED type
Luminaire Efficacy
Imax Intensity
FLOOD LED - BOTH MODELS
Voltage
Weight
Working
temperature
Ingress Protection
Construction
IMPORTANT
This product is suitable for use only with a supply voltage of 220-240V AC 50Hz.
All electrical work must be carried out in accordance with local and national electrical codes as applicable.
We strongly recommend that this light fitting is installed by a registered electrician.
Always switch power off prior to installation. A means of mains power isolation must be installed on the
circuit for the purpose of safe access for any internal cleaning, recalibration, or maintenance.
This light fitting is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Young children should
be supervised to ensure that they do not play with the appliance.
Any changes or modifications made or attem pted to this product, without the prior written approval of the
manufacturer, will void any and all stated warranties.
A
LHT0214
30watts
0.16A
0.92
OSRAM OSLON® Square
79.9 lm/w
953cd
220V - 240V AC
2.25 kg (approx)
-20°C to + 40°C
IP65
Cast Alloy housing, tempered glass, stainless steel external fixations
C
Flood LED 55W
Lamp Wattage
Current load
Power Factor
LED type
Luminaire Efficacy
Imax Intensity
Light beam angle
Color temperature
CRI (Ra)
TM21 L70
B
LHT0215
50watts
0.26A
0.94
OSRAM OSLON® Square
71.3 Im/w
1337cd
100° to ½ peak intensity
5700k
70
L70 (12k) > 56000hrs
