System Description
Table 3-4. 150 Pin HSE Connector (SEAM-30-03.5-L-05-2-A-K-TR) (continued)
Pin Name
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A26
A27
A28
A29
A30
C1
C2
C3
C4
C5
C6
C7
C8
C9
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C20
C21
12 TMDS64DC01EVM and TMDS243DC01EVM User's Guide
Net Name
PRG0_MDIO0_MDC
DGND
PRG0_PRU0GPO8
PRG0_PRU0GPO2
PRG0_PRU0GPO3
DGND
PRG0_PRU1GPO1
PRG0_PRU1GPO0
PRG0_PRU0GPO4
PRG0_PRU0GPO12
PRG0_PRU1GPO16
DGND
PRG0_HSE_ETH1_CLK
DGND
GPMC0_AD15
HSE_GPIO0_36
GPMC0_AD9
GPMC0_AD8
DGND
DGND
DGND
VCC3V3_IO_HSE
VCC3V3_IO_HSE
VCC3V3_IO_HSE
SOC_SPI1_CLK
VCC1V8_HSE
VCC1V8_HSE
DGND
PRG0_PRU0GPO13
PRG0_PRU0GPO5
DGND
PRG0_PRU1GPO3
PRG0_PRU0GPO14
DGND
PRG0_PRU1GPO15
PRG1_PRU1GPO19
DGND
GPMC0_AD2
GPMC0_AD5
DGND
DGND
DGND
DGND
DGND
GPMC0_AD12
Copyright © 2021 Texas Instruments Incorporated
Pin Name Net Name
B5 DGND
B6 DGND
B7 PRG0_PRU0GPO7
B8 PRG0_PRU0GPO17
B9 PRG0_PRU0GPO18
B10 DGND
B11 PRG0_PRU0GPO19
B12 PRG0_PRU0GPO0
B13 PRG0_PRU1GPO4
B14 PRG0_PRU0GPO11
B15 PRG0_PRU1GPO12
B16 DGND
B17 PRG0_HSE_ETH2_CLK
B18 DGND
B19 DGND
B20 GPMC0_AD14
B21 GPMC0_AD10
B22 HSE_GPIO0_31
B23 DGND
B24 HSE_GPIO0_35
B25 DGND
B26 DGND
B27 DGND
B28 DGND
B29 HSE_PRG0_PRU0_GPO10
B30 DGND
D1 SOC_SPI1_CS0
D2 SOC_SPI1_CS1
D3 MCU_RESETZ
D4 DGND
D5 PRG0_PRU1GPO13
D6 PRG0_PRU1GPO5
D7 DGND
D8 PRG0_PRU0GPO6
D9 PRG0_PRU1GPO2
D10 DGND
D11 PRG0_PRU1GPO11
D12 PRG0_PRU0GPO15
D13 DGND
D14 GPMC0_AD1
D15 GPMC0_AD4
D16 DGND
D17 GPMC0_AD7
D18 GPMC0_CSN2
D19 GPMC0_CSN3
D20 DGND
D21 GPMC0_AD13
