This user's guide describes the characteristics, operation, and use of the TAS2559 Evaluation Module
(EVM). A complete schematic diagram, printed-circuit board layouts, and bill of materials are included in
this document.
NOTE: Recipient agrees to not knowingly export or re-export, directly or indirectly, any product or
technical data (as defined by the U.S., EU, and other Export Administration Regulations)
including software, or any controlled product restricted by other applicable national
regulations, received from Disclosing party under this Agreement, or any direct product of
such technology, to any destination to which such export or re-export is restricted or
prohibited by U.S. or other applicable laws, without obtaining prior authorization from U.S.
Department of Commerce and other competent Government authorities to the extent
required by those laws. This provision shall survive termination or expiration of this
Agreement. According to our best knowledge of the state and end-use of this product or
technology, and in compliance with the export control regulations of dual-use goods in force
in the origin and exporting countries, this technology is classified as follows:
US ECCN: 3E991
EU ECCN: EAR99
This technology may require export or re-export license for shipping it in compliance with the
applicable regulations of certain countries.
SLOU462A – November 2016 – Revised March 2017
Submit Documentation Feedback
TAS2559 Evaluation Module
Copyright © 2016–2017, Texas Instruments Incorporated
SLOU462A – November 2016 – Revised March 2017
TAS2559 Evaluation Module
User's Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAS2559 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments TAS2559

  • Page 1 SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module This user’s guide describes the characteristics, operation, and use of the TAS2559 Evaluation Module (EVM). A complete schematic diagram, printed-circuit board layouts, and bill of materials are included in this document.
  • Page 2: Table Of Contents

    Default Jumper Settings ................... TAS2559EVM Bill of Materials Trademarks PurePath is a trademark of Texas Instruments. Microsoft, Windows are registered trademarks of Microsoft Corporation. All other trademarks are the property of their respective owners. TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright ©...
  • Page 3: Description

    Software The TAS2559 EVM requires PurePath Console 3 with the TAS2559 plug-in. NOTE: The TAS2559 device needs to be configured using this software. It will not function without this configuration. Please refer to the Smart Amp Tuning Guide which can be found in the project folder at...
  • Page 4: Mono Setup

    5. Connect the EVM to a Windows 7+ PC with a micro-USB cable (J23). It will enumerate as a USB- AudioEVM device (sound card). Figure 1. TAS2559 EVM Mono Setup TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright ©...
  • Page 5: Setting Default Playback Device

    BCLK = on-board Pin 1-2 MCLK = on-board Pin 1-2 SCL = on-board Pin 1-2 SDA = on-board Remove Reset SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 6: 3-Pin Jumper

    ICC =1, inter-chip communication Pin 1-2 Address Select1 Figure 3. 3-Pin Jumper Please refer to Figure 5 for default jumper settings. TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 7: Stereo Setup

    6. Change to channel B in the device control pane and set to Right Channel. 7. Play the test tone as shown in Figure SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 8: Digital Audio Interfaces

    • Ground A jumper inserted in position 1-2 connects the TAS2559 to the digital audio signals from the board (for example, USB or Learning Board 2). Replacing the jumper with a connector from an external source connects the TAS2559 to the external source (for example, AP or PSIA).
  • Page 9: Usb Audio Selection

    To select USB, insert both J26 and J27 and insert J15, J16, J17, and J18 in the 1-2 position. This is shown in Figure Figure 5. USB Audio Selection SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 10: Direct (Ap/Psia) Audio Selection

    (for example AP or PSIA) to pin 2 of each head. Pin 3 provides a convenient ground connection. This is shown in Figure Figure 6. Direct (AP/PSIA) Audio Selection TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 11: Hardware Documentation

    Hardware Documentation www.ti.com Hardware Documentation TAS2559EVM Schematics Figure 7 through Figure 12 show the schematics for the TAS2559 EVM. USB_I2CEN IOVDD FROM LB2 CONN USB_I2CEN +3.3V 10.0k +3.3V +3.3V IOVDD IOVDD +3.3V 4.99k 2.00k 2.00k 10.0k 10.0k TP12 TP13 SCL-USB...
  • Page 12: Tas2559Evm Input Muxes And Translators

    LRCLK-to-LB2 WCLK1 USB_I2CEN SN74AVC4T774RSVR 49.9 LRCLK-MM SDIN0-LB2 MCLKIN-LB2 LEARNING BCLKIN-LB2 BOARD 2 LRCLKIN-LB2 Figure 8. TAS2559EVM Input Muxes and Translators TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 13: Tas2559Evm Output Muxes And Translators

    SDA-USB I2C-USB SDA-USB +3.3V SCL-USB +3.3V RESET XRA1206IG16-F 0.1µF 0.1µF 0.1µF 0.1µF 0.1µF Figure 9. TAS2559EVM Output Muxes and Translators SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 14: Tas2559Evm Channel 1 Schematic

    IOVDD TAS2559YZR MOSI 4700pF 4700pF RESET1 ADR1-1_MISO 10.0k ADR0-1_SCLK RESET1 SPI_SELECT1 SPI-SEL 0.1µF IRQ_GPIO4-1 Figure 10. TAS2559EVM Channel 1 Schematic TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 15: Tas2559Evm Channel 2 (Tas2560) Schematic

    10.0k 10.0k SCL2 RESET2 SDA2 0.1µF SDA2 ADDR 22.1k ADDR IOVDD ADDR SEL Figure 11. TAS2559EVM Channel 2 (TAS2560) Schematic SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 16: Tas2559Evm Power Supply

    0.01µF VBAT1 VBAT1 22µF 0.1µF Hi Current Shunt VBAT1 VBAT2 VBAT VBAT2 VBAT2 22µF 0.1µF Figure 12. TAS2559EVM Power Supply TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 17: Top Overlay

    Hardware Documentation www.ti.com TAS2559 EVM Printed Circuit Board Layout Figure 13. Top Overlay Figure 14. Top Solder Mask SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 18: Top Layer

    Hardware Documentation www.ti.com Figure 15. Top Layer Figure 16. Copper Layer 2 TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 19: Copper Layer 3

    Hardware Documentation www.ti.com Figure 17. Copper Layer 3 Figure 18. Copper Layer 4 SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 20: Copper Layer 5

    Hardware Documentation www.ti.com Figure 19. Copper Layer 5 Figure 20. Bottom Layer TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 21: Bottom Solder Mask

    Hardware Documentation www.ti.com Figure 21. Bottom Solder Mask Figure 22. Drill Drawing SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 22: Board Dimensions

    Hardware Documentation www.ti.com Figure 23. Board Dimensions TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 23: Tas2559Evm Bill Of Materials

    Double Sided Tape for Double Sided Tape 1/2-5-9495LE 3M (TC) Applying Speakers to Boards JUMPER TIN SMD 6.85x0.97x2.51 mm S1911-46R Harwin SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 24 RES, 100k ohm, 1%, 0.063W, CRCW0402100KFKE 100k 0402 Vishay-Dale 0402 RES, 0 ohm, 5%, 0.063W, R30, R31, R32, R33 0402 CRCW04020000Z0ED Vishay-Dale 0402 TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 25 4-BIT DUAL-SUPPLY BUS TRANSCEIVER WITH CONFIGURABLE VOLTAGE U6, U11, U24 RSV0016A SN74AVC4T774RSVR Texas Instruments None TRANSLATION AND 3- STATE OUTPUTS, RSV0016A SLOU462A – November 2016 – Revised March 2017 TAS2559 Evaluation Module Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 26 CRCW04022K00FKE R9, R10 2.00k 0402 Vishay-Dale 0402 RES, 1.00 k, 1%, 0.063 W, CRCW04021K00FKE R53, R57 1.00k 0402 Vishay-Dale 0402 TAS2559 Evaluation Module SLOU462A – November 2016 – Revised March 2017 Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 27 Page ......................... • Changed Figure 1 ......................... • Changed Figure 4 ......................... • Changed Figure 5 ........................• Changed Figure 6 SLOU462A – November 2016 – Revised March 2017 Revision History Submit Documentation Feedback Copyright © 2016–2017, Texas Instruments Incorporated...
  • Page 28 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
  • Page 29 FCC Interference Statement for Class B EVM devices NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 30 【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの 措置を取っていただく必要がありますのでご注意ください。 1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用 いただく。 2. 実験局の免許を取得後ご使用いただく。 3. 技術基準適合証明を取得後ご使用いただく。 なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。 上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ ンスツルメンツ株式会社 東京都新宿区西新宿6丁目24番1号 西新宿三井ビル 3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/ /www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 3.4 European Union 3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive): This is a class A product intended for use in environments other than domestic environments that are connected to a low-voltage power-supply network that supplies buildings used for domestic purposes.
  • Page 31 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2017, Texas Instruments Incorporated...
  • Page 32 IMPORTANT NOTICE FOR TI DESIGN INFORMATION AND RESOURCES Texas Instruments Incorporated (‘TI”) technical, application or other design advice, services or information, including, but not limited to, reference designs and materials relating to evaluation modules, (collectively, “TI Resources”) are intended to assist designers who are developing applications that incorporate TI products;...
  • Page 33 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TAS2559EVM...
