- Page 1 VOLT Q5E SIX PACK™ user manual...
- Page 2 +31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu info@elationlighting.eu Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000 +52 (728) 282-7070 D O C U M E N T V E R S I O N Due to additional product features and/or enhancements, an updated version of this document may be available online.
-
Page 3: Table Of Contents
C O N T E N T S General Information Warranty Returns (USA Only) Safety Guidelines Maintenance Guidelines Overview Battery Charging Installation Guidelines System Menu Internal Wireless DMX Receiver Setup DMX Channel Functions and Values Specifications Optional Accessories... -
Page 4: General Information
(6) 9.8 ft. (3m) 3pin IP Female to 3pin DMX Male DATA INPUT Cables (6) Magnetic Frost Filters (6) Omega Brackets CUSTOMER SUPPORT Contact ELATION Service for any product related service and support needs. Also visit forums.elationlighting.com with questions, comments or suggestions. -
Page 5: Warranty Returns (Usa Only)
B. For warranty service, send the product only to the Elation Professional factory. All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, Elation Professional will pay return shipping charges only to a designated point within the United States. -
Page 6: Safety Guidelines
These fixtures are sophisticated pieces of electronic equipment. To guarantee a smooth opera- tion, it is important to follow all instructions and guidelines in this manual. Elation Profession- al is not responsible for injury and/or damages resulting from the misuse of these fixtures and charging road case due to the disregard of the information printed in this manual. - Page 7 Consistent operational breaks will ensure fixture will function properly for many years. ONLY use the ROAD CASE to transport all 6 fixtures in for service. If you have a need to send less than 6 fixtures, please contact ELATION SERVICE for packaging instructions. BATTERY USE DO NOT EXPOSE BATTERY TO EXTREME HOT OR COLD TEMPERATURES.
-
Page 8: Maintenance Guidelines
Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside these fixtures and road case, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer. -
Page 9: Overview
O V E R V I E W LEDs Lens Wireless Wireless DMX Carrying LCD Menu Handle Indicator Display Antenna Charge Indicator DMX In/Out MODE/ESC Power Switch Button Power In ENTER Button UP Button Safety Cable DOWN Button Anchor Point... -
Page 10: Battery Charging
B AT T E R Y C H A R G I N G The rechargeable Lithium-Ion battery provides up to 7 hours of operation at FULL ON 100% intensity. BATTERY LIFE MAY VARY DEPENDING ON FIXTURE USAGE, SETTINGS, INSTALLATION LOCATION TEMPERATURE, AND TOTAL NUMBER OF CHARGE CYCLES. -
Page 11: Installation Guidelines
NOT be subject to any warranty claims and/or repairs. OPTIONAL CORROSION-RESISTANT COATING Optional Corrosion-Resistant Coatings may be available for this fixture. Please contact Elation Professional for more details. FLAMMABLE MATERIAL WARNING Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics. - Page 12 I N S TA L L AT I O N G U I D E L I N E S OMEGA BRACKETS INSTALLATION Use the included Omega Bracket to mount the fixture(s) on truss or other suitable structure. Insert the Omega Bracket into the matching holes on the bottom of each fixture. Secure the Omega Brackets to the fixture by turning each quick-lock fastener ¼...
- Page 13 LEDs. This issue is not specific only to ELATION lighting fixtures, it is a common issue with lighting fixtures from all manufacturers. Although there is no true way to fully prevent this issue from happening, the guidelines below can prevent any potential damage from occurring if followed.
-
Page 14: System Menu
SYSTEM MENU The fixture includes an easy to navigate system menu. The control panel (see image below) located on the front of the fixture, provides access to the main system menu and is where all necessary system adjustments are made to the fixture. During normal operation, pressing MODE/ESC button once will access the fixture’s main menu. - Page 15 S YS T E M M E N U ELATION VOLT Q5E™ Supports Software Versions: ≥ 1.0.3 OPTIONS / VALUES (Default Settings in MAIN MENU SUB MENU DESCRIPTION BOLD) Address A001~AXXX DMX Address Setting ValuDisp ALL…… DMX Value Display FuncMode...
- Page 16 S YS T E M M E N U PERSNAL - Stat Set - Addr DMX When ON, define the desired DMX address via an external controller. NOTE: This process assumes the fixture DMX address is set to 001. If fixture DMX address is not at 001, you must adjust the channel numbers accordingly in order for this feature to work.
- Page 17 SYSTEM MENU EDIT PROGRAM – Record Controller – Working With Built In Programs A Primary unit can send up to 3 different data groups to the Secondary units, i.e. a Primary unit can start 3 different Secondary units, which run 3 different programs. The Primary unit sends the 3 program parts in a continuous loop.
- Page 18 S YS T E M M E N U EDIT PROGRAM – Record Controller – Working with Built-In Program [continued] 4. Program Selection for Edit Program Select “EditProg”. Press ENTER to confirm. Select the desired program. With this function you can edit specific scenes into a specific program.
-
Page 19: Internal Wireless Dmx Receiver Setup
I N T E R N A L W I R E L E S S D M X R E C E I V E R ( E W D M X ) The VOLT Q5E™ is equipped with an internal Elation Wireless DMX Receiver, which is fully compatible with an Elation Wireless DMX System. - Page 20 I N T E R N A L W I R E L E S S D M X R E C E I V E R ( E W D M X ) CLEARING EWDMX TRANSMITTER LINK Access the fixture’s main menu and toggle to the “PERSNAL” menu, then access the “WDMX” sub menu and select “ClrWDMX”...
-
Page 21: Dmx Channel Functions And Values
D M X T R A I T S : C H A N N E L F U N C T I O N S & VA L U E S ELATION VOLT Q5E Supports Software Versions: ≥ 1.0.3... - Page 22 ELATION VOLT Q5E Supports Software Versions: ≥ 1.0.3 Features subject to change without notice MODE/CHANNEL VALUE FUNCTION 4 CH 7 CH 9 CH COLOR CHASE MACROS No Function 1-30 Chase Macro 1 31-60 Chase Macro 2 61-90 Chase Macro 3...
-
Page 23: Specifications
S P E C I F I C AT I O N S VOLT Q5E VOLT Q5™ CHARGING ROAD CASE FEATURES SOURCE Charges (6) Volt Q5™ Units (5) 10W QUAD Color RGBW LEDs Charge Status Windows for each unit 100,000 Hour Average Life* *May vary depending on several factors including SIZE / WEIGHT (loaded case with 6 units) but not limited to:... - Page 24 D I M E N S I O N S *Drawings not to scale. Specifications and improvements in the design of this unit and this manual are subject to change without notice. VOLT Q5E CHARGING ROAD HOUSE...
-
