Elation SIX+ PAR S OPS User Manual

Elation SIX+ PAR S OPS User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
.5 inch
1 inch
1.5 inch
SIX+ PAR S
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIX+ PAR S OPS and is the answer not in the manual?

Questions and answers

Related Manuals for Elation SIX+ PAR S OPS

Summary of Contents for Elation SIX+ PAR S OPS

  • Page 1 .5 inch 1 inch 1.5 inch SIX+ PAR S User Manual...
  • Page 2 Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands +31 45 546 85 66 | +31 45 546 85 96 fax | www.elationlighting.eu | info@elationlighting.eu Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000...
  • Page 3 C O N T E N T S General Information IP65 Rated Limited Warranty (USA Only) Safety Guidelines Overview Torque Settings for Screws IP Test Parameters Installation Guidelines Accessory Installation Near Field Communication (NFC) Remote Device Management (RDM) Dimmer Modes & Curves DMX Traits Emulation DMX Traits Color Temperature Chart...
  • Page 4 Gel Frame and Holder Kit (x1) Safety Cable (x1) Power Cable (x1) CUSTOMER SUPPORT Contact ELATION Service for any product related service and support needs. Also visit forums.elationlighting.com with questions, comments, or suggestions. ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST 323-582-3322 | Fax 323-832-9142 | support@elationlighting.com...
  • Page 5 I P 6 5 R AT E D The International Protection (IP) rating system is commonly expressed as “IP” (Ingress Protection) followed by two numbers (i.e. IP65), where the numbers define the degree of protection. The first digit (Foreign Bodies Protection) indicates the extent of protection against particles entering the fixture, and the second digit (Water Protection) indicates the extent of protection against water entering the fixture.
  • Page 6 ELATION and/or an ELATION Authorized Service Center, unless prior written authorization was issued to the purchaser/owner by ELATION; if the product damage is as a result of the use of parts not manufactured, sold, or recommended by ELATION and/or in connection with the integration of any third-party equipment, accessory, and software not sold, distributed, or approved by ELATION;...
  • Page 7 5. Outdoor Permanent, Marine, or extreme weather location applications using ELATION Professional products are subject to a 5-year limited warranty, and ELATION must be notified prior to delivery of units for such applications so that preventative treatment can be made to the products to ensure proper performance and product life with a special marine code coating/sealing process at an additional cost.
  • Page 8 S A F E T Y G U I D E L I N E S This fixture is a sophisticated piece of electronic equipment. To guarantee smooth operation, it is important to follow all instructions and guidelines in this manual. Elation Professional is not responsible for injury and/or damages resulting from the misuse of this fixture due to the disregard of the information printed in this manual.
  • Page 9 S A F E T Y G U I D E L I N E S RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET UV RADIATION! FIXTURE EMITS HIGH INTENSITY WAVELENGTH OF ULTRAVIOLET UV LIGHT FROM THE UV COLOR FILTER. WEAR PROPER SKIN...
  • Page 10 O V E R V I E W Bracket Adjustment Knob Mounting Bracket With 2-wire With 4-wire plate plate Mark Valve Power Power Power Input In & Out Valve Input Output Output Input Cable Cable Cable Cable Cable Cable...
  • Page 11 T O R Q U E S E T T I N G S F O R S C R E W S IN ORDER TO MAINTAIN THE IP65 RATING ON THE LIGHTING FIXTURES, ALL SCREWS MUST BE TIGHTENED TO THE FOLLOWING TORQUE SPECIFICATION USING A TORQUE DRIVER.
  • Page 12 Following any repair or maintenance procedure that requires disassembly of the fixture, use Elation’s IP Tester to confirm the IP integrity of the fixture. The air valve is located on the same side as the Power Out and DMX Out ports, as shown in the diagram below. Please...
  • Page 13 I N S TA L L AT I O N G U I D E L I N E S FLAMMABLE MATERIAL WARNING Keep fixture minimum 1.6 feet (0.5m) away from flammable materials and/or pyrotechnics. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations.
  • Page 14 I N S TA L L AT I O N G U I D E L I N E S CLAMP INSTALLATION This device features a mounting clamp attachment point built into the mounting bracket. To install, align the hole on the mounting clamp with the central hole in the mounting bracket, then insert a bolt of the appropriate rating through the hole and secure in place with a match- ing nut.
  • Page 15 I N S TA L L AT I O N G U I D E L I N E S FIXTURE INSTALLATION The Elation SIX+ PAR S is fully operational in three different mounting positions, hanging upside-down, mounted sideways on trussing, or set on a flat level surface. Be sure this fixture is kept at least 0.2m (7.9in.) away from any flammable materials (decoration etc.).
  • Page 16 LEDs. This issue is not specific only to ELATION lighting fixtures, it is a common issue with lighting fixtures from all manufacturers. Although there is no true way to fully prevent this issue from happening, the guidelines below can prevent any potential damage from occurring if followed.
  • Page 17 A C C E S S O RY I N S TA L L AT I O N - F R O S T L E N S 2. Install the Frost Lens by angling the bezel groove of 1. Slide lock levers inward to retract the locking tabs. the Frost Lens into the tab and levering it into place.
  • Page 18 A C C E S S O RY I N S TA L L AT I O N - G E L F R A M E 1. Align the 4x holes on the Holder with the face of the fixture, and secure it with 4x philips head screws 2.
  • Page 19 A C C E S S O RY I N S TA L L AT I O N - B A R N D O O R 1. Flip open the retaining clip located near 2. Slide the barndoor into place in front of the top of the lens.
  • Page 20 N E A R F I E L D C O M M U N I C AT I O N ( N F C ) Near Field Communication (NFC) is a short-range wireless technology, operating at 13.56 MHz, that enables secure data exchange between devices within a proximity of 6-inches. With NFC, one can use an Android or iOS device to configure an NFC compatible fixture.
  • Page 21 R E M O T E D E V I C E M A N A G E M E N T ( R D M ) NOTE: In order for RDM to work properly, RDM enabled equipment must be used throughout the entire system, including DMX data splitters and wireless systems.
  • Page 22 D I M M E R M O D E S & C U R V E S DIMMER 100% Time (ms) 0 Sec Rise Time Down Time 0 sec Fade Time 1 sec Fade Time Dimming Curve Ramp Effect Rise Time (ms) Down Time (ms) Rise Time (ms) Down Time (ms) Standard (default) Stage...
  • Page 23 D M X T R A I T S Color Dim. Color Std. Ext. Snap Default Ext. & Dim. Ext. Function 11CH 14CH 20CH Values Value 14CH Dimmer 0-255 Intensity 0 → 100% Dimmer Fine 0-255 Fine Intensity Control Shutter/Strobe 0-31 Shutter closed 32-63...
  • Page 24 D M X T R A I T S Color Dim. Color Std. Ext. Snap Default Ext. & Dim. Ext. Function 11CH 14CH 20CH Values Value 14CH Color Open 1-179 Virtual Swatch Book (See Table) Color Scroll 180-201 Clockwise Fast → Slow 202-207 Stop 208-229 Counter-clockwise Slow →...
  • Page 25 D M X T R A I T S Color Dim. Color Std. Ext. Snap Default Ext. & Dim. Ext. Function 11CH 14CH 20CH Values Value 14CH Control 0-84 Idle 85-89 Bluetooth On 90-94 Bluetooth Off (Default) 95-99 Idle Refresh Rate (Hz) 1000 1010 1020...
  • Page 26 D M X T R A I T S Color Dim. Color Std. Ext. Snap Default Ext. & Dim. Ext. Function 11CH 14CH 20CH Values Value 14CH 1270 1280 1290 1300 1310 1320 1330 1340 1350 1360 1370 1380 1390 1400 1410 1420...
  • Page 27 E M U L AT I O N D M X T R A I T S Default 6 ch 7 CH 8 CH 12 CH Value Function Snap Value 0-255 0 → 100% Green 0-255 0 → 100% Blue 0-255 0 →...
  • Page 28 E M U L AT I O N D M X T R A I T S Default 6 ch 7 CH 8 CH 12 CH Value Function Snap Value 124-127 RED + AMBER + UV 128-131 GREEN + BLUE + WHITE 132-135 GREEN + BLUE + AMBER 136-139 GREEN + BLUE + UV 140-143 GREEN + WHITE + AMBER...
  • Page 29 C O LO R T E M P E R AT U R E DMX VALUE COLOR TEMPERATURE (K) DMX VALUE COLOR TEMPERATURE (K) 2400 6300 2500 6400 2600 6500 2700 6600 2800 6700 2900 6800 3000 6900 3100 7000 3200 7100 3300...
  • Page 30 V I R T U A L C O L O R S VALUE FILTER # COLOR VALUE FILTER # COLOR Pale Yellow Mauve Straw Medium Purple Gold Tint Lavender Spring Yellow Palace Blue Medium Yellow Dark Blue Yellow Medium Blue Deep Amber Deep Blue Deep Straw...
  • Page 31 S O F T WA R E U P D AT E S AN ELATION C-LOADER II CAN ALSO BE USED TO UPDATE THE FIXTURE TO THE LATEST SOFTWARE. To order this device, please contact Elation Support for further details.
  • Page 32 Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture. Please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from an authorized Elation dealer.
  • Page 33 S P E C I F I C AT I O N S SIZE / WEIGHT SOURCE Length: 7.6” (193mm) (7) x 20W RGBLA+ UV LEDs Width: 9.5” (241mm) 30,000 Hour Average LED Life* Vertical Height: 9.1” (230mm) *May vary depending on several factors Weight: 9.5 lbs (4.3 kg) including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns...
  • Page 34 D I M E N S I O N D R AW I N G S Drawings not to scale 230mm [9.1in.] 241mm [9.5in.] 134mm [5.3in.] 241mm [9.5in.] 130mm [5.1in.] 110mm [4.3in.]...
  • Page 35 D I M E N S I O N D R AW I N G S Drawings not to scale Ø6.4in. [Ø162.0mm] 1.7in. [43.5mm] H H O O L L D D E E R R 8.0in. [202.4mm] 0.9in. [22.0mm] 0.2in.
  • Page 36 O R D E R I N G I N F O R M AT I O N SKU US/EU ITEM DESCRIPTION SIX434 1237000372 SIX+ PAR S OPS SIX+S WFL 1223200104 60° lens SIX+S XFL 1223200105 100° Lens SIX+S L1060 1223200102 10°x60°...
