Oven Serial Number _________________________________
Oven Code
149
150
153
158
159
170
Condenser Serial Number ____________________________ (if fitted)
www.monoequip.com
In the event of an enquiry, please quote these serial numbers.
Bx OVEN
Eco
Installation and Operation Manual
4/5/10-Tray | Steam
FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eco FG159 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mono Eco FG159

Summary of Contents for Mono Eco FG159

  • Page 1 Oven Serial Number _________________________________ Oven Code Condenser Serial Number ____________________________ (if fitted) www.monoequip.com In the event of an enquiry, please quote these serial numbers. Bx OVEN Installation and Operation Manual 4/5/10-Tray | Steam FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 2 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 3 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens ATTENTION If oven fails to heat up, when first connected to a power supply or during use at any time, press the reset buttons located on the rear back panel.
  • Page 4 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Safety symbols The following safety symbols are used throughout this document and manual (available at www.monoequip.com). Before using your new equipment, read the instruction manual carefully and pay special attention to information...
  • Page 5 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Electrical safety and advice regarding supplementary electrical protection Commercial kitchens and food service areas are environments where electrical appliances may be located close to liquids or operate in and around damp conditions or where the restricted movement for installation and service is evident.

  • Page 6: Table Of Contents

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Contents Page 1. Introduction ......................7 2. Specifications ....................... 8 3. Safety ........................9 4. Installation ......................10 Power ..............................10 Water ..............................11 Ventilation ............................11 Before use ............................11 Safety ..............................

  • Page 7: Introduction

    “A combination of clean industrial design and the latest technology.”  The MONO BX oven range is designed to take the baking Industry’s standard trays.  Ovens in the range are of stainless steel construction and selected models have removable tray racks to aid cleaning.

  • Page 8: Specifications

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 2. Specifications Table 1: Technical specifications 4/5 Tray 10 Tray eco-connect model no. FG159 FG153 FG158 FG150 FG149 FG170 Tray size (mm) 400 x 600 600 x 400 400 x 600...

  • Page 9: Safety

    Do not attempt any repairs.  Contact the Mono Service Department for advice.  Fit only MONO spare parts to this oven.  All connections to the oven must comply with the statuary requirements of the country of installation. ...

  • Page 10: Installation

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 4. Installation Power Warning!  A 30mA Residual Current Device (RCD) must protect the supply to this machine.  Always fit a wall isolator to isolate the oven completely. The isolator must be visible, labelled clearly, and easily accessible by an operator.

  • Page 11: Water

    Allow a 50 mm gap at the sides and rear of this oven.  Chimneys and evacuation ducts fitted above mono ovens should be insulated. Before use In the interests of hygiene, we strongly recommend that, before using the oven for the first time, you wipe the inside of the oven and all accessories thoroughly with a clean cloth soaked in warm soapy water.

  • Page 12: Ambient Working Temperatures

    It is the customers’ sole responsibility to arrange for adequate ventilation. Any component malfunctioning during the guarantee period found to have been subject to excessive humidity or ambient working temperature above 40 °C (115 °F) will not be covered by the component manufacturer guarantee or MONO’s product warranty. MONO...

  • Page 13: Isolation

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens 5. Isolation Electrical supply To stop the oven in an emergency, switch off the electricity at the wall isolator. Water supply In an emergency, shut off the water supply to stacked ovens by closing the shut-off valves...

  • Page 14: Touchscreen Operations

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 6. Touchscreen Operations Operations are performed by touching an area of the screen, bringing up the next information panel, or activating a function. Caution!  Do not use excessive force. The pressure required to operate the touchscreen panel is adjustable in the Settings menu.

  • Page 15: Starting And Operating Using Ready-Made Recipes (Programs)

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Starting and operating using ready-made recipes (programs) Ensure the power and water supplies are safely connected to the oven (see Installation on page 7). If the display (A) is off, press the green power button (B) at the bottom of the front panel.
  • Page 16 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Touch the Program panel. Select the program required. (a) Keeping a finger touching the screen, slide the finger up and down to scroll through the list. (b) Touch a program name (e.g., Program03) to highlight it.
  • Page 17 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Load the oven with trays of products and close the door. Note To maintain the heat in the oven, do not leave the door open for longer than needed. The actual oven temperature fluctuates during a bake –...

  • Page 18: Continuous Bake (No Program Mode)

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Continuous bake (no program mode) Touch the Program panel. Select the Continuous Bake program. (a) Keeping a finger touching the screen, slide the finger up and down to scroll through the list.
  • Page 19 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Touch the Start button (B) to begin heating the oven. Wait while the oven heats up to the set temperature.  The Temperature button flashes while the oven is heating.
  • Page 20 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Touch the Start button (B) to start baking.  Baking begins with the oven light switched on.  The oven maintains the temperature with the fan running in forward and reverse cycles.

  • Page 21: Setting The Time And Date

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Setting the time and date Touch the Settings button. Enter the password, and then touch the Tick () button. Note Default passwords for the various access levels are in the Passwords section. However, for security reasons, the passwords section may have been removed.
  • Page 22 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Use the up or down arrows to make adjustments.  The time, date, month, and year can be adjusted.  The day is not adjustable – it automatically updates using the date, month, and year.

  • Page 23: Setting Up A New Program

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Setting up a new program Touch the Program panel. Choose a new, unused program (e.g., Program05). If a pop-up window appears asking to save values, touch the No option.
  • Page 24 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Set the baking temperature required. (a) Touch the temperature button (A). (b) Use the keypad to edit the temperature, and then touch the Tick () button. Set the timer function.
  • Page 25 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Set the steam function (optional). (a) Touch the Steam button to set the operation time. (b) Use the keypad to enter the seconds required (e.g., 10). (c) Touch the Tick () button.
  • Page 26 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Save the recipe program by touching the Save icon.  Touch the Yes option when prompted to save the recipe changes. Enter the password and touch the Tick () button.
  • Page 27 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens 10. Change the program title. (a) Touch the Change Program Title icon. (b) Enter the password and touch the Tick () button. (c) Type the new name of the recipe program.

  • Page 28: Putting The Oven Into Standby Mode

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Putting the oven into Standby mode The Standby button turns the oven off until the screen is touched again. Putting the oven into Sleep mode The Sleep button instructs the oven to maintain temperature to a pre-set fall-back setting.

  • Page 29: User Settings (Oven Setup)

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens User settings (oven setup) Caution!  Do not make changes to settings unless you are fully aware of the results. Touch the Settings button. Enter the password and touch the Tick () button.
  • Page 30 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 5. Touch the page required (i.e., 1, 2, or 3). Page 1 Page 2 Page 3 6. To make an adjustment, touch the item and edit a new setting.

  • Page 31: Factory Settings (Oven Setup)

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Factory settings (oven setup) Caution!  Do not make changes to settings unless you are fully aware of the results. Touch the Settings button. Enter the password and touch the Tick () button.
  • Page 32 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 5. Touch the page required (i.e., 1, 2, or 3). Page 1 Page 2 Page 3 6. To make an adjustment, touch the item and edit a new setting.

  • Page 33: Changing The Passwords

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Changing passwords Touch the Settings button. Enter the password and touch the Tick () button. Note Default passwords for the various access levels are in the Passwords section. However, for security reasons, the passwords section may have been removed.
  • Page 34 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual 5. Touch the password level you want to change. 6. Change to password. Touch the Old Password box (C), and enter the current password. Touch the New Password box (D), and enter the new password.

  • Page 35: Diagnostics

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Diagnostics The operation of the following items can be checked from the diagnostics screen: Door switch operation Fan reverse Lights on/off    Heater Steam solenoid Sound ...
  • Page 36 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Using the diagnostics screen 1. Touch the Force button next to the item to be tested.  A blue arrow appears. 2. Touch the Test button (A) of that item to start the test.

  • Page 37: Cleaning

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens 7. Cleaning Warning!  Isolate the oven from the mains supply and allow time to cool before cleaning. Warning!  Do not remove the rear panelling inside the oven. That panel provides access to the fan assembly, which is not safety interlocked and could cause serious injury.

  • Page 38: Additional For Ovens With 60 Cm X 40 Cm Trays (Fg158 4-Tray)

    MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Additional cleaning for ovens with 60 cm x 40 cm trays (FG158 4-tray) Open the oven door. Lift and unlatch the internal racking. Remove the internal racking from the sides of the oven.

  • Page 39: Maintenance

    Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens 8. Maintenance General maintenance  Check for frayed or bare cables.  Do not use the machine if frayed or bare cables are visible.  Follow cleaning instructions (see Cleaning on page 29).
  • Page 40 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Take the frame (B), glass (C) and gasket (D) off the lamp unit. Remove the light bulb (E) by pulling in the direction of the arrow. Replace it with a new light bulb.
  • Page 41 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens 9. Condenser Unit (Option) Caution!  All versions should be part of a regular cleaning schedule. Water should be drained and parts cleaned with an antibacterial wash. Index Introduction ..........page 42 Dimensions ..........
  • Page 42 Installation and Operation Manual Introduction (condenser unit) A condenser unit can be fitted to any MONO Bx oven (or stacked Bx ovens) as required. The thermostatic control can be adjusted to operate in most ambient temperatures. A simple water connection (washing machine type fitting) and a hose to drain are required to operate efficiently.
  • Page 43 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Dimensions (condenser unit) Figure 7: Dimensions of a condenser unit Water out Water in Rear of the oven FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 44 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Specifications (condenser unit) Power  230 Vac (50 Hz), single phase  21 Watts  Wired to the oven electrical panel. Water  Washing machine type connection to the normal water supply via steam water connection to the oven(s).
  • Page 45 While the oven is in operation (and for some time after use), it is inadvisable to touch the condenser or the surrounds because of conducted heat.  No unauthorised modifications to the condenser are permitted.  Only use MONO spare parts on this condenser. FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 46 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Installation (condenser unit) Ensure that all power is disconnected and the oven is cool. Before fitting the main condenser assembly, insert blanking plug (A) into the lower hole that will not be required for the type of oven being used.
  • Page 47 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Figure 8: Installation of a condenser unit FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 48 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Figure 9: Water pipe connections Condenser solenoid Oven #1 Oven #2 Bracket fixings for the water tap Mains water supply inlet Tee-pipe for double oven connection MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 49 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Operation (condenser unit) Review all safety sections in this manual. Ensure that the water is connected correctly and the oven power is on. Adjust the thermostat control to the required position (Figure 10).
  • Page 50 Installation and Operation Manual Spares (condenser unit) This section is for Engineer use only Do not attempt any modifications to the condenser or oven. If in doubt, contact Mono Equipment for advice. Figure 11: Main parts of the condenser unit MONO FG0BX-UK-MAN-0100 | Rev.
  • Page 51 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Item Part number Description Quantity 150-07-01300 Inlet water control unit 150-19-01700 Top sheet 150-19-02300 Cover plate 150-19-02600 Base tray 150-19-02700 Water tank 150-25-07100 Junction box A900-01-196 Jubilee clip A900-01-271...
  • Page 52 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Other versions of the condenser that may be fitted The following evaporation design versions could be fitted to your oven. They only require to be plugged into the socket found to the rear of the oven (Figure 12).
  • Page 53 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Figure 13: Condenser unit FG150/AC5 FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 54 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Figure 14: Condenser assembly FG155/X38 MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 55 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Figure 15: Condenser assembly FG158/AC1 FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 56 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Figure 16: Reduced height condenser FG158/AC3 MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 57 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens Figure 17: Reduced height condenser FG158/AC4 FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 58 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual Figure 18: Condenser FG159/AC1 MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)

  • Page 59: Passwords

    Oven setting access – setting time/date, etc. 3142 Oven factory settings access. Note If the passcodes have been changed and are not available, contact Mono Equipment for a master number that will open all screens. FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 60 MONO Bx Eco Ovens 4/5/10-Tray | Steam Installation and Operation Manual (Intentional Blank Page) MONO FG0BX-UK-MAN-0100 | Rev. A21 (July 2021)
  • Page 61 Installation and Operation Manual 4/5/10-Tray | Steam MONO Bx Eco Ovens (Intentional Blank Page) FG0BX-UK-MAN-0100 | Rev. A21 (July 2021) MONO...
  • Page 62 If a fault arises, please do not hesitate to contact the Customer Service Department, quoting the machine serial number on the silver information plate of the machine and on the front cover of this manual Mono Equipment Limited Queensway Swansea West Industrial Estate Swansea, SA5 4EB, UK spares@monoequip.com...

This manual is also suitable for:

Eco fg153Eco fg158Eco fg150Eco fg149Eco fg170

Table of Contents
