SIA B
Self and Dual powered Overcurrent & Earth Fault Protection Relay
USER´S MANUAL
SIA_MANU_SIAB_ING_R006.Docx

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIA B and is the answer not in the manual?

Questions and answers

Related Manuals for FANOX SIA B

Summary of Contents for FANOX SIA B

  • Page 1 SIA B Self and Dual powered Overcurrent & Earth Fault Protection Relay USER´S MANUAL SIA_MANU_SIAB_ING_R006.Docx...

  • Page 2: Table Of Contents

    6.2. States and Events ..........................36 6.3. Fault Reports ............................ 40 6.4. Date and Time by Real Time Clock (RTC) ..................40 6.5. Self-diagnosis ..........................41 6.6. Commands ............................41 6.7. Test Menu ............................42 6.8. Power supply............................ 42 www.fanox.com Rev. 06 2/99...
  • Page 3 MODBUS RTU PROTOCOL ......................85 9.1. ModBus packaged format ....................... 86 9.2. Function codes ..........................86 9.3. Exemptions and error answers ...................... 87 9.4. Data type ............................87 9.5. Memory map of SIA-B ........................88 9.6. Commands Map ..........................92 www.fanox.com Rev. 06 3/99...
  • Page 4 10.7. Front communications port ......................93 10.8. Commissioning ..........................94 11. APPENDIX ............................95 11.1. Identification............................. 95 11.2. Checks .............................. 95 11.3. Test menu ............................95 11.4. Register of commissioning settings ....................95 11.5. Comments ............................97 www.fanox.com Rev. 06 4/99...

  • Page 5: Reception, Handling & Installation

    It is necessary to inspect the equipment at the time it is delivered to ensure that the relays have not been damaged during transport. If any defect is found, the transport company and FANOX should be informed immediately. If the relays are not for immediate use, they should be returned to their original packaging.

  • Page 6: Installation, Commissioning And Service

    All electrical power sources should be removed before performing this operation to avoid the risk of electrical discharge. This product must be disposed of in a safe way. It should not be incinerated or brought into contact with water sources like rivers, lakes, etc… www.fanox.com Rev. 06 6/99...

  • Page 7: Dimensions And Connection Diagrams

    DIMENSIONS AND CONNECTION DIAGRAMS 2.1. Frontal view www.fanox.com Rev. 06 7/99...

  • Page 8: Case Dimensions

    2.2. Case dimensions The dimensions are in mm. Cut-out pattern www.fanox.com Rev. 06 8/99...

  • Page 9: Connection Diagram

    2.3. Connection diagram  NOTE! STRIKER: 6 – 24 Vdc & <= 0.1 W·s www.fanox.com Rev. 06 9/99...

  • Page 10: Terminals

    External trip C3-C4 Phase B current output for measurement and self- Auxiliary power supply + power Phase C current input for measurement and self-power Auxiliary power supply - Phase C current output for measurement and self- power www.fanox.com Rev. 06 10/99...

  • Page 11: Description

    Worldwide, the energy sector is currently undergoing a profound change as a result of high levels of energy demand; more distribution lines and advanced supervision systems are required. Given the need for creating intelligent infrastructure, FANOX has developed the SIA family of products to carry out this function.
  • Page 12 The equipment has a frontal communication port (miniUSB). This port allows a PC to be connected, which can be used to monitor the equipment using the SICom communications program (supplied by FANOX). Besides, the frontal port can be used to power the equipment by using an USB cable which can be directly connected with PC.

  • Page 13: Functional Diagram

    Battery power accessory: 5 V with Kitcom adaptor Monitoring and recording Events saved in the non-volatile FRAM* memory Commands Optional Settings groups  Real-Time Clock (RTC) Fault reports 4 (24 events each one)  Test menu  Self-diagnosis 3.3. Functional Diagram www.fanox.com Rev. 06 13/99...

  • Page 14: Selection And Ordering Codes

    2 led’s + trip output (striker) + External trip input (49T) + 1 FLAG MECHANICAL ASSEMBLY LANGUAGE English, Spanish and German English, Spanish and Turkish English , Spanish and French English , Spanish and Russian ADAPTATION www.fanox.com Rev. 06 14/99...

  • Page 15: Specific Cts

    Depending on the model selected, there are the following primary currents: Is range CT type 8-28 (A) CT008-5 CT016-5 16-56 (A) CT016-10 32-112 (A) CT032-5 64-224 (A) CT064-5 128-448 (A) CT128-5 256-896 (A) CT256-5 The main characteristics of the transformers are: www.fanox.com Rev. 06 15/99...
  • Page 16 Cable diameter 8-28 (A) 5P80 45 mm 16-56 (A) 5P80 50 mm 16-56 (A) 10P80 50 mm 32-112 (A) 5P80 50 mm 64-224 (A) 5P80 50 mm 128-448 (A) 5P80 50 mm 256-896 (A) 5P80 50 mm www.fanox.com Rev. 06 16/99...
  • Page 17 Three transformers are needed, one per each phase. In the following picture, it is possible to see the label corresponding to CT016, where the connecting terminals are showed. Terminals: Primary Input Primary output A-/S2 Output for current measurement A+/S1 Input for current measurement B+ B-/C-D Test wiring terminals www.fanox.com Rev. 06 17/99...
  • Page 18  Dimensions: www.fanox.com Rev. 06 18/99...

  • Page 19: Test Winding

    CT08 25 A CT16 50 A CT32 100 A CT64 200 A CT128 400 A CT256 800 A The correct measurement of these values in the relay guarantees that the whole current range will be measured. www.fanox.com Rev. 06 19/99...

  • Page 20: Protection Functions

    0,05 1,25 0,01 1,25 0,20 7,00 0,01 1,00 Operating time 0,02 300,0 0,01 (1*) IEC Inverse, IEC Very inverse, IEC Extremely inverse, IEC Long time inverse, Defined time, ANSI Inverse, ANSI Very inverse, ANSI Extremely inverse www.fanox.com Rev. 06 20/99...

  • Page 21: Function. Definite Time Overcurrent

    The function activates at 100% of the pre-set input, and deactivates at 90%. The reset is instantaneous. The accuracy of the operating time is equal to the pre-set time ±30ms or ±0.5% (greater of both). www.fanox.com Rev. 06 21/99...

  • Page 22: 50/51N Function. Inverse Time Neutral

    Group Description Minimum Maximum Step Unit Default Trip block protection for the switchgear Blocking Yes/No Block limit 1,50 20,00 0,01 7,00 www.fanox.com Rev. 06 22/99...

  • Page 23: Function. Thermal Image Protection

    This protection function is adjusted by setting five different parameters: Function Description Minimum Maximum Pitch Unit Default Thermal image protection function Permission Yes/No 0,10 2,40 0,01 ζ heating ζ cooling ζ heating Alarm www.fanox.com Rev. 06 23/99...
  • Page 24 Thermal image protection trip bit is active when the measurement of the thermal image is over 100% and it is reset when the measurement of the thermal image is under the adjusted alarm level. www.fanox.com Rev. 06 24/99...
  • Page 25 5.6.3. Thermal image measurement display. Reset Thermal image measurement can be displayed on Measurement menu. 5.6.4. Thermal protection curves This is the thermal curve for ζ = 3 minutes. www.fanox.com Rev. 06 25/99...

  • Page 26: External Trip

    Any change of set values will restart all functions, irrespective they are activated or not. When the frequency is changed it is necessary to reinitialize the relay twice to ensure that the setting is loaded correctly. www.fanox.com Rev. 06 26/99...

  • Page 27: Settings Groups

    Ext. Inverse Very Inverse 13,5 Inverse 0,14 0,02 The curve can mode from its axis using the D time selection device, which the user can adjust. is the initial operating current, set by the user. adjusted www.fanox.com Rev. 06 27/99...
  • Page 28 Rev. 06 28/99...
  • Page 29 Rev. 06 29/99...
  • Page 30 Rev. 06 30/99...
  • Page 31 Rev. 06 31/99...

  • Page 32: Ansi-Ieee Curves

    Very Inverse 19,61 0,491 Inverse 0,0515 0,02 0,114 The curve can move from its axis using the TD time selection device, which the user can adjust. is the initial operating current, set by the user. adjusted www.fanox.com Rev. 06 32/99...
  • Page 33 Rev. 06 33/99...
  • Page 34 Rev. 06 34/99...
  • Page 35 Rev. 06 35/99...

  • Page 36: Monitoring And Control

    HMI, you have to go to the events menu and press and hold the "RESET" key until the number of events reads 1, and this event is registered as "Events deleted". To delete the events using communications, use the corresponding "delete events" command. To delete the events it is necessary to enter a password. www.fanox.com Rev. 06 36/99...
  • Page 37 Set data/time Local bit-09 Local communication communication bit-10 Factory settings Factory settings bit-11 EEPROM error EEPROM error bit-12 EEPROM changed EEPROM changed bit-13 Events error Events error Bit-15 Reset Reset bit-14 Fault report Fault report record number www.fanox.com Rev. 06 37/99...
  • Page 38 Phase A current bit-09 50 Phase B Trip 50 Phase B Trip Phase B current bit-10 50 Phase C Trip 50 Phase C Trip Phase C current bit-11 50 Phase Trip 50 Phase Trip Maximum current www.fanox.com Rev. 06 38/99...
  • Page 39 Phase C block Phase C block Phase C current bit-03 Phase block Phase block Thermal image bit-04 49 Alarm 49 Alarm Thermal image 49 (*) bit-12 49 Trip 49 Trip Thermal image (*) Optional depending on model www.fanox.com Rev. 06 39/99...

  • Page 40: Fault Reports

    This clock can be synchronized by any of the two following procedures:  From the HMI. In this case the date and time can be entered via the keyboard. The relay will store the new event indicating that it has been synchronized. www.fanox.com Rev. 06 40/99...

  • Page 41: Self-Diagnosis

    On the other hand, “Default settings” means that the equipment is operating under factory settings, being all protection functions disabled. 6.6. Commands By HMI o by communications, depending on model is possible to:  Reset Thermal Image www.fanox.com Rev. 06 41/99...

  • Page 42: Test Menu

    It can also be supplied from a USB cable which goes directly till PC. The USB is plugged into the front communications port. Using USB cable for power supply does not inhibit the USB communications port, as it can be used simultaneously. www.fanox.com Rev. 06 42/99...

  • Page 43: Self-Powered Relay With Specific Current Transformers

    Using battery power does not block the USB communications port, as it can be used simultaneously. When the equipment is being powered from a 5 V battery, it is capable of functioning for 4 hours. www.fanox.com Rev. 06 43/99...

  • Page 44: Opening Mechanism: Striker

    On the other hand, if a higher level that the required by the striker is selected, the activation of the striker is guaranteed, however, the fault trip time during start-up may be increased. Fanox encourages selecting the correct value of this critical setting and offers its expertise at any doubt.
  • Page 45 Level of protection:.......IP-40 Due to the existing variety in the market, it is important to check the voltage and the necessary energy for its activation. Some examples are shown next: If you have any doubt, please contact with Fanox. www.fanox.com Rev. 06...

  • Page 46: Equipment Starting Up Time. Fault Trip Time During Starting Up Of The Equipment

    Next graphics provide different trip curves depending on the fault current and Trip Voltage Levels. In the following image it is shown the result using CT16 but tis result is valid for the rest of the CTs. www.fanox.com Rev. 06 46/99...
  • Page 47 1200 1000 Three Phase 17 Vdc (ms) 730 500 290 240 190 180 180 178 177 177 175 175 Single Phase 17 Vdc (ms) 1000 680 410 305 250 210 190 188 187 187 Current xIS www.fanox.com Rev. 06 47/99...

  • Page 48: Technical Specifications And Standards

    Dial: 0.05 to 1.25 (step 0.01) Curve, activation level 110% Curve, deactivation level 100% Defined time, activation level 100% Defined time, deactivation level 90% Instantaneous deactivation Timing accuracy:± 30 ms or :± 5% (greater of both) www.fanox.com Rev. 06 48/99...
  • Page 49 Blocking: Yes/no Trip Block (*) Blocking limit: 1.5 to 20 x In (step 0.01) Trip output 24 Vdc; 135 mJ (activation of the striker or low powered coil) Frequency 50/60Hz Current measurement True RMS Sampling: 16 samples/cycle www.fanox.com Rev. 06 49/99...

  • Page 50: Thermal Resistance

    Storage temperature: -20 to 80 ºC Humidity: 95% Transformers Power supply and measurement specific CTs Mechanical features Metallic box Panel Mounting ¼ Rack-4U IP-54 panel mounted (*) Optional depending on model 7.2. Thermal resistance  2,5xIsmax: continuously www.fanox.com Rev. 06 50/99...

  • Page 51: Standards

    1.12. 100KHz damped oscillatory IEC 61000-4-18 Class 3, Repetition frequency 40Hz, Duration waves of each application 3s. Common mode: ±2.5kV. Differential mode: ±1kV 1.13. Pulse magnetic fields IEC 61000-4-9 Field strenght 1000 A/m, Cadence between pulses 40s. www.fanox.com Rev. 06 51/99...
  • Page 52 Dry Heat Operation Bb, +70ºC, 72h Dry Heat transport & Storage Bd, +85ºC, 72h 6.3 Change of temperature IEC 60068-2-14 Change of Temperature Nb, Upper temp +70ºC, Lower temp -25ºC, 5 cycles, Exposure time 3h, Transfer time 2 min. www.fanox.com Rev. 06 52/99...
  • Page 53 Declared on manual, without damage for continuous operation 8.4. VT Input short time overload IEC 60255-27 Declared on manual, without damage for 10s short time overloading 9. Enclosure protection 60255-27 IP-54 IEC 60529 Quality Management System ISO 9001:2008 www.fanox.com Rev. 06 53/99...

  • Page 54: Communication And Hmi

    It is possible to verify the correct running of the LEDs via test menu. Apart from these leds, depending on model, SIAB offers a magnetic indicator to signal that a trip has occurred. www.fanox.com Rev. 06 54/99...

  • Page 55: Lcd And Keypad

    Reading and deleting events  Changing the user passwords  Loading settings files  Loading configuration files  Date-time synchronization  Checking the versions of the equipment  Configuring the Modbus address  Configuring and checking the demand www.fanox.com Rev. 06 55/99...

  • Page 56: How To Install Sicom Software

    How to install SICOM Software 8.4.1. To install the SICom it is necessary the following link: http://fanox.blob.core.windows.net/sicom/publish.htm The link will open the next screen, where key “install” must be pressed: The necessary drivers depending on the operative system can be downloaded from this page.

  • Page 57: Setting Up The Session: Password And Access Levels

    SIcom program. It is possible to change the passwords The password must have 4 characters. By default, the equipment is programmed with the following passwords and their associated levels: PASSWORD ACCESS LEVEL 2222 3333 4444 5555 www.fanox.com Rev. 06 57/99...

  • Page 58: Menus

    ▼ are used to increase or decrease the value. If an invalid value is entered during the process, the “C” key can be used to delete it. The navigation through the menus is described as graphically as possible below. www.fanox.com Rev. 06 58/99...

  • Page 59: Date-Time Menu

    The contrast menu can be accessed from the standby mode screen by pressing the “◄” key. Contrast level can be changed using the “▲” and “▼” keys. Press the “C” key to return to the standby mode screen. ◄ Contrast: SIAB00011000AA 0.00 0.00 0.00 0.00 hold www.fanox.com Rev. 06 59/99...

  • Page 60: Fault Report

    From the "sleep" mode screen, press the “◄” key to access the fault report. Use the “▲” and “▼” keys to find the fault report and pressing “OK” the data of this fault report can be read. 50 Trip SIAB00011000AA ◄ 04/11/2013 01:43:25 0.00 0.00 0.00 0.00 04/11/2013 01:43:25000 _I 50 Trip www.fanox.com Rev. 06 60/99...

  • Page 61: Test Menu

    “OK” to access the components that can be tested. TEST MENU y/n? ◄ ▼ ► without protection! OK hold Set Password -> 0 Set Password ◄▼▲► -> 5555 TEST MENU Led1: not activated Led1: <<ACTIVATED>> Led2: ▲▼ not activated www.fanox.com Rev. 06 61/99...
  • Page 62 Led2: <<ACTIVATED>> Trip bistable: ▲▼ not activated Trip bistable: <<ACTIVATED>> Trip Output: ▲▼ not activated Trip Output: <<ACTIVATED>> www.fanox.com Rev. 06 62/99...

  • Page 63: Functions Menu

    Press the “OK” key to access the second level from the main screen. Use the ▲ and ▼ keys to move from one menu section to another in the second level. Use the “C” key to return to a higher level. www.fanox.com Rev. 06...

  • Page 64: Measurements Menu

    0.00 0.00 0.00 0.00 ↓ ↑ MEASUREMENTS = 0.00 A ↓  = 0.00 *A  ▲▼ = 0.00 A ▲▼ = 0.00 A ▲▼ = 0.00 A ▲▼ IMax = 0.00 A ▲▼ = 10 www.fanox.com Rev. 06 64/99...

  • Page 65: States Menu

    Sta. GENERAL ↑ STATES ↓ Trip: Sta. GENERAL not activated External Trip: ▲▼ not activated Error Trip power: ▲▼ not activated 50 Hz: ▲▼ <<ACTIVATED>> Trip Block Enab.: ▲▼ not activated Error Measure: ▲▼ not activated www.fanox.com Rev. 06 65/99...
  • Page 66 Not activated Set Date/Time: ▲▼ not activated Local Act.: ▲▼ not activated Factory Settings: ▲▼ not activated Error Eeprom: ▲▼ not activated Eeprom changed: ▲▼ not activated Error Events: ▲▼ not activated Reset: ▲▼ not activated www.fanox.com Rev. 06 66/99...
  • Page 67 HMI Activity: ▲▼ not activated Reset TI: not activated ↑ STATES Sta. 50 ▲▼ ↓ Phase A Pickup: Sta. 50 not activated Phase B Pickup: ▲▼ not activated Phase C Pickup: ▲▼ not activated www.fanox.com Rev. 06 67/99...
  • Page 68 Phase C Trip: ▲▼ not activated Phase Trip: ▲▼ not activated Sta. 51 ↑ STATES ▲▼ ↓ Phase A Pickup: Sta. 51 not activated Phase B Pickup: ▲▼ not activated Phase C Pickup: ▲▼ not activated www.fanox.com Rev. 06 68/99...
  • Page 69 Phase B Trip: ▲▼ not activated Phase C Trip: ▲▼ not activated Phase Trip: ▲▼ not activated ↑ STATES Sta. 50N ▲▼ ↓ Ground Pickup: Sta. 50N not activated Ground Trip: ▲▼ not activated www.fanox.com Rev. 06 69/99...
  • Page 70 Ground Trip: ▲▼ not activated Sta. INPUTS ↑ STATES ▲▼ ↓ Input 1: Sta. INPUTS not activated Sta. LEDS ↑ STATES ▲▼ ↓ Led 1: Sta. LEDS <<ACTIVATED>> Led 2: ▲▼ not activated Trip bistable not activated www.fanox.com Rev. 06 70/99...
  • Page 71 Phase A Block: Sta. TRIP BLOCK not activated Phase B Block: ▲▼ not activated Phase C Block: ▲▼ not activated Phase Block: ▲▼ not activated Sta. 49 ↑ STATES ▲▼ ↓ Alarm: Sta. 49 not activated www.fanox.com Rev. 06 71/99...

  • Page 72: Settings Menu

    If it is necessary to change one of the password characters or numbers due to an error, press "C" to delete it. Press "OK” to validate the password. The method for navigating through the settings menu and the sequence to follow to change a setting are shown graphically below: www.fanox.com Rev. 06 72/99...
  • Page 73 ↓ ↓ Select table ↑ ▲▼ ↓  GEN Sett(1) 50 SETTINGS ↑ COM  ↓ Function Enable Sett(1) 50 Set Password Function Enable -> 0 Set Password ◄▼▲► -> 5555 Function Enable NO -> NO www.fanox.com Rev. 06 73/99...
  • Page 74 NO > YES y/n SETTING CHANGED Function Enable Function Enable Current Tap ▲▼ 1.00 xIn Operating Time ▲▼ 0.02 s Sett(1) 51 SETTINGS  ↑ ▲▼ COM  ↓ Function Enable Sett(1) 51 Curve type ▲▼ Def Tim www.fanox.com Rev. 06 74/99...
  • Page 75 Sett(1) 50N ↑ SETTINGS ▲▼ COM  ↓ Function Enable Sett(1) 50N Current Tap ▲▼ 1.00 xIn(1.00) Time Delay ▲▼ 0.2 s  Sett(1) 51N SETTINGS ↑ ▲▼ ▲▼ COM  ↓ Sett(1) 51N Function Enable www.fanox.com Rev. 06 75/99...
  • Page 76 Time Delay ▲▼ 0.2 s Sett(1) TRIP BLOCK SETTINGS  ↑ ▲▼ COM  ↓ Function Enable Sett(1) TRIP BLOCK Set Password Function Enable -> 0 Set Password ◄▼▲► -> 5555 Function Enable NO -> NO www.fanox.com Rev. 06 76/99...
  • Page 77 NO > YES y/n SETTING CHANGED Function Enable Function Enable Current Tap ▲▼ 1.00 xIn Time delay 0.20 s  GEN Sett(1) 49 ↑ SETTINGS ▲▼ ↓ Function Enable Sett(1) 49 Current Tap ▲▼ 0.20 xIn www.fanox.com Rev. 06 77/99...
  • Page 78 ▲▼ To access the general settings from the “SETTINGS” menus, press “◄”  GEN Identification ↑ SETTINGS ◄ SIAB text COM  ↓ Frequency ▲▼ 50Hz Serial Number ▲▼ Language ▲▼ ENG. Active Settings Group ▲▼ www.fanox.com Rev. 06 78/99...
  • Page 79 CT type ▲▼ CT008 Password ▲▼ **** ► To access the communication parameters from the “SETTINGS” menus, press “ ” Local COM Address SETTINGS  GEN ↑ ► ↓ COM Identification SIAB Text Frequency ▲▼ 50Hz www.fanox.com Rev. 06 79/99...
  • Page 80 Serial Number ▲▼ Language ▲▼ ENG. Active Settings Group ▲▼ Trip Voltage Level ▲▼ 17 Vdc Nominal current ▲▼ CT type ▲▼ CT008 Password ▲▼ **** www.fanox.com Rev. 06 80/99...

  • Page 81: Events Menu

    There are 5 ↓ Set Password ◄▼▲► -> 5555 Confirm Erased Events y/n? EVENTS ↑ There are 1 ↓ The “┘” and “┐” shows the event has been caused by the activation or reset of the associated state. www.fanox.com Rev. 06 81/99...
  • Page 82 Position of the event within the list of events  Events generated by a state activation or reset  Associated measurement (if it has one) Associated measurement Time Date 01/01/00 00:54:18600 1/99 measurement Events erased Events erased Activated or Not activated Event description www.fanox.com Rev. 06 82/99...

  • Page 83: Commands Menu

    Press the "OK" key to perform a command, and press the "OK" key again to confirm the command. COMMANDS SIAB00001000AA ↑ 0.00 0.00 0.00 0.00 ↓ EXECUTE COMMAND COMMANDS ↑ Reset TI ↓ CONFIRM COMMAND EXECUTE COMMAND Reset TI Reset TI COMMANDS ↑ ↓ www.fanox.com Rev. 06 83/99...

  • Page 84: Fault Reports

    To delete the fault reports, position the cursor over the fault report menu and press and hold the "RESET" key, until password is requested. Introduce the password and press OK until there is a massage informing “fault reports erased”." www.fanox.com Rev. 06...

  • Page 85: Modbus Rtu Protocol

    3 characters. The following table shows the generic package format that is valid for transmission and reception. However, each function has its own peculiarities, as will be described further on. www.fanox.com Rev. 06 85/99...

  • Page 86: Modbus Packaged Format

    The registers are values of Registers 2 bytes of length, transmitted with the most important byte at first. The maximum number of register to be written in a package is 60. www.fanox.com Rev. 06 86/99...

  • Page 87: Exemptions And Error Answers

    Number in floating decimal point “Float” of 4 bytes FLOAT String: Length variable character chain. Final of String marked with ‘\0’. ASCIIxx xx/2 E. g.: “ABC” 0x41x42x43x00..Year(UINT).month(UCHAR).day(UCHAR).hour(UCHAR).minutes(UCHAR).seconds(UCHAR).hu ndredth(UCHAR).thousandth(UINT) EVENT2 Criteria Directory(UINT).Event Identifier(UINT).Value(UINT).Associated Measure(float).Date and Time(FH) EVENTO2 Antiquity(UINT).Event(EVENT2) www.fanox.com Rev. 06 87/99...

  • Page 88: Memory Map Of Sia-B

    Memory map of SIA-B Numb Start Function Description Format address regist ries Write Directory UINT Event Write the number of the UNIT Setting List Read of Model and Version ASCII88 Write access code UCHAR4 See Passwords and Access Levels www.fanox.com Rev. 06 88/99...
  • Page 89 Trip blocking function map State reading BIT32 49 function map 03 y 16 Setting ASCII20 Equipment identifier Setting DENUM 5060Hz Frequency Setting LONG Serial number 03 y 16 Setting DENUM LANGUAGE Language 03 y 16 Setting LONG Active group www.fanox.com Rev. 06 89/99...
  • Page 90 F49 cooling constant 03 y 16 Setting LONG F49 Alarm 03 y 16 Setting DENUM NOSI Blocking trip permission 03 y 16 Setting FLOAT Blocking trip tap Confirm setting Equipment identifier Confirm setting Frequency Confirm setting Serial number www.fanox.com Rev. 06 90/99...
  • Page 91 Confirm setting F50/51N Definite time Confirm setting F49 Permission Confirm setting F49 Tap Confirm setting F49 Heating constant Confirm setting F49 cooling constant Confirm setting F49 Alarm Confirm setting Blocking trip permission Confirm setting Blocking trip tap www.fanox.com Rev. 06 91/99...

  • Page 92: Commands Map

    Number of bytes Password 35,35,35,35 Checksum H Checksum L And SIAB respond OK: Address Function H start address L start address Number of H registers Number of L registers Number of bytes Checksum H Checksum L www.fanox.com Rev. 06 92/99...

  • Page 93: Commissioning

    To perform this test, connect a PC with the SICom software program to the SIA-B relay, and check that there are no communication errors. It is important to check communications port (COM) which is assign to USB. www.fanox.com Rev. 06 93/99...

  • Page 94: Commissioning

     FANOX recommends the use of the KITCOM accessory with a battery in the front port. This additional energy source allows the relay to be monitored and the trip to function without the need for self-power in any breakdown situation.

  • Page 95: Appendix

    Box earth:  Vaux value: 11.3. Test menu   On LED: Trip Output  Alarm LED:  Trip indicator: 11.4. Register of commissioning settings Password: …………………………………………………………………………… Identification: ………………………………………………………………………… Voltage level:…………………………………………………………………………………..CT type: ……………………..……………………………………………………………. Nominal current: ……………………..…………………………………………………… www.fanox.com Rev. 06 95/99...
  • Page 96  Ext. Inverse Def. Time Dial……....………… Operating Time…..…..……..s  Enabled  Disabled Permission Tap……..………………………… x In ζ heating: …………………………. min ζ cooling: …………………………. ζ heating Alarm: …………………………. Trip block  Enabled  Disabled Permission Blocking level.....………… x In www.fanox.com Rev. 06 96/99...

  • Page 97: Comments

    11.5. Comments …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… ……………....……………………………………………………………………………..…. …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… …………….....……………………………………………………………………………..… Person in charge of commissioning………..……..…………..Date……….....… Maintenance performed on the………………….. by ………..………………………………….. www.fanox.com Rev. 06 97/99...
  • Page 98 NOTES: ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… ……………………………………………………………………………………………………..… www.fanox.com Rev. 06 98/99...
  • Page 99 Rev. 06 99/99...
