INSTALLATION GUIDE
AND USERS MANUAL
Professional Wall-Mount Range Hood
www.victoryrangehoods.com
NOTICE:
For residential use only.
Installer: Leave this guide with the homeowner.
Homeowner: Keep this guide for future reference.
PSD
Model:
Sizes:
30", 36", 42"
VEGA
Model:
Sizes:
30", 36", 42"
MAESTRO
Model:
30", 36", 42"
Sizes:
rev.20220622
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Victory PSD
Summary of Contents for Victory PSD
- Page 1 INSTALLATION GUIDE AND USERS MANUAL Professional Wall-Mount Range Hood Model: Sizes: 30”, 36”, 42” VEGA Model: Sizes: 30”, 36”, 42” MAESTRO Model: 30”, 36”, 42” Sizes: NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference. www.victoryrangehoods.com rev.20220622...
-
Page 2: Table Of Contents
Specifications................... 7 Required Tools.................. 8 Parts Supplied................... 8 Dimensions..................11 Preparation..................14 Rough-In.................... 15 Installation..................16 Glass Installation (PSD model only)..........19 Grease Tunnel and Filters..............20 Venting Methods................21 Range Hood Operations..............22 Wiring Diagram................. 23 Troubleshooting................24 Maintenance..................25 Bulb Replacement................ -
Page 3: Important Safety Notice
Use high settings on cooking range only when necessary. • Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. VICTORY range hoods PSD / VEGA / MAESTRO... - Page 4 The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. VICTORY range hoods | PSD / VEGA / MAESTRO...
-
Page 5: Electrical Requirements
(at the range hood and at the junction box). Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 VICTORY range hoods PSD / VEGA / MAESTRO... -
Page 6: Venting Requiremens
If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood mounting height above range. Minimum Duct Size: • Round - 6” * Due to different ceiling height configurations, recommended height may not be applicable. VICTORY range hoods | PSD / VEGA / MAESTRO... -
Page 7: Calculating Duct System Length
2 x 35W GU10 Halogen, 120V (12V LED Optional) Ducting Size Top 6” Round Warranty 1 YEAR ( parts warranty ) * Subject to change without notice, please contact your local reseller for details. VICTORY range hoods PSD / VEGA / MAESTRO... -
Page 8: Required Tools
Inner Ring Light Key Allen Key (used to gain access to your light housing to (used for PSD model only when replace the Halogen GU10 bulb should your installing the glass cover onto range hood come installed with them. Please refer the range hood.) - Page 9 PARTS SUPPLIED (PSD) Upper Chimney Lower Chimney Duct Adapter Plastic Flaps Grease Tunnel Baffle Filters (x2) Glass Cover WALL MOUNT RANGE HOOD VICTORY range hoods PSD / VEGA / MAESTRO...
- Page 10 Chimney Duct Lower Adapter Chimney Plastic Flaps Ø - 6” Transition Grease Tunnel Baffle Filters (amount may vary dependent on model) VEGA WALL MOUNT RANGE HOOD MAESTRO WALL MOUNT RANGE HOOD VICTORY range hoods | PSD / VEGA / MAESTRO...
-
Page 11: Dimensions
Available Glass Sizes: 29 ½”, 35 ½”, 41 ½” FRONT VIEW SIDE 13” 12 ⅜” VIEW Chimney height adjustable from 23” to 40” 12 ½” 10 ¹⁄8” 3 ¹⁄8” 4 ⁵⁄8” 19 ¾” 20 ¼” BOTTOM VIEW VICTORY range hoods PSD / VEGA / MAESTRO | 11... - Page 12 Available Sizes: 29 ½”, 35 ½”, 41 ½” FRONT VIEW SIDE VIEW 12 ¾” 11 ⅜” Chimney height adjustable from 23” to 39 ½” 12 ½” 10 ¼” 1 ¾” 19 ¾” BOTTOM VIEW VICTORY range hoods | PSD / VEGA / MAESTRO...
- Page 13 Available Sizes: 29 ½”, 35 ½”, 41 ½” FRONT VIEW SIDE VIEW 12 ¾” 11 ⅜” Chimney height adjustable from 23” to 39 ½” 12 ½” 10 ¼” 4” 19 ¾” BOTTOM VIEW VICTORY range hoods PSD / VEGA / MAESTRO | 13...
-
Page 14: Preparation
2. Set aside the stainless steel baffle filters and grease tunnel until the range hood is properly installed. IMPORTANT NOTE: All PSD, VEGA and MAESTRO models have similar Pre-Install and Installations. For demonstrative purposes, this manual will be using the VEGA model as example. -
Page 15: Rough-In
Install area for metal bracket *Due to different ceiling height configurations, *Due to different ceiling height configurations, which holds up the chimney recommended height may not be applicable. recommended height may not be applicable. VICTORY range hoods PSD / VEGA / MAESTRO | 15... -
Page 16: Installation
For safety purpose, pre-drilled mounting holes are provided through the back of the hood. For a more secure installation, use as many mounting holes as needed to secure from the inside of hood. VICTORY range hoods | PSD / VEGA / MAESTRO... - Page 17 Before connecting wires, switch power off at service panel and lock service panel to preduct power from being switched on accidentally. VICTORY range hoods PSD / VEGA / MAESTRO | 17...
- Page 18 To avoid scratching the chimney, extend the upper should be able to slide into the gap of the top housing. chimney slowly and carefully to the chimney-mounting bracket and tighten screws. VICTORY range hoods | PSD / VEGA / MAESTRO...
-
Page 19: Glass Installation (Psd Model Only)
(1) For the PSD Model, there is a glass cover included. Your range hood housing will have 4 hexagon screws with countersink washers and plastic sleeves. They are partially screwed on the main housing, and you will need to remove them prior to the placement of the glass cover using the Allen Key included. -
Page 20: Grease Tunnel And Filters
Lift front end of the filter and into slot holding, as shown below. insert into the opening above the front light panel. SIDE VIEW Lower back end of the filter until it rests onto Grease Tunnel. VICTORY range hoods | PSD / VEGA / MAESTRO... -
Page 21: Venting Methods
Use a smooth elbows. Use 45 degrees reducer will reduce the CFM of elbow to guide the air outdoors. instead, if possible. the hood and increase the noise. VICTORY range hoods PSD / VEGA / MAESTRO | 21... -
Page 22: Range Hood Operations
Press Power button once to turn off the system. Note: The system saves user configurations, settings such as light, timer and blower (motor) speed will remain the same the next time it is turned on. VICTORY range hoods | PSD / VEGA / MAESTRO... -
Page 23: Wiring Diagram
White 110V AC-N White MO-n Blue MO-1 (FAN1) Yellow Pink MO-2 (FAN2) Capacitor MO-3 (FAN3) Orange MO-4 Yellow (FAN4) Purple MO-5 (FAN5) Brown MO-6 (FAN6) Black LAMP-L LIGHTS White LAMP-N VICTORY range hoods PSD / VEGA / MAESTRO | 23... -
Page 24: Troubleshooting
NO reducers or plenums in the duct work. • Refer to Duct Venting in the Venting Methods page for illustrative examples. NOTE: For all other inquiries, please contact Victory Range Hoods. VICTORY range hoods | PSD / VEGA / MAESTRO... -
Page 25: Maintenance
Dry filters and re-install before using hood. Replacing Filters: • Should filters wear out due to age and prolonged use, please contact Victory Range Hoods to order • Note: Also replace damaged filter that has punctured or broken mesh, bent or broken frame. -
Page 26: Bulb Replacement
7. Turn ON breaker and range hood to test for operation. Light Housing Power Plug Hood Panel Flat-head Screwdriver Metal Clip NOTE: For all other inquiries, please contact Victory Range Hoods. VICTORY range hoods | PSD / VEGA / MAESTRO... -
Page 27: Warranty
Victory Range Hoods. The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. VICTORY range hoods... -
Page 28: Disclaimer
583 Nicola Avenue, Port Coquitam, BC, Canada Toll Free: 1-800-394-4020 info@victoryrangehoods.com The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. VICTORY range hoods | PSD / VEGA / MAESTRO... - Page 29 NOTES VICTORY range hoods PSD / VEGA / MAESTRO | 29...
- Page 30 583 Nicola Avenue | Port Coquitlam | BC | Canada | V3B 0M3 www.victoryrangehoods.com...
