Installation Guide
and Users Manual
VICTORY
Professional Range Hood
Model number: PSD/F/L/Z
available size: 30", 36", 42"
IMPORTANT:
Read and save these instructions.
NOTICE:
Installer: Leave this guide with the homeowner
Homeowner: Keep this guide for future reference
Wall Mount Range Hood
Rev. 3046u.6a
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Victory PSD
Summary of Contents for Victory PSD
- Page 1 Installation Guide and Users Manual VICTORY Professional Range Hood Model number: PSD/F/L/Z available size: 30”, 36”, 42” IMPORTANT: Read and save these instructions. NOTICE: Installer: Leave this guide with the homeowner Homeowner: Keep this guide for future reference Wall Mount Range Hood...
-
Page 2: Important Safety Notice
Important Safety Notice Read all Instructions before Installing and operating this appliance • The installation in this manual is intended for qualified installers, service technicians or persons with similar qualified background. Installation and electrical wiring must be done by qualified profession- als and in accordance with all applicable codes and standards, including fire-rated construction. -
Page 3: Table Of Contents
Important Safety Notice Table of Contents Read all Instructions before Installing and operating this appliance INSTALLATION USE AND CARE Tools needed............3 Troubleshooting...........17 • Clean ventilating fan frequently. Parts supplied...........4 Use and care information.......18 • Always use appropriate cookware and utensils size. Venting requirements........5 Specifications..........18 •... -
Page 4: Parts Supplied
Parts supplied: Venting Requirements Height & Clearance Range Hood (vary with model) • Vent system must terminate to the outside Mounting (roof or side wall). Maximum* ceil- Bracket • DO NOT terminate the vent system in an at- ing clearance Standard 110”... -
Page 5: Venting Methods
Venting Methods IMPORTANT: • A minimum of 6” round (standard for this range hood) or 3-1/4 x 10” rectangular duct (purchased separately) • This range hood is factory set for venting through the roof or wall. For non-vented (re-circulating) installa- must be used to maintain maximum airflow efficiency. -
Page 6: Preparation
Charcoal Filter Installation Preparation NOTE: The charcoal filters are preinstalled if you purchased the range hood with re-circulating kit from us. Advanced Preparations: 1. Remove stainless steel baffle filters on hood. 1. Read the entire installation guide and users manual thoroughly, understand instructions and warnings. 2. -
Page 7: Installation
Installation Installation (Continued) Figure 1 Installations (refer to Page 4 for parts): Measure the distance between stove top and the bottom of 6. Store excess wires in the wiring box. range hood. A distance of 28” to 31” is recommended*. 7. -
Page 8: Range Hood Operations
Range Hood Operations Range Hood Operations (Continued) Power Light Power Light Power-Off Delay Power-Off Delay Increase Value Increase Value Decrease Value Power-Off Delay Digital Timer Decrease Value Power-Off Delay Digital Timer Blower Speed Indicator Cleaning Reminder Indicator Blower Speed Indicator Cleaning Reminder Indicator •...
