- Page 1 INSTALLATION GUIDE AND USERS MANUAL NOTICE: For residential use only. Installer: Leave this guide with the homeowner. Homeowner: Keep this guide for future reference. Professional Island Range Hood Model Name: PLANE-ISLAND 30”, 36”, 42”, 48” Available Sizes: Rev. 3062u.3a...
-
Page 2: Table Of Contents
Installation..................18 Venting Methods................23 Filter Installation................24 Range Hood Operations..............25 Wiring Diagram................. 27 Troubleshooting................28 Use and Care Information..............29 Maintenance..................30 Bulb Replacement................31 Warranty..................... 32 Disclaimer..................33 Contact Us..................33 VICTORY range hoods | PLANE ISLAND... -
Page 3: Important Safety Notice
Use high settings on cooking range only when necessary. • Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. VICTORY range hoods PLANE ISLAND... - Page 4 The manufacturer and/or distributor/reseller will not be held responsible for any damages to personal property or real estate or any bodily injuries whether caused directly or indirectly by the range hood. VICTORY range hoods | PLANE ISLAND...
-
Page 5: Electrical Requirements
(at the range hood and at the junction box). Copies of the standards listed may be obtained from: * National Fire Protection Association Batterymarch Park Quincy, Massachusetts 02269 ** CSA International 8501 East Pleasant Valley Road Cleveland, Ohio 44131-5575 VICTORY range hoods PLANE ISLAND... -
Page 6: Venting Requiremens
Minimum Duct Size: • Round - 6” for Models 30, 36, 42 • Round - 8” or 10” for Model 48 * Due to different ceiling height configurations, recommended height may not be applicable. VICTORY range hoods | PLANE ISLAND... -
Page 7: Calculating Duct System Length
3W) 120V, Dimmable Ducting Size Top, 6” Round (Models 30, 36, 42) 8” or 10” (Model 48) Warranty 1 YEAR (parts warranty) * Subject to change without notice, please contact your local reseller for details. VICTORY range hoods PLANE ISLAND... -
Page 8: Required Tools
REQUIRED TOOLS Marker or Pencil Putty Knife Tape Measure Phillips Screwdriver Level Power Drill Aluminum Tape Utility Knife Drywall Knife VICTORY range hoods | PLANE ISLAND... -
Page 9: Parts Supplied
PARTS SUPPLIED Screws included to assemble this Range Hood model. NOTE: Where necessary, additional screws will be needed for installation and added support, but is not included. Please review contents before installation. VICTORY range hoods PLANE ISLAND... - Page 10 Ø - 10” Transition 6”- Ø Transition (optional for Model 48 only) (Models 30, 36, 42 only) Inner Ring Light Key (used to gain access to your light housing to replace bulb) Range Hood (Model 42 shown) VICTORY range hoods | PLANE ISLAND...
-
Page 11: Dimensions
23 ¾” Available Sizes: 29 ½”, 35 ½”, 41 ½” FRONT SIDE VIEW VIEW 11 ¼” 13 ½” 26” to 40” 12 ¼” 8 ¾” 10 ⅜” 12 ½” 2 ¾” BOTTOM VIEW VICTORY range hoods PLANE ISLAND | 11... - Page 12 DIMENSIONS ( Continued ) 26” to 40” 2 ¾” 12 ¼” 13 ½” 11 ¼” 23 ¾” Model 29 ½” 35 ½” 41 ½” VICTORY range hoods | PLANE ISLAND...
- Page 13 TOP VIEW Ø 8” Transition Ø 10” Transition (optional) 27” 47 ½” SIDE FRONT VIEW VIEW 22” to 40” 21 ½” 13 ¼” 12 ½” 8 ¾” 12 ¾” 21” 2 ¾” BOTTOM VIEW VICTORY range hoods PLANE ISLAND | 13...
- Page 14 DIMENSIONS ( Continued ) 26” to 40” 2 ¾” 12 ½” 21 ½” 13 ¼” 47 ½” 27” Model 48 VICTORY range hoods | PLANE ISLAND...
-
Page 15: Preparation
12” of electrical cord hanging from the ceiling. Do not restore power until wiring is completed. 7. Disconnect power cord, remove the stainless steel baffle filter and grease tunnel. 8. Set aside the stainless steel baffle filters and grease tunnel until the range hood is properly installed. VICTORY range hoods PLANE ISLAND | 15... -
Page 16: Pre-Installation
(3) Thread the electrical outlet and duct through the (4) Screw the frame onto the drywall where the wood main frame of the range hood support braces are which will provide support. VICTORY range hoods | PLANE ISLAND... - Page 17 (woodscrews not included). (3) Thread the electrical outlet and duct through the (4) Screw the frame onto the drywall where the wood main frame of the range hood support braces are which will provide support. VICTORY range hoods PLANE ISLAND | 17...
-
Page 18: Installation
Due to the difference in larger dimensions of Model 48, please take into account that there are some added or ommitted components, as well as the instructions will vary. Please refer to Parts Supplied to confirm your application prior to assembly and installation. VICTORY range hoods | PLANE ISLAND... - Page 19 (3) Attach a flex duct (not included) to the extension. (4) Use aluminum foil tape to secure a proper seal. VICTORY range hoods PLANE ISLAND | 19...
- Page 20 (7) Fasten arm extensions to the brackets with a (8) Slip on the chimney sleeve over the arm screw on each side of each bracket with locking nut. extensions while ensuring the power cord also slips through the sleeves. VICTORY range hoods | PLANE ISLAND...
- Page 21 NOTE: Use a stable platform to rest the range hood and/or receive assistance to hold on range hood. Connect the flex duct from the range hood to the ducting in the ceiling. Use aluminum foil tape to secure a proper seal. VICTORY range hoods PLANE ISLAND | 21...
- Page 22 (12) Lift the inner sleeve of the chimney, and raise plugging in to outlet. Check the fan motor and to the main frame. Fasten screws to each of the lights are functioning. hole openings and ensure a secure fit. VICTORY range hoods | PLANE ISLAND...
-
Page 23: Venting Methods
Colder climates require wrapping 96” insulation around the ducts and *Max: 108” optional blowers. • The system must have a Backdraft Damper. * Due to different ceiling height configurations, recommended height may not be applicable. VICTORY range hoods PLANE ISLAND | 23... -
Page 24: Filter Installation
While continuing to install the filter, ensure you lift the lever Lift Lever for the retractable tabs to clear way for flush insertion. When filter sits flush within the opening, release the lever Tab Inserts to lock in place. VICTORY range hoods | PLANE ISLAND... -
Page 25: Range Hood Operations
Press Power button once to turn off the system. Note: The system saves user configurations, settings such as light, timer and blower (motor) speed will remain the same the next time it is turned on. VICTORY range hoods PLANE ISLAND | 25... - Page 26 Note: Light settings are independent from other settings (including power-off delay) and lights has to be manually turned off. Note: The system saves user configurations, settings such as light, timer and blower (motor) speed will remain the same the next time it is turned on. VICTORY range hoods | PLANE ISLAND...
-
Page 27: Wiring Diagram
Black 110V AC-L White 110V AC-N White MO-n Blue MO-1 (FAN1) Yellow Pink MO-2 (FAN2) Capacitor MO-3 (FAN3) Orange Yellow MO-4 (FAN4) Purple MO-5 (FAN5) Brown MO-6 (FAN6) Black LAMP-L LIGHTS White LAMP-N VICTORY range hoods PLANE ISLAND | 27... -
Page 28: Troubleshooting
Check if all joints are properly con- nected, sealed, and taped. • Make sure the power is on high speed for heavy cooking. NOTE: For all other inquiries, please contact Victory Range Hoods. VICTORY range hoods | PLANE ISLAND... -
Page 29: Use And Care Information
DO NOT operate blowers when filters are removed. Never disassemble parts to clean without proper instructions. Disassembly is recommended to be performed by qualified personnel only. Read and understand all instructions and warnings in this manual before proceeding. VICTORY range hoods PLANE ISLAND | 29... -
Page 30: Maintenance
Dry the filters and re-install before using the hood. Replacing Filters: • Should filters wear out due to age and prolonged use, please contact Victory Range Hoods to order replacement filters. VICTORY range hoods... -
Page 31: Bulb Replacement
The inner ring will loosen and the light bulb will be available for removal as shown in Figure (2) • Install a new light bulb and reverse the steps • Turn ON breaker and range hood to test for operation. Figure (1) Figure (2) VICTORY range hoods PLANE ISLAND | 31... -
Page 32: Warranty
Victory Range Hoods. The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. VICTORY range hoods... -
Page 33: Disclaimer
Toll Free: 1-800-394-4020 info@kitchenhoods.ca The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details. VICTORY range hoods PLANE ISLAND | 33... - Page 34 583 Nicola Avenue | Port Coquitlam | BC | Canada | V3B 0M3 www.kitchenhoods.ca...
