Mid-Line Control Units are available for the Model C2 Plus & G Plus Feeders. The Mid-Line Controls are shown
in Figure 43.
Model C2 Plus Mid-Line Control with
Sensor Plus Proximity Switch
Model C2 Plus Mid-Line Control with
Mechanical Switch and Windows
28
CHORE-TIME EQUIPMENT
A DIVISION OF CTB INC.
MILFORD, INDIANA 46542-2000
42663 MODEL C2 PLUS
INTERMEDIATE CONTROL
WITH PROXIMITY SWITCH
2529-711
DANGER
ELECTROCUTION HAZARD!
Do not open this control
box until electrical power is
disconnected at circuit breakers.
1255-66 6/01
1255-33 3/1998
Figure 43. Mid-Line Controls
