Processing of Measurements saved in the Cloud area

Association after execution of measurements
This procedure allows you to associate the measurements saved in the Cloud area to a Door/Customer, at a later time after
execution. (The following graphical representation shows the use with a PC, however, the operation can also be done with
mobile devices).
1) From the Home page, select Doors Management. Doors management contains all the saved doors (it is possible to filter
only for doors associated with a customer from the Filter by Customer menu). If there are no doors available, you can create
a new one by selecting Add Door.
1
2
2) By selecting an available door (e.g. sliding gate) you access the section
dedicated to the Technical File, where you can create the documents
required for the Conformity of automatic doors, e.g.: Maintenance Log,
Risk Analysis, Forces Limitation, EC Declaration, etc.
3) Then select Forces Limitation to access the next menu (which also
allows you to check/add/edit data of the Customer and of the Door).
4) Next, select Force Measurements Association to access the page
describing the door (with graphical representation and reference points).
Select Add test on a measurement point to start associating
3
measurements.
4
N.B. The pictures show all the measurement
points required by the reference Standards. In
view of the many variants of automatic doors, it is
not always possible to carry out all the
measurements required by the Standards.
Therefore only the actual measurements
available in the Cloud area should be associated.
