Test Measurement

After the turn-on phase, move to the first available memory location (e.g., No. 1).

With the instrument in place, apply force with your hand for about one second, then release.

The instrument detects the crushing force above the minimum threshold, then starts the measurement

acquisition for 6 sec. The display shows the location number and the letter "A" followed by three dashes.

N.B. if the Point function is activated (see page 8) the instrument asks you to enter the measurement point.

At the end of the acquisition, the display shows only the location number together with a short

scrolling sequence of dots indicating that the measurement has been saved and that simultaneously

the acquired parameters have been transmitted to the BlueForce Cloud portal. To make a new

measurement, briefly press the left button.

These are the parameters saved inside the instrument and sent to the Cloud area:

Fd: Maximum amplitude of force peak (N)

Td: Force peak duration (s)

Fs: Average value of the static force (N)

Fe: Value of the final force, 5 seconds after initial contact (N)

Date and time (in standard format)

GPS position (geographical address and point on map)

Instrument position (horizontal or vertical)

Reference number of the measurement (indicated in the Quick Start Guide, see Point setting on p. 8)

BlueForce Cloud Area

Each measurement taken is immediately sent and saved in the BlueForce Cloud area, to be viewed online on mobile devices

(see pages 9 and 10). You can then use the measurements and their parameters to create customised print reports (see pages

11 and 12), but not only, the Cloud area also allows you to draw up all the documentation relating to the conformity of motorised

doors and gates, such as: the risk analysis, the EC declaration of conformity, the maintenance log and the acceptance and

testing reports.
