Akuvox E12 Quick Manual

Hide thumbs Also See for E12:

Advertisement

Table of Contents

Before you being using the device, please check the version you obtained
and ensure that the following items are included in the shipped box:

Universal Accessories:

E12 x 1

Wall mounting

bracket x 1
ST4x20 screw x 4
Torx screw x 2
Plastic Wall Anchor x 4
Back cover x 1
7-pin cable x 1
Wall-mounting template x 1
E12
M3x4 screw x 4
Torx Wrench x 1
6-pin cable x 1
Diode
x
1
Mic
Photosensitive sensor
Camera
RF card reader
Call button
E12
