Hardware Installation
Turntable connection
STEP
03
1.Connect the turntable connection cable ⑤ into the
turntable USB port ①.
2.Connect the turntable connection cable ④ into computer
USB port.
3.Connect the turntable power cable ③ into the turntable
port ②.
2
4.Plugin the power adapter to power source.
Lightbox connection (optional)
1. Connect the scanner lightbox cable
cable .
1
2. Connect the scanner lightbox cable
connection cable
3. Connect the scanner lightbox cable
interface shown on the back of the scanner.
1
4
3
2
Note：
1. The lightbox switch is used in conjunction with the lightbox switch button in
the software white balance interface.
2. Make sure both the lightbox switch are on for white balance testing and
texture project scanning.
3. After creating a new project in the scanning interface, when selecting the
texture project, it will prompt the status of the lightbox in the current texture
scanning state, please choose whether to access the lightbox according to
the prompt information.
4. Whether to open the lightbox while scanning, depends on whether open the
lightbox while doing the white balance test.
5. Make sure the light box connection cable is connected in the correct order,
and the ports connected to each lamp are connected to one-to-four adapter
cable.
1
4
2
1
5
.
4
5
5
4
3
3
to the lightbox power
2
to the one-to-four
3
to the LAMP
5
LAMP
