04/2022 MN048028EN
Manual
XP-504
Manual

Advertisement

Table of Contents
loading

Related Manuals for Eaton XP-504-10-A10-A01-2B

Summary of Contents for Eaton XP-504-10-A10-A01-2B

  • Page 1 04/2022 MN048028EN Manual XP-504 Manual...
  • Page 2 No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, micro-filming, record- ing, or otherwise, without the prior written permission of Eaton Industries GmbH, Bonn. Subject to alteration.
  • Page 3 DANGER! Hazardous electrical voltage! Before starting with the installation Installation requires qualified electrician desktop devices and portable devices only when the housing is closed. Disconnect the power supply of the device. Measures should be taken to ensure the proper Secure against retriggering restarting of programs interrupted after a voltage Verify isolation from the supply dip or outage.
  • Page 5 What the different parts of the part number mean Accessory devices Support Conditions for Underwriters Laboratories Inc. (UL) listing 1.7.1 Panel-PC 1.7.2 Terminal 1.7.3 Terminal with Extender RX Conditions for Underwriters Laboratories Inc. (UL) listing in haz- ardous locations - UL-EX XP-504 04/2022 MN048028EN Eaton.com...

  • Page 6: Table Of Contents

    Mounting position Unpacking and checking the equipment supplied Mounting 3.4.1 Panel-PC, Terminal and Terminal with Extender RX 3.4.1.1 Preparations 3.4.1.2 Installing the Panel-PC and Terminals 3.4.2 Box-PC 3.4.2.1 Rail mounting 3.4.2.2 Mounting wall 3.4.3 Extender TX XP-504 04/2022 MN048028EN Eaton.com...
  • Page 7 4.3.2 USB-B 4.3.3 Mini USB-B Ethernet Display interfaces 4.5.1 DisplayPort (DP) 4.5.2 High Definition Multimedia Interface (HDMI) Serial interfaces RS232/RS422/RS485 DVI-I Commissioning Initial commissioning 5.1.1 Connecting peripheral devices Running the XP-504 Operation Touch display Safety Instructions XP-504 04/2022 MN048028EN Eaton.com...
  • Page 8 Modifying an Account Name or Password 7.2.6 Device start without user login dialog box 7.2.7 License Eaton Galileo-Open Runtime 7.2.8 License Eaton Visual Designer Runtime 7.2.9 Enabling / disabling IIS communication for Visual Designer 7.2.10 Enabling / disabling the automatic screen lock Faults...
  • Page 9 A.1.2.8 XP-504-10-...Terminal with Extender RX A.1.2.9 XP-504-15-...Terminal with Extender RX A.1.2.10 XP-504-21-...Terminal with Extender RX A.1.2.11 XP-504-EXT module A.1.3 General data A.1.4 Information on the power supply A.1.5 Approvals and declarations Further usage information Alphabetical index XP-504 04/2022 MN048028EN Eaton.com...
  • Page 10 The following significant amendments have been introduced since previous issues: Publication Page Keyword New Modification Deleted date 09/2021 New edition, panel-PC, CE, UKCA ✓ 01/2022 Panel-PC, UL approval ✓ 04/2022 Device series expanded with box PC, ✓ extender module, terminal, and terminal with extender XP-504 04/2022 MN048028EN Eaton.com...
  • Page 11 Incomplete documents Working with individual pages taken out from the information for use may lead to bodily injury and property damage due to failure to observe relevant safety information. Always work with the latest and full document. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 12 Hazards posed by the XP-504 cannot be eliminated if the safety instructions are not observed – especially if the XP-504 is installed and commissioned by unqualified per- sonnel and/or is used improperly. Eaton assumes no liability for any damages resul- ting from cases such as these.
  • Page 13 Dangerous Electrical Voltage! CAUTION Warns of the possibility of hazardous situations that can cause injury. Property damage warning CAUTION Warns about the possibility of material damage. Prohibited uses, actions, etc. Explains the prohibition Explains the instruction XP-504 04/2022 MN048028EN Eaton.com...
  • Page 14 Documents (such as manuals) are listed after the icon together with the cor- responding name and Eaton number. Publication title For identifying the Eaton publication code External Internet addresses. They will be shown after the icon. Destination address XP-504 04/2022 MN048028EN Eaton.com...
  • Page 15 USB data receiver The II 3D Ex tc IIIC T70°C U ATEX certification applies to devices with a Widescreen terminal: Panel-PCs, Terminals, and Terminal with Extender RX. Panel-PC Box-PC Extender TX Terminal Terminal with Extender RX XP-504 04/2022 MN048028EN Eaton.com...
  • Page 16 When choosing devices, it is necessary to take into account the distances between the devices and the connections between them. An Extender TX module needs to be used for distances greater than 1.8 m. Fig. 3: Device concept overview XP-504 04/2022 MN048028EN Eaton.com...
  • Page 17 2 x Ethernet ports (1000/100/10 Mbps Ethernet / GbE-Ethernet) for use as a communication or field bus interface 4x USB 3.0 One RS232/RS422/RS485 (COM) port for communicating with PLCs or devi- ces, 1x DisplayPort 1x HDMI XP-504 04/2022 MN048028EN Eaton.com...
  • Page 18 Screen mode: 16:9, visible screen area 344.23 mm x 193.54 mm, 1366 x 768 px XP-504-21-... - Screen diagonal 21.5" (54.6 cm), Screen mode: 16:9, visible screen area 476.06 mm x 276.79 mm, 1920 x 1080 px Fig. 4: Display size comparison XP-504 04/2022 MN048028EN Eaton.com...
  • Page 19 1 x RJ45 (Extender 1 x RJ45 (Extender TX), 4 x USB3.0, touch functionality) 1 x Mini USB-B, 1 x DVI-I, 1 x DP RS232/RS422/485, 1 x DP 1 x HDMI, 1 x DP, Slot for SD card XP-504 04/2022 MN048028EN Eaton.com...
  • Page 20 Type approval and certification marks and information Layout of interfaces To get fast and effective support, make sure to always provide Customer Service with the following information from the nameplate: Article No. (part No. or article No.) Serial No. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 21 Windows 10 Enterprise LTSC, runtime license for Visual Designer visualization software Terminal, Terminal with Extender RX XP-504 - Display size (screen diagonal) - Type 10.1" (25.65 cm) TERMINAL Terminal 15.6" (39.6 cm) TERMINAL-EXT Terminal with Extender RX 21.5" (54.6 cm) Extender TX transmitter module XP-504 04/2022 MN048028EN Eaton.com...
  • Page 22 1. Description 1.4 What the different parts of the part number mean XP-504 - Type Series EXT-MODUL XP-504 04/2022 MN048028EN Eaton.com...
  • Page 23 1.5 Accessory devices A variety of accessories are available for XP-504 devices. CAUTION Only use original accessories. Order accessories through your supplier or through the Eaton online catalog Eaton.com/ecat 1.6 Support To get fast and effective support, make sure to provide Customer Service with the fol- lowing information from the nameplate: Part-No.
  • Page 24 Permissible voltage range -15%/+20% of rated operating voltage 24 V Type rating Use in type 4X or type 12 enclosures, use indoors only, at dry locations only IPxx not evaluated by UL Ambient temperature 0°C to 45°C XP-504 04/2022 MN048028EN Eaton.com...
  • Page 25 50% at 40 °C. The torque used to tighten the screw terminals on the plug-in connection for the sup- ply voltage must not exceed 0.5 - 0.6 Nm (4.4 -5.3 lb-in). XP-504 04/2022 MN048028EN Eaton.com...
  • Page 26 EXPLOSION HAZARD LITHIUM BATTERY The lithium battery inside the Panel-PC may explode if handled incor- rectly. Batteries must only be changed in an area known to be non- hazardous. Dispose of the XP-504 unit professionally. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 27: Use In Hazardous Locations - Atex

    45°C. The environment has to be designed to avoid any bunch discharge. For safe instal- lation, comply with the specification to holding brackets and tightening torque in the respective Instruction leaflet for the device. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 28: Marine Approvals

    1. Description 1.10 Marine approvals 1.10 Marine approvals An application for approval for the XP-504 has been submitted to Det Norske Veritas. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 29: Safety Regulations

    The personnel responsible for installation, operation, maintenance, and repairs must have the necessary qualifications for the work they will be performing. They must be appropriately trained and/or briefed and be informed of all hazards and risks asso- ciated with the device. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 30: Information On How To Use The Device

    XP-504. Additional parts of the documentation and information for the XP-504, including the installation instructions, can be found at the Eaton Download Center - Documentation and at the product pages on the Internet WARNING...

  • Page 31: Prerequisites For Proper Operation

    Failure to follow any applicable occupational health and safety rules, standards, and/or regulations Device failures or function disturbances Improper use and/or handling Not following the instructions or observing the information in the documentation for the XP-504 Alterations, changes, and repairs to the XP-504 XP-504 04/2022 MN048028EN Eaton.com...

  • Page 32: Device-Specific Hazards

    USB and HDMI Connectors are for maintenance only, except when installed together with strain relief metal plate with the cable ties provided. The devices shall be installed inside or as part of a tool secured enclosure. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 33 Instruction leaflet for the device. EXPLOSION HAZARD LITHIUM BATTERY The lithium battery installed in Panel-PC or Box-PC may explode if handled incorrectly. Do not replace batteries in hazardous locations Dispose of the XP-504 unit professionally. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 34 The cables being used must be assembled and terminated as requi- red by the port/interface description in this document. When wiring the XP-504, follow all instructions regarding how to wire the corresponding port/interface. All general Directives and standards must be complied with. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 35 CAUTION NON-GALVANICALLY-ISOLATED INTERFACES The device may be damaged by potential differences. The GND terminals of all bus modules must be connected. The device must be de-energized before connecting or dis- connecting any connections to it. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 36 CAUTION UV LIGHT Plastics will become brittle when exposed to UV light. This artificial aging will reduce the XP-504 unit's lifespan. Protect the XP-504 series devices from direct sunlight and other sources of UV radiation. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 37 USB port), it is important to keep in mind that their EMC interference immunity parameters may render them unsuitable for use in industrial environments. The USB and HDMI Connectors are for maintenance only, except when installed together with strain relief metal plate with the cable ties provided. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 38 ICE/EN 61000−6-4. These products can cause radio interference in domestic environments. In this case, the party operating the products must implement appropriate radio inter- ference suppression measures. CAUTION Installation requires qualified electrician XP-504 04/2022 MN048028EN Eaton.com...

  • Page 39: Installation

    Make sure that the XP-504 devices do not overheat. The minimum clearance to components that radiate heat, such as transformers under heavy loads, is 15 cm. The controls and connectors must remain accessible even after the device has been installed. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 40: Temperatures

    Fig. 6: Example: Panel-PC airflow, heat dissipation through cooling fins on Box-PC Make sure that there will be enough volume for air changes inside the control cabinet, etc. Maintain the specified clearance around the XP-504 devices. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 41 Ambient temperature with natural convection: ϑ: 0°C (32°F) ≦ T ≦ 45°C (113°F) The panel builder is responsible for the temperature rise calculation. Eaton will provide heat dissipation data as necessary for design verification in conformity with IEC EN 61439 – please refer to the data sheet for the XP-504 in the online catalog at Eaton.com/ecat.

  • Page 42: Installation Position

    ≦ max. + 10° in the directions shown below. If the device is not mounted in a perfectly vertical position, make sure that air will still be able to circulate properly through the openings in the housing. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 43 The interfaces are located on the bottom of the computer core on Panel-PC, Terminal and Terminal with Extender RX. Make sure to consider the space required to remove the SD card and replace the battery, as well as the space needed for the inter- face connections. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 44: Box-Pc

    The Extender TX is designed to be vertically flush-mounted in control cabinets. A mounting bracket is used for installation on the DIN-rail in the control cabinet. 3.2.3.2 Mounting position Only vertical mounting is allowed, and all airflow clearances must be maintained. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 45 Power connector at the top The connectors must remain accessible even after the device has been installed. The interfaces are located on the front of the Extender TX. Make sure to maintain the required space for the interface connec- tions. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 46: Unpacking And Checking The Equipment Supplied

    Missing parts or damage If you notice anything wrong, please contact your distributor or Eaton Service +1 877-386-2273 (en) / 877-ETN-CARE (877-386-2273) The packages for this device series come with: Tab. 4: Std. packPanel-PC XP-504-...
  • Page 47 Internal hexagon M 4 x 25 DIN 914 galvanized XP-504-10-... 10 x XP-504-15-... 12 x XP-504-21-... USB-A to USB-B cable DisplayPort cable Cable binder Tab. 7: Std. packTerminal with Extender RX Description Unit XP-504-..-TERMINAL-EXT Plug connector MSTBT 2.5/3-ST-5.08 XP-504 04/2022 MN048028EN Eaton.com...
  • Page 48 Accordingly, make sure to protect the XP-504 from mechanical loads that exceed the scope of the unit's intended use. The device should only be transported in its original packaging after being packed properly. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 49: Mounting

    List of tools: Wrench for 2 mm Allen key (5/64") PZ2 Pozidriv screwdriver Open-ended wrench SW10 Ground strap: length ≤ 35 cm, width ≥ 20 cm with eyelet Torque wrench with Newton meter scale XP-504 04/2022 MN048028EN Eaton.com...

  • Page 50: Preparations

    The purpose of the holding brackets is to secure the Panel-PC, Terminal and Terminal with Extender RX in the installation cutout, e.g., on the control panel door. To this end, the brackets must be hooked into the enclosure and screwed against the control panel door, etc. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 51 One holding bracket each at the left and right outer fixing positions, as well as at the center On the left and right sides of the device: One holding bracket each at the upper and lower fixing positions Fig. 14: Location of holding brackets for IP65 on the XP-504-15-... XP-504 04/2022 MN048028EN Eaton.com...
  • Page 52 Fig. 15: Location of holding brackets for IP65 on the XP-504-21-... IP rating If the gasket is resting in the correct position and the holding brackets are installed properly, the following IP degrees of protection will be achieved: IP65 (at front) IP20 (at rear) XP-504 04/2022 MN048028EN Eaton.com...

  • Page 53: Installing The Panel-Pc And Terminals

    7. Check that the device is in its correct, centered position and that the gasket is in contact all around; adjust if necessary 8. Tighten the set screws in a criss-cross sequence with a max. torque of 0.6 - 0.7 Nm (5.31 -6.2 lb-in). XP-504 04/2022 MN048028EN Eaton.com...

  • Page 54: Box-Pc

    Push down on the mounting bracket spring so that the device will snap into place. To do this, push the bottom of the Box-PC onto the DIN-rail at the same time. Check to make sure that the device is securely mounted on the DIN-rail. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 55: Mounting Wall

    For mounting on the mounting wall, you will need to use M4 screw assemblies through the mounting plates. Make sure to use both mounting points. Tighten each M4 screw assembly with a torque of 2.2 Nm (19.4716 lb-in). XP-504 04/2022 MN048028EN Eaton.com...

  • Page 56: Extender Tx

    Snap the spring mechanism into place on the DIN-rail. To do this, push down on the mounting clamp spring and push the bottom of the XP-504-EXT module onto the DIN-rail. Check to make sure that the device is securely mounted on the DIN-rail. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 57: Preparing The Device For Operation

    If the device has condensation in or on it, or if the panel has been exposed to environmental fluctuations, let the panel settle into the existing ambient temperature before switching it on. Do not expose the device to direct thermal radiation from heating appliances. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 58: E Lectrical Connection

    10.1" (25.65 cm) 1.6 A 0.3 A 0.5 A 15.6" (39.6 cm) 1.8 A 0.4 A 0.6 A 21.5" (54.6 cm) 2.0 A 0.7 A 0.9 A Power consumption Extender TX module: max. 0.13 A, Box-PC: 1.3 A at 24V XP-504 04/2022 MN048028EN Eaton.com...
  • Page 59 7.2 W 15" terminal max. 9.6 W 21" terminal max. 16.8 W 10" terminal EXT max. 12 W 15" terminal EXT max. 14.4 W 21" terminal EXT max. 21.6 W Extender TX module XP-504-EXT module 3.12 W XP-504 04/2022 MN048028EN Eaton.com...

  • Page 60: Functional Earthing Widescreen Terminal

    Remove the M6 nut from the set screw at the grounding point. Slip the ground strap eye onto the set screw. Tighten the M6 nut with a torque of 1.3 Nm (11.5 lb-in) back on the set screw. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 61 Functional earth +24 V DC Panel-PC +24 V DC Terminal +24 V DC Terminal with Extender RX Fig. 20: Screwing the functional earth conductor/ground strap onto the enclosure, with a Panel-PC used here as an example XP-504 04/2022 MN048028EN Eaton.com...

  • Page 62: Functional Earthing Box-Pc And Extender Tx

    3.5 Preparing the device for operation 3.5.1.2 Functional earthing Box-PC and Extender TX For Box-PCs and XP-504-EXT modules, a functional earth via the connection on the plug connector is enough. Make sure to observe the power supply specification. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 63: Power Supply Via Plug Connector

    0.75 mm / max. 2.5 mm (drain wire or conductor) min. AWG19 / max. AWG14 Tightening torque 0.5 - 0.6 Nm (4.4 -5.3 lb-in) for the screws on the respective plug connector Strip length 7 mm XP-504 04/2022 MN048028EN Eaton.com...

  • Page 64: Power Supply Panel-Pc, Terminal And Terminal With Extender Rx

    Fig. 21: Connecting the screw terminals with MSTBT 2.5/3-ST-5.08 Tab. 11: ConfigurationMSTBT 2.5/3-ST-5.08 Signal Connection Configuration Power Supply 24 VDC + 24 VDC SELV (safety extra low voltage) +24 V DC n.c. n.c. not used 0 V power supply XP-504 04/2022 MN048028EN Eaton.com...

  • Page 65: Power Supply Box-Pc

    Fig. 22: Connecting the screw terminals with MSTBT 2.5/3-ST-5.08 Tab. 12: ConfigurationMSTBT 2.5/3-ST-5.08 Signal Connection Configuration Power Supply 24 VDC + 24 VDC SELV (safety extra low voltage) +24 V DC Functional Functional earth earth 0 V power supply XP-504 04/2022 MN048028EN Eaton.com...

  • Page 66: Power Supply Extender Tx

    Fig. 23: Connecting the screw terminals with MSTBT 2.5/4-ST-5.08 Tab. 13: ConfigurationMSTBT 2.5/4-ST-5.08 Signal Connection Configuration Functional earth n.c. Internally connected n.c. +24 V DC Power Supply 24 VDC + 24 VDC SELV (safety extra low voltage) 0 V power supply XP-504 04/2022 MN048028EN Eaton.com...

  • Page 67: Using Peripheral Devices - External Connections

    4. Using peripheral devices - External connections 4. Using peripheral devices - External connections With its ports, Eaton's XP-504 series makes it possible to connect a variety of peri- pheral devices and components. The features on the individual devices in the XP-504 series are based on the devices' needs.

  • Page 68: Layout Of Interfaces

    Can be configured in BIOS; default setting: RS-232 full duplex ⑪ Strain relief Metal plate for fixing the USB and HDMI ports ⑫ power supply 24 VDC MSTBT 2.5/3-ST-5.08 ⑬ Battery BR2032 (190mAh, 3V) from Panasonic XP-504 04/2022 MN048028EN Eaton.com...

  • Page 69: Box-Pc

    Dual-USB3.0 / 2.0 T, plug type A ⑧ Default display interface ⑨ HDMI Default display interface 1.4b ⑩ RS232/422/485 9-pin D-sub plug, not galvanically isolated Can be configured in BIOS; default setting: RS-232 full duplex ⑪ 24 VDC power supply MSTBT 2.5/3-ST-5.08 XP-504 04/2022 MN048028EN Eaton.com...
  • Page 70 RJ-45 socket, 8-pole, 2 LEDs (CAT5e/6) EXT IN The RJ45 sockets on Terminal with Extender RX and Extender TX are used by the transmitter/receiver cable. Do not connect the RJ45 (Extender RX) EXT IN port to an Ethernet network. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 71: Extender Tx

    RJ45 (Extender TX) RJ-45 socket, 8-pole, 2 LEDs (CAT5e/6) The RJ45 sockets on Terminal with Extender RX and Extender TX are used by the transmitter/receiver cable. Do not connect the RJ45 (Extender TX) port to an Ethernet network. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 72: Sd Card

    Push the SD card into the SD card slot all the way to the stop. Pull the SD card out of the SD card slot. Store the SD card in its case in order to protect it. Insert the holder back in place. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 73 4. Using peripheral devices - External connections 4.2 SD card Fig. 29: Removing the SD card XP-504 04/2022 MN048028EN Eaton.com...

  • Page 74: Usb Interfaces

    The device must be de-energized before connecting or dis- connecting any connections to it. Only use standard USB cables with a shield. Max. cable length: 5 m. Dual-USB 3.0/2.0 Type A USB 3.0/2.0 Type A Fig. 30: USB ports on the PCs in the series XP-504 04/2022 MN048028EN Eaton.com...

  • Page 75: Usb-B

    USB 3.0 SSTX+ Super Speed Transmitter SSTX+ Super Speed Transmitter (UP) data cable USB 3.0 (DOWN data cable USB 3.0 4.3.2 USB-B Available on: Terminal Fig. 33: USB-B 2.0, not galvanically isolated, plug type B XP-504 04/2022 MN048028EN Eaton.com...

  • Page 76: Mini Usb-B

    4.3.3 Mini USB-B Available on: Extender TX module Fig. 34: Type-B mini-USB port pinout specification Wire Function Power + 5V Data - White Data - Data + Green Data + n.c. – Host device Black ground XP-504 04/2022 MN048028EN Eaton.com...

  • Page 77: Ethernet

    RJ45 plug-in connection is subjected to pulling. Protect the RJ45 plug-in connection from strong vibrations. Protect the RJ45 plug-in connection from tensile forces at the socket. Eaton recommends implementing measures for protecting against cyberattacks. Eaton cyber security Eaton.com/us/en-us/company/news-insights/cybersecurity.html Eaton.com/cybersecurity XP-504 04/2022 MN048028EN Eaton.com...

  • Page 78: Display Interfaces

    Hot Plug Detect LANE 0+ Return LANE 2+ DP Power LANE 1- Available on: Extender TX n.c. AUX CH+ LANE 1+ n.c. LANE 0- AUX CH- n.c. Hot Plug Detect LANE 0+ Return n.c. n.c. LANE 1- XP-504 04/2022 MN048028EN Eaton.com...

  • Page 79: High Definition Multimedia Interface (Hdmi)

    T.D.M.S. Data 2+ 8 DDC Clock T.D.M.S. Data 0- 16 DDC DATA T.D.M.S. Data 2- 10 T.D.M.S. Clock+ T.D.M.S. Data 1+ 11 T.D.M.S. Clock- Hot Plug Detect T.D.M.S. Data 1- 13 n.c. T.D.M.S. Data 0+ 14 n.c. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 80: Serial Interfaces Rs232/Rs422/Rs485

    RS422 mode. RS422 RX+ n.c. RS422 RX- n.c. Tab. 16: Pin assignment (RS485 mode) signal signal RS485 Data+ 6 n.c. The BIOS will need to be RS485 Data- n.c. set to RS485 mode. n.c. n.c. n.c. n.c. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 81: Dvi-I

    T.D.M.S. Clock - DDC Clock (Return for +5V, H-Sync, and V-Sync) n.c. DDC Data Hot Plug-Detect n.c. n.c. T.D.M.S. Data 0- n.c. T.D.M.S. Data 1- T.D.M.S. Data 0+ n.c. T.D.M.S. Data 1+ T.D.M.S. Data 0/5 Shield XP-504 04/2022 MN048028EN Eaton.com...
  • Page 82 4. Using peripheral devices - External connections 4.7 DVI-I XP-504 04/2022 MN048028EN Eaton.com...

  • Page 83: Commissioning

    Do not expose the device to direct thermal radiation from heating appliances. Power the XP-504 with 24 VDC. The XP-504 unit will boot up. As soon as the operating system loads, the application will start. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 84: Initial Commissioning

    The XP-504 can be connected to various computer networks using the two RJ-45 ports that serve network as Ethernet ports. Ethernet is a standard used for local networks, and requires twisted-pair cables in order to con- nect the computers. XP-504 04/2022 MN048028EN Eaton.com...

  • Page 85: Running The

    Reducing the level of brightness will increase the display back- light's lifespan. If the Panel-PC or Box-PC will not boot, and/or an error message appears, follow the instructions in the → Section "Faults", page 99 section. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 86 5. Commissioning 5.2 Running the XP-504 XP-504 04/2022 MN048028EN Eaton.com...

  • Page 87: Operation Touch Display

    Make sure that the gestures you perform on the Multi-touch touch panel will be recognized by the application. It may be necessary to practice cer- tain gestures beforehand. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 88 Scratches and other damage on the device's glass panel may trigger unexpected operator actions. When functions are triggered incor- rectly in the system, bodily injury and property damage may occur. Make sure that the glass panel is not damaged during installation or use. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 89 Touch display or using it for support. Make sure to always keep the Touch display clean. Always check to make sure that the device has recognized the operator actions you have entered. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 90 Touch the touch display with your finger. Then press the Enter key on your keyboard and touch the other touch display with your finger. Once you have done this on all connected Touch displays, the setup process will be complete. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 91 ONLY BE TRIGGERED BY USING MULTIPLE FINGERS AT THE SAME TIME Important operating functions must be programmed in such a way that they can only be triggered by gestures requiring multiple fingers on the touch panel at the same time. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 92 If there is static contact on the touch panel during booting, this may result in functional restrictions. To prevent this, take the measures below: Do not touch the touch panel during booting! If you do touch it, make sure to move your finger(s) slightly! XP-504 04/2022 MN048028EN Eaton.com...
  • Page 93 7.2.1 Updates Eaton releases patches and updates for its products regularly in order to protect them from identified vulnerabilities. Accordingly, Eaton encourages customers to monitor the availability of new firmware updates and install them immediately. Avail- able firmware and software updates can be found at Eaton.com/software...
  • Page 94 Protect Mode. To do this, go to "Start → Eaton → Protect Mode Manager" in Windows, select the "Advanced" tab, and click on the "Enable Protect Mode" button. The system will then restart and return the XP-504 device to its normal protected state.
  • Page 95 7.2.4 Managing users and configuring the XP-504 Managing Accounts An "XP504" user account with admin privileges is already set up on the Eaton XP-504 device by default. You will need to enter a new password for this user the first time you start the device.
  • Page 96 7.2.8 License Eaton Visual Designer Runtime XP-504-..-…-…-2V-device types, which are licensed for Eaton Visual Designer runtime, are licensed at the factory for Eaton Visual Designer runtime and enabled with 4000 tags. Shipped from the factory the license is installed on the device and a recent version of Visual Designer runtime is installed.
  • Page 97 Visual Designer functions (e.g., remote project setup and WEB visualization). There are two applications for enabling and disabling this service (and the cor- responding TCP/UDP ports) that can be accessed by clicking on "Start → Eaton" in Windows: Activate IIS.cmd Deactivate IIS.cmd...
  • Page 98 7. Operating System 7.2 Windows 10 Enterprise LTSC XP-504 04/2022 MN048028EN Eaton.com...
  • Page 99 The Projected Capacitive Touch Loosen the set screws → page (PCT) is not responding or is The set screws are too tight responding incorrectly when used. Check touch configuration, → Touch function not set up page 90 XP-504 04/2022 MN048028EN Eaton.com...
  • Page 100 8. Faults XP-504 04/2022 MN048028EN Eaton.com...
  • Page 101 Do not replace batteries in hazardous locations Dispose of the XP-504 unit professionally. EXPLOSION HAZARD LITHIUM BATTERY Replace the battery exclusively with a battery of the same type. Using other batteries may pose a risk of fire or explosion. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 102 Remove the battery from the battery holder (red arrow) and insert the new bat- tery BR2032 (190mAh, 3V) from Panasonic into the holder with the + terminal in front. Slide the battery holder back into its slot. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 103 ESD protection measures. CAUTION Installation requires qualified electrician CAUTION Arrange for a qualified electrician or for EATON Service to replace the battery. In order to prevent damage to the device, do the following before opening the enclos- ure: Shut down the operating system.
  • Page 104 Set the SD card holder with the bracket to the side so that you can get to the bat- tery. Disconnect the plug from the motherboard and carefully remove the battery from the inside of the enclosure. Put in the new battery in the same place on the motherboard. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 105 Close Box-PC Put the enclosure cover back in place. Screw the six screws (Torx A2 M3x8 ISO 14581) back in. 0.9 Nm (7.97 lb-in) Tighten the six Torx screws with a torque of 0.9 Nm. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 106 9. Maintenance 9.2 Repairs 9.2 Repairs For repairs, please contact your vendor or Eaton's Technical Support. CAUTION DESTRUCTION The XP-504 should only be opened by the manufacturer or by an authorized center. Operate the device until only with the enclosure fully closed and sealed.
  • Page 107 The ambient conditions must be met when transporting and storing the XP-504. The ambient air temperature for storage and transportation must not exceed the max- imum specified limit of: -20 – + 60 °C (-4 – +140 °F). XP-504 04/2022 MN048028EN Eaton.com...
  • Page 108 Accordingly, make sure to protect the XP-504 from mechanical loads that exceed the scope of the unit's intended use. The device should only be transported in its original packaging after being packed properly. XP-504 04/2022 MN048028EN Eaton.com...
  • Page 109 BR2032 (190mAh, 3V) from Panasonic, the battery for the Box-PC is available as a spare part Electrical components Various Tab. 17: Materials used in the packaging Carton Cardboard Inner packaging Panel-PC Cardboard; plastic film and bag: Polyethylene (PE) XP-504 04/2022 MN048028EN Eaton.com...
  • Page 110 Appendix Appendix A.1 Technical data A.1.1 Data sheet A.1.2 Dimension and weight specifications A.1.3 General data A.1.4 Information on the power supply A.1.5 Approvals and declarations A.2 Further usage information XP-504 04/2022 MN048028EN Eaton.com...

  • Page 111: Xp-504-21

    Appendix A.1 Technical data A.1 Technical data A.1.1 Data sheet The current specifications can be found in the data sheet for the device in the Eaton online catalog. Eaton.com/ecat Catalog No. Type Panel-PC 199996 XP-504-10-A10-A01-2B 199997 XP-504-10-A10-A01-2V 199998 XP-504-15-A10-A01-2B 199999...
  • Page 112 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 256 mm (10.07") ±0.5 (0.02"), f = 175 mm (6.88") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...
  • Page 113 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 388 mm (15.28") ±0.5 (0.02"), f = 239 mm (9.40") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...
  • Page 114 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 519 mm (20.43") ±0.5 (0.02"), f = 313 mm (12.32") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...
  • Page 115 (0.29") 55 mm (2.17") 7 mm (0.28") Fig. 46: Dimensions Box-PC devices in mm (Inch) Width x Height x Depth 55 mm x 170 mm x 92.3 mm +/- 0.2 mm (without plug) Weight 1.15 kg XP-504 04/2022 MN048028EN Eaton.com...
  • Page 116 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 256 mm (10.07") ±0.5 (0.02"), f = 175 mm (6.88") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...
  • Page 117 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 388 mm (15.28") ±0.5 (0.02"), f = 239 mm (9.40") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...
  • Page 118 ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 519 mm (20.43") ±0.5 (0.02"), f = 313 mm (12.32") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...

  • Page 119: Xp-504-10

    ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 256 mm (10.07") ±0.5 (0.02"), f = 175 mm (6.88") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...

  • Page 120: Xp-504-15

    ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 388 mm (15.28") ±0.5 (0.02"), f = 239 mm (9.40") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...

  • Page 121: Xp-504-21

    ≦ 0.5 mm (0.02") with a surface roughness Rz ≦ 120; IP 65 ￫ DIN ISO 2768-2 (K) Hole diameter built-in: e = 519 mm (20.43") ±0.5 (0.02"), f = 313 mm (12.32") ±0.5 (0.02") XP-504 04/2022 MN048028EN Eaton.com...

  • Page 122: Xp-504-Ext Module

    114 mm (4.49") (0.89") 43.5 mm (1.71") Fig. 53: Dimensions XP-504-EXT module in mm (Inch) Width x Height x Depth 22.6 mm x 99.35 mm x 113.65 mm +/- 0.2 mm (without plug) Weight 0.17 kg XP-504 04/2022 MN048028EN Eaton.com...

  • Page 123: General Data

    Heat sink Aluminum (heat sink) (only Panel-PC and Box-PC Battery Panel-PC BR2032 (190mAh, 3V) from Panasonic, the battery for the Box-PC is available as a spare part Electrical components Various Panel-PC Touchsensor Projected Capacitive Touch (PCT) XP-504 04/2022 MN048028EN Eaton.com...
  • Page 124 Operating System Windows 10 Enterprise LTSC Cooling Fanless CPU and system cooling, natural convection- based passive cooling Battery BR2032 (190mAh, 3V) from Panasonic lifespan, backup time Maintenance-Free, normally 5 years at 25° C (77°F) (at zero voltage) XP-504 04/2022 MN048028EN Eaton.com...
  • Page 125 XP-504-21-... Normally 350 cd/m2 Backlight dimmable via software Lifespan of backlight Normally 50000 h at 25 °C Format XP-504-10-... 16:10 XP-504-15-... 16:9 XP-504-21-... 16:9 Viewing range [left/right/above/below] normally 85°/85°/85°/85° XP-504-10-... normally 85°/85°/80°/80° XP-504-15-... XP-504-21-... normally 89°/89°/89°/89° XP-504 04/2022 MN048028EN Eaton.com...

  • Page 126: Information On The Power Supply

    7.2 W 15" terminal max. 9.6 W 21" terminal max. 16.8 W 10" terminal EXT max. 12 W 15" terminal EXT max. 14.4 W 21" terminal EXT max. 21.6 W Extender TX module XP-504-EXT module 3.12 W XP-504 04/2022 MN048028EN Eaton.com...

  • Page 127: Approvals And Declarations

    (1000 Volts Maximum) Product standards DIN EN 60898- Electrical accessories - Circuit-breakers for overcurrent 1:2006-03 protection for household and similar installations EN 50178 Electronic equipment for use in power installations IEC/EN 61131-2 Programmable controllers: Equipment requirements and XP-504 04/2022 MN048028EN Eaton.com...
  • Page 128 Displacement amplitude: 5–9 Hz: 3.5 mm; 9–60 Hz: 0.15 mm Acceleration amplitude: 60–150 Hz: 2 g Free fall, packaged IEC/EN 60068-2-32 Climatic proofing Cold to IEC 60068-2-1 Damp heat as per EN 60068-2-3 Dry heat to IEC60068-2-2 XP-504 04/2022 MN048028EN Eaton.com...

  • Page 129: Further Usage Information

    Information on networks in general and on how to integrate PCs and touch displays in networks Download Center, Eaton Online Catalog Enter "XP500" into the search box and the catalog will take you directly to the cor- responding product group in the Automation, Control and visualization section.
  • Page 130 Appendix A.2 Further usage information XP-504 04/2022 MN048028EN Eaton.com...

  • Page 131: Alphabetical Index

    Specifications External Further reading Cooling Copy-protected Copyright General data Current 58, 126 Hazards Damage Device-specific Declarations HDMI 68-69 Description Device variants Dimensions Initial commissioning Directives Installation Display Installation cutout Disposal Installation position Recycling Selection 42, 44 XP-504 04/2022 MN048028EN Eaton.com...
  • Page 132 71, 76 Screen area Missing parts Visible Mounting 49, 54, 56 Screen diagonal Mounting distance SD card Mounting position SD card slot 68-69 SD card 43-44 Service Standards Std. pack 46-48 Nameplate Storage Support Online Catalog XP-504 04/2022 MN048028EN Eaton.com...
  • Page 133 Technical data Touch-Sensor Transit damage Transport Troubleshooting UL listing USB-B USB-Device USB-Host 68-69 USB host Versions Voltage range 58, 126 Weight XP-504 04/2022 MN048028EN Eaton.com...
  • Page 134 Eaton is dedicated to ensuring that reliable, efficient and safe power supply is available when it’s needed most. With unparalleled knowledge of electrical power management across industries, experts at Eaton deliver customized, integrated solutions  to solve our customers’ most critical challenges. Our focus is on delivering the right solution for the application.
