22. Appendix

A - Console Menu Structure

NOTE: The System will automatically return to the main screen after 30 secs if a menu screen is displayed and no buttons are pressed.
Parameter
Menu 1 - Code Transmitter
STORING TRANSMITTERS
Menu 2 - Current Trips
Full Load Amps 0.5 HP model AX3105
Full Load Amps 1.0 HP model AX3110
Full Load Amps 0.5 HP model AX3305
Full Load Amps 1.0 HP model AX3310
Full Load Amps 1.5 HP model AX3315
100% Overload Time
Menu 3 - Auto Close
V1 CONSOLE:
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time
S.B AUTO-CLOSE TIME Sets and enables the S.B triggered
Auto-Close time
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time
S.B PEDESTRIAN AUTO-CLOSE TIME Sets and enables the PE
Pedestrian Auto-Close time
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions (requires
Safety Beams)
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions
AUTO-CLOSE AFTER POWER UP
Enables Auto-Close feature power up
V2 CONSOLE
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time
S.B AUTO-CLOSE TRIG Selects the Safety Beam or combination
of Safety Beams to enable the S.B triggered Auto-Close mode.
S.B AUTO-CLOSE TIME Sets and enables the S.B triggered
Auto-Close time
PEDESTRIAN AUTO-CLOSE TIME Sets and enables the
Pedestrian Auto-Close time
S.B PEDESTRIAN AUTO-CLOSE TRIG Selects the Safety Beam
or combination of Safety Beams to enable the S.B triggered
Pedestrian Auto-Close mode.
S.B PEDESTRIAN AUTO-CLOSE TIME Sets and enables the PE
Pedestrian Auto-Close time
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close obstructions (requires
Safety Beams)
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open obstructions
AUTO-CLOSE AFTER POWER UP
Enables Auto-Close feature power up
OPERATIONAL BUTTONS:
1. Press PREV/NEXT buttons move to Left/Right.
2. Press OPEN/CLOSE buttons to change setting.
3. Press SET button to save changes.
4. Press STOP to return to MENU without saving changes.
Min Max Default
0.0 511
0.0 1.6 1.6
0.0 2.9 3.7
0.0 1.6 1.6
0.0 2.9 2.9
0.0 3.5 3.5
0 30 10
0.0 300.0 0.0
0.0 60.0 0.0
0.0 60.0 0.0
0.0 60.0 0.0
Off On Off
Off On Off
Off On Off
0.0 300.0 0.0
None None
0.0 60.0 0.0
0.0 60.0 0.0
None None
0.0 60.0 0.0
Off On Off
Off On Off
Owner Installation Instructions
Off On Off
Step Unit Menu Section
No.
1 13.1
1 Amps 2.1 Appendix C
1 Amps 2.1 Appendix C
1 Amps 2.1 Appendix C
1 Amps 2.1 Appendix C
1 Amps 2.1 Appendix C
1 Sec 2.2 Appendix C
1.0 Sec 3.1 15.2
1.0 Sec 3.2 15.3
1.0 Sec 3.3 15.4
1.0 Sec 3.4 15.4
3.5 15.5
3.6 15.5
3.7 15.5
1.0 Sec 3.1 16.2
3.2 16.3
1.0 Sec 3.3 16.3
1.0 Sec 3.4 16.4
3.5 16.4
1.0 Sec 3.6 16.4
3.7 16.5
3.8 16.5
Axess Pro Series 3000
3.9 16.5
