To our customers,
st
On April 1
, 2010, NEC Electronics Corporation merged with Renesas Technology
Corporation, and Renesas Electronics Corporation took over all the business of both
companies. Therefore, although the old company name remains in this document, it is a valid
Renesas Electronics document. We appreciate your understanding.
Issued by: Renesas Electronics Corporation (http://www.renesas.com)
Send any inquiries to http://www.renesas.com/inquiry.
Old Company Name in Catalogs and Other Documents
Renesas Electronics website:
http://www.renesas.com
st
April 1
, 2010
Renesas Electronics Corporation

Advertisement

Table of Contents
loading

Related Manuals for Renesas 32185

Summary of Contents for Renesas 32185

  • Page 1 On April 1 , 2010, NEC Electronics Corporation merged with Renesas Technology Corporation, and Renesas Electronics Corporation took over all the business of both companies. Therefore, although the old company name remains in this document, it is a valid Renesas Electronics document. We appreciate your understanding.
  • Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific”...
  • Page 3 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
  • Page 4 Please be sure to implement safety measures to guard against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other applicable measures.
  • Page 5 2. The product described herein was prepared for program development or evaluation purposes. The product cannot be used for the mass production. 3. Renesas Technology Corporation and Renesas Solutions Corporation will not assume any responsibility for the results of development no matter what systems may have been developed by customers by using the product described herein.
  • Page 6 M3A-2154G52B. This manual describes how to set up the hardware and software products included with the 32185/32186/32192/32195/32196 Group Starter Kit and the precautions to be observed when using those products. For details about the 32192/321296 or 32186 Group hardware and software products and development support tools, refer to the user’s manuals and related documentation supplied with...

  • Page 7: Table Of Contents

    1. Overview...1 Outline of the Starter Kit ... 1 System Configuration... 2 2. Contents of the Product Package ...3 Packaged Product Items ... 3 Contents of CD-ROM ... 4 Other Necessary Items ... 4 3. Usage Precautions...5 Guaranteed Scope of the Starter Kit ... 5 Regarding About System Power-on Sequence when Connected to the Emulator...
  • Page 8 Appendix 1 Contents of CD-ROM ...19 1. Contents of CD-ROM...19 Acrobat ... 20 Tool... 21 Manual... 24 Board Related Manual (Document) ... 25 Sample Program ... 30 Appendix 2 Part List...31 Appendix 3 M3A-2154G02A Product Standards ...33 1. Overview...34 Outline of the Product ... 34 External View ...

  • Page 9: Overview

    This is an evaluation kit designed specifically for evaluating your computer at the early stage of system development as well as developing application software for the 32185/32186/32192/32195/32 196 Group by using M32100T-EZ-E (Emulator for M32R). M32100T-EZ-E should separately be prepared by the user.

  • Page 10: System Configuration

    XCN1 M32100T-EZ-E 5V power supply cable (included with a kit) XCN1 5V DC power supply (required on the user side) Mar 2008 32185/32186/32192/32195/32196 Group M3A-2154G02A (32185/32186/32192/ 32195/32196 Group evaluation board) 5V DC power supply (required on the user side) M3A-2154G02A...

  • Page 11: Contents Of The Product Package

    Note: When you unpack the Starter Kit, check to see that none of the above package contents is damaged or missing. If any item is damaged or not included, return the package to Renesas Technology Corporation through distributors. It will be replaced with a new one..

  • Page 12: Contents Of Cd-Rom

    CD-ROM for your application, please be sure to evaluate those technical contents, programs, and algorithms as the whole system, and not individually as single items before you determine whether they are useful. Renesas Technology Corporation will not assume any responsibility regarding their suitability for your application.

  • Page 13: Usage Precautions

    3. Usage Precautions Guaranteed Scope of the Starter Kit The Starter Kit was developed for users to trial the 32185/32186/32192/32195/32196 Group microcomputer specifications and development environment. Therefore, the results arising from the use of the Starter Kit are not guaranteed.

  • Page 14: About M3T-Pd32Rm

    The M32R core’s internal debug circuit (SDI) allows setting breakpoints, at which to break the program immediately before executing an instruction (at the address indicated by the program counter). For the M3A-2154G52B (32185/32186/32192/32195/32196 Group MCU), four such breakpoints can be set. (3) Post-execution PC break The M32R core’s internal debug circuit (SDI) allows setting one breakpoint, at which to break the...

  • Page 15: About Security Code Check Function

    Save check box, and the security code you entered is saved. From next time on, the security code saved here is used to check matching with the stored security code when M3T-PD32RM starts. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B in conventional emulators. The pre-execution PC break,...

  • Page 16: About Evaluation Board

    The socket included in the evaluation board uses NQPACK and HQPACK by TOKYO ELETECH CORPORATION. For more details, visit their website at http://www.tetc.co.jp/e_index.htm. The following illustrates configuration of M3A-2154G02A (32185/32186/32192/32195/32196 Group Evaluation Board). 32185/32186/32192/32195/32196 Group evaluation board M3A-2154G02A Figure 3.2 Configuration of M3A-2154G02A 3.5.2...

  • Page 17: Starter Kit Usage Conditions

    Conditions for the Power Supply Used Table 4.3 shows Power Supply Specifications required when using the Starter Kit. Table 4.3 Power Supply Specifications Symbol REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Rated value C to 35 No dewdrops allowed. Corrosive gas environment not allowed.

  • Page 18: Hardware Setup

    USB cable. The Connecting M32100T-EZ-E and Host PC is shown in Figure 5.1 Figure 5.1 Connecting M32100T-EZ-E and Host PC REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B When connected to the emulator 1st (Refer to 5.1.1) 2nd (Refer to 5.1.1) 3rd (Refer to 5.1.2)

  • Page 19: M3A-2154 Evaluation Board Power Supply And Setting

    Power to M32100T-EZ-E can be fed from USB cable. Note: Unless the Starter Kit is powered on this sequence, the kit may operate erratically or break down. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B 4.75-5.25V DC power supply SDI I/F...

  • Page 20: Hardware Setup When The Evaluation Board By Itself In Use

    Connecting the 5V power supply with the included cable turns the M3A-2154 Evaluation Board powered on. By disconnecting it, the M3A-2154 Evaluation Board turns powered off. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B 4.75-5.25V DC power supply Mar 2008...

  • Page 21: Software Setup

    (2) Proceed to install M3T-PD32RM following messages on the installation screen. (3) When you finished installing M3T-PD32RM, the dialog box shown in Figure 6.1 appears. Figure 6.1 Dialog Box when Installation is Finished REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Mar 2008 Page 13 of 80...

  • Page 22: Starting M3T-Pd32Rm

    To start M3T-PD32RM, choose [Start] -> [Programs] -> [Renesas] -> [PD32RM V3.01 Release 00] -> [PD32RM] from Start menu of Windows. When M3T-PD32RM starts, the initialize dialog box shown in Figure 6.2 appears. So initialize M3T-PD32RM from this dialog box.
  • Page 23 Case of using 32192 or 32195 or 32196 Group, while the MCU tab is open, select the “160” for the appropriate CPU Clock. Case of using 32185 or 32186 Group, while the MCU tab is open, select the “80” for the appropriate CPU Clock.

  • Page 24: Error Messages During M3T-Pd32Rm Startup

    “OK” button in that pop-up box. This brings up the initialize window, allowing you to retry the startup. In this case, you can retry only once. REJ10B0223-0150/Rev.1.50 ERROR11473: Target MCU is not under control. Please reset target systems. Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Page 16 of 80...

  • Page 25: Terminating M3T-Pd32Rm

    M3T-PD32RM. Or click the “Cancel” button, in which case M3T-PD32RM does not terminate. Figure 6.6 Dialog Box for Confirming Whether to Quit M3T-PD32RM REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Cancel Mar 2008 Page 17 of 80...

  • Page 26: M3T-Cc32R

    If M3T-CC32R has been installed normally, a command version of M3T-CC32R like the one shown below is displayed. CC32R Compiler for M32R Family V.X.XX Release X Copyright 1995-XXXX RENESAS TECHNOLOGY CORPORATION AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED. (X varies with the version of the Cross Tool Kit included in the package.) Displayed below this is the version information of each tool included in the Cross Tool Kit.

  • Page 27: Appendix 1 Contents Of Cd-Rom

    CD-ROM for your application, please be sure to evaluate those technical contents, programs, and algorithms as the whole system, and not individually as single items before you determine whether they are useful. Renesas Technology Corporation will not assume any responsibility regarding their suitability for your application.

  • Page 28: Acrobat

    + Readme.txt + Win16e + (For Windows3.1) + AR16E301.EXE + Readme.txt + Readme.txt Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B : PDF reader installation software : README file : PDF reader installation software : README file : PDF reader installation software...

  • Page 29: Tool

    + rej10j1494_pd32rm_n.pdf : M3T-PD32RM release note (Japanese version) Jpn+Tool+Pd32rm+ + pd32rmv301r00_j.exe + rjj10j1800_pd32rm_n.pdf : M3T-PD32RM release note REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B : Setup programs for M3T-CC32R : MAP Viewer user’s manual : Setup programs for M3T-CC32R : M3T-CC32R user’s manual (Assembler) : M3T-CC32R user’s manual (C Compiler)
  • Page 30 + W95E (Japanese version) Jpn+Tool+Ufla32r+ + rjj10b0232_ufla32rum.pdf: M3S-UFLA32R user’s manual + W95J REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B : M3S-KD32R release note : Setup programs for M3S-KD32R : M3S-KD32R release note : Setup programs for M3S-KD32R : Setup programs for M3S-UFLA32R...
  • Page 31 + Cc32rv50 + Pd32rmv3 + Kd32rv3 + Ufla32rv13 REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B : Objects for M3T-CC32R Version 4.3 : Objects for M3T-CC32R Version 5.0 : Objects for M3T-PD32RM Version 3 : Objects for M3S-KD32R Version 3 : Objects for M3S-UFLA32R Version 1.3...

  • Page 32: Manual

    + e32170um.pdf + e32172um.pdf + rej06b0048_32180um.pdf + rej09b0014_32182um.pdf + rej09b0015_32171um.pdf + rej09b0067_32176hm.pdf + rej09b0123_32192_195_196hm.pdf: 32192/32195/32196 Group hardware manual + rej09b0235_32185_186hm.pdf : 32185/32186 Group hardware manual (Japanese version) Jpn + Manual + + Readme_j.txt + j32rsm.pdf + rjj09b0107_32fpusm.pdf + j32170um.pdf + j32171um.pdf + j32172um.pdf...

  • Page 33: Board Related Manual (Document)

    Board are included in PDF file format. (English version) Eng+Document+M3A-2142+ (Japanese version) Jpn+Document+M3A-2142+ REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B + Readme_e.txt : README file + 2114um_e.pdf : M3A-2114 Starter Kit use’s manual + 2114g02sk_e.pdf : M3A-2114G02 product standards + 2114g12sk_e.pdf : M3A-2114G12 product standards...
  • Page 34 The related documents for the 32176 Group Evaluation Board are included in PDF file format. (English version) Eng+Document+M3A-2152+ (Japanese version) Jpn+Document+M3A-2152+ (4) M3A-2154 Evaluation Board related documents The related documents for the 32185/32186/32192/32195/32196 Group Evaluation Board are included in PDF file format. (English version) Eng+Document+M3A-2154+ (Japanese version) Jpn+Document+M3A-2154+ (5) M32100T-EZ-E related documents M32100T-EZ-E documents are included in PDF file format.
  • Page 35 (7) M3A-2145 Evaluation Board related documents The related documents for the M3S-UFLA32R are included in PDF file format. (English version) Eng+Document+M3A-2145+ (Japanese version) Jpn+Document+M3A-2145+ REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B + Readme_e.txt : README file + rej10b0228_2191sk.pdf : M3A-2191 product standards + cdrom_e.pdf : Content list of CD-ROM + Readme_j.txt...
  • Page 36 + 2154g52aum_e.pdf : M3A-2154 Starter Kit user’s manual + 2154g02sk_e.pdf : M3A-2154G02 product standards + Readme_j.txt + 2154g52aum_j.pdf + rjj10b0244_2154g02sk.pdf Mar 2008 32185/32186/32192/32195/32196 Group : README file : M3A-2154 Starter Kit user’s manual : M3A-2154G02 product standards Page 28 of 80...
  • Page 37 + rej10b0231_2142g04sk.pdf : M3A-2142G04 product standards + cdrom_e.pdf + Readme_j.txt + rjj10b0241_2142g04sk.pdf + cdrom_j.pdf Mar 2008 32185/32186/32192/32195/32196 Group : README file : Content list of CD-ROM : README file : M3A-2142G04 product standards : Content list of CD-ROM Page 29 of 80...

  • Page 38: Sample Program

    : 32172/32173 Group application notes and sample programs : 32176 Group application notes and sample programs : 32180/32182 Group application notes and sample programs : 32185/32186 Group application notes and sample programs sample programs : README file : 32170/32171 Group application notes and sample programs...

  • Page 39: Appendix 2 Part List

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Appendix 2 Part List A part list is provided in following pages for your reference. REJ10B0223-0150/Rev.1.50 Mar 2008 Page 31 of 80...
  • Page 40 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 32 of 80...

  • Page 41: Appendix 3 M3A-2154G02A Product Standards

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Appendix 3 M3A-2154G02A Product Standards This manual describes how to operate the M3A-2154G02A (32185/32186/32192/32195/32196 Group Evaluation Board) REJ10B0223-0150/Rev.1.50 Mar 2008 Page 33 of 80...

  • Page 42: Overview

    One of four channels can be selected using a rotary switch Inputs on two channels can be controlled using variable resistor (VR) controls Comes with a single-port LED Comes with a single-port toggle switch Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B M3A-2154G02A Power supply connector LED indicator (power-on)

  • Page 43: External View

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B External View An external view of the M3A-2154G02A is shown below. Figure 1.2 External View of the M3A-2154G02A REJ10B0223-0150/Rev.1.50 Mar 2008 Page 35 of 80...

  • Page 44: Block Diagram

    VCC-BUS VDDE /VDDE /VCCER VCCER /AVCC AVCC /VREF0 VREF0 32185/32186/32192/ 32195/32196 group MCUs Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B (JTAG, MCU control and other pins excluded) select select JTAG connector NBD I/F connector Reset circuit Page 36 of 80...

  • Page 45: Specifications Of The Evaluation Board

    Comes standard with a 9-pin Dsub connector (CN5) for serial communication with the host PC (Windows) Comes standard with a 10-pin JTAG connector for Renesas SDI (XCN1) Comes standard with a 14-pin NBD connector (CN4) Comes standard with a 2-channel connector for CAN communication (CN3),...

  • Page 46: Functional Specifications

    * TXx : Test pin * Ux : IC Note: CN1, TX1 and U3 are not mounted but they only have patterns available. Figure 2.1 Power Supply Circuit REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B LT1086CM-3.3 3.3V Mar 2008...
  • Page 47 Case of setting the condition except for default, setting the jumper is required after cutting the pattern for default condition by referring to the chapter 3.8 Setting jumper by cutting pattern. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Jumper...

  • Page 48: Fp Select Circuit

    Case of setting the condition except for default, setting the jumper is required after cutting the pattern for default condition by referring to the chapter 3.8 Setting jumper by cutting pattern . REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B VCCE...

  • Page 49: Mod Select Circuit

    Case of setting the condition except for default, setting the jumper is required after cutting the pattern for default condition by referring to the chapter 3.8 Setting jumper by cutting REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B VCCE VCCE...

  • Page 50: Serial I/O Interface

    REJ10B0223-0150/Rev.1.50 QS21X384Q1G TXD0 TXD1 TXD2 TXD3 RXD0 RXD1 RXD2 RXD3 CON2 FX1-144S-1.27DS P175 P174 CON1 FX1-144S-1.27DS Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B M32R/ECU P82/TXD0/TO26 P85/TXD1/TO23 P174/TXD2/TO28 P74/RTDTXD/ TXD3/NBDD0 P83/RXD0/ TO25 P86/RXD1/TO22 P175/RXD2/TO27 P75/RTDRXD/ RXD3/NBDD1 XG4C-1434 NBDD0 NBDD1...
  • Page 51 Note: The jumpers J15, J18, J19 and J20 are shorted by jumper parts. Table 2.7 RS-232C Connector Pin Assignments Connector Pin No Name REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B SIO Selected channel Description Connects P83/RXD0/TO25 to the extension connector (CON2) Uses the RXD0 function in RS-232C...

  • Page 52: Oscillator Circuit

    Shorted between 3–4 Note1: Using M32186F8VFP, the J1 jumper should be shorted between 2-4. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Outputs a clock from X1 (surface mount-type oscillator module) Outputs a clock from X2 (surface mount-type oscillator module)

  • Page 53: General-Purpose Output Port Led Indicators

    ON Condition M32R/ECU Port P110 P111 P112 P113 P114 P115 P116 P117 Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B VCCE * CONx : Connector * Lx : LED * Ux : IC Color High High High High High...

  • Page 54: General-Purpose Input Port Control Circuit

    P136 P137 * CONx : Connector * Jx : Jumper * Sx : Switch * Ux : IC Figure 2.7 General-purpose Input Port Control Circuit REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B PCA82C250T CON1 FX1-144S-1.27DS P136 P137 Mar 2008...
  • Page 55 Figure 2.8 Toggle Switch Positions REJ10B0223-0150/Rev.1.50 Starter Kit User’s Manual M3A-2154G52B Table 2.11 Toggle Switch Positions Lever Direction P130 P131 P132 P133 P134 P135 P136 P137 Middle Open Mar 2008 32185/32186/32192/32195/32196 Group Port Input Level High Middle Open Down Down Page 47 of 80...

  • Page 56: Analog Port Input Control Circuit

    AD0IN1 Uses VR control (VOL0) Does not use VR control (VOL0) Uses VR control (VOL1) Does not use VR control (VOL1) Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B VCCE VCCE VOL1 * CONx : Connector * Jx : Jumper...

  • Page 57: Can Interface

    * Ux : IC Note: TX7, TX8, TX9, TX10, TX11, TX12, TX13 and TX15 are not mounted but they only have patterns available. Figure 2.10 Interface with a CAN-mounted System REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B PCA82C250T CANH...
  • Page 58 1–2 Shorted Default between 1–2 Open between 1–2 Note: The jumpers J9 and J11 are shorted by jumper parts. REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Signal Name CANH1 High-level CAN0 input/output port CANL1 Low-level CAN0 input/output port CANH2...

  • Page 59: Jtag/Nbd Interface

    2.10 JTAG/NBD Interface The JTAG connector for Renesas SDI, XCN1 consists of the 2.54-mm contact pitch XG4C-1034 made by Omron Corporation. The NBD connector, CN4 consists of the 2.54-mm contact pitch XG4C-1434 made by Omron Corporation. VCCE XG4C-1434 VCCE XCN1 XG4C-1034 Figure 2.11 JTAG/NBD Interface...
  • Page 60 Table 2.16 JTAG Interface Connector Pin Assignments Connector Pin No Name XCN1 Table 2.17 NBD Interface Connector Pin Assignments Connector Pin No. Name REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Signal Name JTCK Test clock Ground JTDI Test data input JTDO Test data output...

  • Page 61: Reference Data

    TX 12 TX 13 RESET TX 14 MOD0 TX 15 CANH1 TX 16 CTX0 TX17 CRX0 TX 18 Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Description Signal Name CANL1 CANH2 CTX1 CRX1 CANL2 TXD1 VREF0 Page 53 of 80...

  • Page 62: Extension Connectors Con1 And Con2

    Pin Nos. 121 to 144 are not connected. REJ10B0223-0150/Rev.1.50 Signal Pin No. Name RESET P100 P101 P102 P103 P104 P105 P106 P107 Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B 1st pin 3rd pin Signal Pin No. Name VCCE AVCC0 VREF0 AD0IN0 AD0IN1 AD0IN2 AD0IN3 AD0IN4...

  • Page 63: Pin Assignments Of The Extension Connector Con2

    82 (202) 83 (203) 84 (204) 85 (205) 86 (206) 87 (207) 88 (208) 89 (209) 90 (210) Mar 2008 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B 1st pin 3rd pin CON2 Signal Pin No. Name P174 91 (211) P175...

  • Page 64: Can Cable

    Table 3.5 Connection Table Pin No. Pin Name — CANL (blue) — CANH (white) GND (black) — REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B CC2:Dsub connector 100mm Mar 2008 Pin Name Pin No. CANL CANH Page 56 of 80...

  • Page 65: Connection Diagram

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Connection Diagram A connection diagram is provided in following pages for your reference. REJ10B0223-0150/Rev.1.50 Mar 2008 Page 57 of 80...
  • Page 66 EXCVDD EXCVCC EXCVCC M32186F8VFP M32186F8VFP M32192F8VFP VDDE VCCE VCCE VCCER VCCBUS VCCBUS REJ10B0223-150/Rev.1.50 M32192F8VFP Mar. 2008 1M(OPEN) 1M(OPEN) Page 58 of 80...
  • Page 67 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 59 of 80...
  • Page 68 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 60 of 80...
  • Page 69 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 61 of 80...
  • Page 70 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 62 of 80...
  • Page 71 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 63 of 80...

  • Page 72: Part List

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Part List A part list is provided in following pages for your reference. REJ10B0223-0150/Rev.1.50 Mar 2008 Page 64 of 80...
  • Page 73 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 65 of 80...
  • Page 74 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 66 of 80...
  • Page 75 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 67 of 80...
  • Page 76 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 68 of 80...
  • Page 77 REJ10B0223-150/Rev.1.50 Mar. 2008 Page 69 of 80...

  • Page 78: Pattern Diagram

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Pattern Diagram A pattern diagram for the board is provided in following pages for your reference. REJ10B0223-0150/Rev.1.50 Mar 2008 Page 70 of 80...
  • Page 79 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 71 of 80...
  • Page 80 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 72 of 80...
  • Page 81 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 73 of 80...
  • Page 82 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 74 of 80...
  • Page 83 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 75 of 80...
  • Page 84 REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 76 of 80...

  • Page 85: Diagram Of External Dimension

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Diagram of External Dimension A diagram of external dimension for the board is provided in following pages for your reference. REJ10B0223-0150/Rev.1.50 Mar 2008 Page 77 of 80...
  • Page 86 CHANGE REJ10B0223-0150/Rev.1.50 Mar. 2008 Page 78 of 80...

  • Page 87: Setting Jumper By Cutting Pattern

    The jumper is shorted according to the condition. The example of using jumper pin is shown below. Figure 3.5 Example of Using Jumper Pin REJ10B0223-0150/Rev.1.50 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Example of cutting pattern Note: Cut pattern wiring from edge of through-hole.

  • Page 88: Description Of Board Silk

    32185/32186/32192/32195/32196 Group Starter Kit User’s Manual M3A-2154G52B Description of Board Silk The color of board silk indicates solder specification when the items on board are mounted. Table 3.7 Difference in the Color of Board Silk Color of board silk Solder specification when the items on board are mounted...

  • Page 89: Contents

    Oct 16, 2006 — - Added the board M3A-2154G02A product (Appendix 3) - Added the 32185 Group and the 32195 Group to the starter kit applicable microcomputer - Updated a setup method along with the tool update (Chapter 6) - Updated contents of CD-ROM (Appendix 1) - Updated a diagram of the external dimension.
  • Page 90 Rev.1.50, Mar.13,2008 2008, Renesas Technology Corp., All rights reserved. Printed in Japan.
  • Page 91 (4) any other purposes that pose a direct threat to human life Renesas shall have no liability for damages arising out of the uses set forth in the above and purchasers who elect to use Renesas products in any of the foregoing applications shall indemnify and hold harmless Renesas Technology Corp., its affiliated companies and their officers, directors, and employees against any and all...
  • Page 92 32185/32186/32192/32195/32196 Group Starter Kit User’s Manual 1753, Shimonumabe, Nakahara-ku, Kawasaki-shi, Kanagawa 211-8668 Japan REJ10B0223-0150...

This manual is also suitable for:

32192321953219632186
