REJ10J1208-0300
SH7125 Group PRQP0064GB-A
User System Interface Board
User's Manual
Renesas Microcomputer Development Environment System
SuperH™ Family / SH7125 Series
R0E571250CFG00
Rev.3.00
Revision Date: Feb. 27, 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRQP0064GB-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Renesas PRQP0064GB-A

  • Page 1 REJ10J1208-0300 SH7125 Group PRQP0064GB-A User System Interface Board User’s Manual Renesas Microcomputer Development Environment System SuperH™ Family / SH7125 Series R0E571250CFG00 Rev.3.00 Revision Date: Feb. 27, 2007...
  • Page 3 Please be sure to implement safety measures to guard against the possibility of physical injury, and injury or damage caused by fire in the event of the failure of a Renesas product, such as safety design for hardware and software including but not limited to redundancy, fire control and malfunction prevention, appropriate treatment for aging degradation or any other applicable measures.
  • Page 5: Important Information

    Improvement Policy: Renesas Technology Corp. (including its subsidiaries, hereafter collectively referred to as Renesas) pursues a policy of continuing improvement in design, performance, and safety of the emulator product. Renesas reserves the right to change, wholly or partially, the specifications, design, user's manual, and other documentation at any time without notice.
  • Page 6 2. In no event shall Renesas Solutions Corporation be liable for any consequence arising from the use of this emulator.
  • Page 7: Limited Warranty

    Renesas, upon inspection, shall determine to be defective in material and/or workmanship. The foregoing shall constitute the sole remedy for any breach of Renesas’ warranty. See the Renesas warranty booklet for details on the warranty period. This warranty extends only to you, the original Purchaser.
  • Page 8 3. This user's manual and emulator product are copyrighted and all rights are reserved by Renesas. No part of this user's manual, all or part, may be reproduced or duplicated in any form, in hard-copy or machine-readable form, by any means available without Renesas’ prior written consent.
  • Page 9: Definition Of Signal Words

    • READ this user's manual before using this emulator product. • KEEP the user's manual handy for future reference. Do not attempt to use the emulator product until you fully understand its mechanism. DEFINITION OF SIGNAL WORDS Either in the user's manual or on the product, several icons are used to insure proper handling of this product and also to prevent injuries to you or other persons, or damage to your properties.
  • Page 10 means WARNING or CAUTION. Example: CAUTION AGAINST AN ELECTRIC SHOCK means PROHIBITION. Example: DISASSEMBLY PROHIBITED means A FORCIBLE ACTION. Example: UNPLUG THE POWER CABLE FROM THE RECEPTACLE.
  • Page 11 Warnings for AC Power Supply: • If the attached AC power cable does not fit the receptacle, do not alter the AC power cable and do not plug it forcibly. Failure to comply may cause electric shock and/or fire. • Use an AC power cable which complies with the safety standard of the country.
  • Page 12 • If you smell a strange odor, hear an unusual sound, or see smoke coming from this product, then disconnect power immediately by unplugging the AC power cable from the outlet. Do not use this as it is because of the danger of electric shock and/or fire.
  • Page 13 Cautions for AC Adapter: • Use only the AC adapter included in this product package. • The included AC adapter is for this emulator. Do not use it for other product. • The DC plug on the included AC adapter has the below polarity.
  • Page 14 Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1. Do not repair or remodel the emulator product by yourself for electric shock prevention and quality assurance.
  • Page 15 Preface The R0E571250CFG00 is a user system interface board that connects a user system for the SH7125 PRQP0064GB-A (former code: FP-64AV) package to the SH7080 E200F emulator (R0E0200F1EMU00 or R0E570800VKK00).
  • Page 17: Table Of Contents

    Section 1 Configuration ...1 Section 2 Environmental Conditions ...3 Section 3 Connection Procedures ...5 Connecting User System Interface Board to User System... 5 3.1.1 Installing IC Socket ... 5 3.1.2 Installing Cable Head... 6 3.1.3 Fastening Cable Head ... 6 Connecting User System Interface Board to EV-Chip Board...
  • Page 19: Section 1 Configuration

    Section 1 Configuration Figure 1 and table 1 show the configuration and components of the user system interface board for the PRQP0064GB-A (former code: FP-64AV) package. Please make sure you have all of these components when unpacking. Screws (M2.0 x 6 mm) EV-chip unit Screws (M2.0 x 10 mm)
  • Page 20 Use an NQPACK064SA socket (manufactured by Tokyo Eletech Corporation) and a HQPACK064SA (manufactured by Tokyo Eletech Corporation) for the PRQP0064GB-A (former code: FP-64AV) package IC socket and socket cover, respectively, on the user system. Table 1 R0E571250CFG00 Components No. Component...
  • Page 21: Section 2 Environmental Conditions

    Section 2 Environmental Conditions Maintain the conditions in table 2 when using the emulator. Table 2 Environmental Conditions Item Temperature Humidity Vibration Ambient gases Specifications Operating: +10 to +35°C Storage: -10 to +35°C Operating: 35 to 80% RH, no condensation Storage: 35 to 80% RH, no condensation Operating: 2.45 m/s max.
  • Page 23: Section 3 Connection Procedures

    3.1.1 Installing IC Socket Solder the IC socket for a PRQP0064GB-A (former code: FP-64AV) package to the user system. Be sure to completely solder the leads so that the solder slops gently over the leads and forms solder fillets. (Use slightly more solder than the MCU.)
  • Page 24: Installing Cable Head

    22 (Vcc) 24 (Vss) Align pin 1 on the IC socket for a PRQP0064GB-A (former code: FP-64AV) package on the user system with pin 1 on the user system interface board, and insert the user system interface board into the IC socket on the user system, as shown in figure 4.
  • Page 25 Fasten the user system interface board to the IC socket for a PRQP0064GB-A (former code: FP-64AV) package on the user system with the four screws (M2.0 screw should be tightened a little at a time, alternating between screws on opposing corners. Take special care, such as manually securing the IC socket soldered area, to prevent the soldered IC socket from being damaged by overtightening the screws or twisting the components.
  • Page 26: Connecting User System Interface Board To Ev-Chip Board

    Connecting User System Interface Board to EV-Chip Board Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST. 1.
  • Page 27 User system Figure 3 Connecting User System Interface Board to EV-Chip Board EV-chip unit Connector No. EV-Chip Unit Connector No. User I/F Connector 1 (CN4) User I/F Connector 2 (CN5) Board Board Connector No. UCN1 UCN2...
  • Page 28: Recommended Dimensions For User System Mount Pad (Footprint)

    Figure 4 shows the recommended dimensions for the mount pad (footprint) for the user system with an IC socket for a PRQP0064GB-A (former code: FP-64AV) package (NQPACK064SA: manufactured by Tokyo Eletech Corporation). Note that the dimensions in figure 4 are somewhat different from those of the actual chip's mount pad.
  • Page 29: Dimensions For Ev-Chip Unit And User System Interface Board

    Dimensions for EV-Chip Unit and User System Interface Board The dimensions for the EV-chip unit and the user system interface board are shown in figure 5. Figure 5 Dimensions for EV-Chip Unit and User System Interface Board 125.0 EV-chip unit 60.0 30.0 Pin 1...
  • Page 30: Resulting Dimensions After Connecting User System Interface Board

    Resulting Dimensions after Connecting User System Interface Board The resulting dimensions, after connecting the user system interface board to the user system, are shown in figure 6. Spacer (φ6.0) Figure 6 Resulting Dimensions after Connecting User System Interface Board (when EV-chip unit User system Top view...
  • Page 31: Section 4 Installing The Mcu To The User System

    Section 4 Installing the MCU to the User System 1. Check the location of pin 1 before inserting. 2. Use a Philips-type screwdriver whose head matches the screw head. 3. The tightening torque must be 0.054 N•m or less. If the applied torque cannot be accurately measured, stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening.
  • Page 32 Screws (M2.0 x 6 mm) Socket cover MCU (SH7125) Pin 1 IC socket (NQPACK064SA manufactured by Tokyo Eletech Corporation) User system Figure 7 Installing MCU to User System...
  • Page 33: Section 5 Verifying Operation

    Section 5 Verifying Operation 1. Turn on the emulator according to the procedures described in the SH-2A, SH-2 E200F Emulator User's Manual (R0E0200F1EMU00E or R0E570800EMU00E). 2. The emulator connected to this user system interface board supports three kinds of clock sources as the MCU clock.
  • Page 35: Section 6 Notice

    Before connecting any parts or cables, make sure that pin 1 on the both sides are correctly aligned. Do not apply excessive force to the user system interface board while it is connected to the user system. The dimensions of the recommended mount pad for the IC socket for this user system interface board are different from those of the MCU.
  • Page 37 Publication Date: Rev. 1.00, March 7, 2005 Rev. 3.00, February 27, 2007 Published by: Sales Strategic Planning Div. Renesas Technology Corp. Edited by: Customer Support Department Global Strategic Communication Div. Renesas Solutions Corp. © 2007. Renesas Technology Corp., All rights reserved. Printed in Japan.
  • Page 38 Nippon Bldg., 2-6-2, Ohte-machi, Chiyoda-ku, Tokyo 100-0004, Japan http://www.renesas.com RENESAS SALES OFFICES Refer to "http://www.renesas.com/en/network" for the latest and detailed information. Renesas Technology America, Inc. 450 Holger Way, San Jose, CA 95134-1368, U.S.A Tel: <1> (408) 382-7500, Fax: <1> (408) 382-7501 Renesas Technology Europe Limited Dukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5FH, U.K.
  • Page 40 SH7125 Group PRQP0064GB-A User System Interface Board User’s Manual...
