Server (Front View)
FIGURE 2-2
Server (Rear View)
FIGURE 2-3
Power supply unit (PSU)
Operator panel (OPNL)
Fan unit (FAN_A)
RCI port
PCIe slot
SAS port
CD-RW/DVD-RW drive unit (DVDU)
Hard disk drive (HDD)
USB port
Gigabit Ethernet (GbE) port
Chapter 2
Serial port
LAN port
UPS
controller
(UPC) port
Hardware Overview
2-3
