2. Hold the two opaque handles on both sides of the motherboard unit and lift
the motherboard unit while sliding it out.
Removing the Motherboard Unit
FIGURE 6-5
3. Remove the motherboard unit from the server, and place it on a conductive
mat.
When removing the motherboard unit from the server, take care not to damage
the connector.
4. Remove the DIMMs.
For details, see
6.3

Mounting the Motherboard Unit

1. Hold the two opaque handles on both sides of the motherboard unit and slide
the unit in while lowering it to align with the predetermined position from the
front of the server.
When mounting the motherboard unit in the server, take care not to damage the
connector.
6-8 SPARC Enterprise M3000 Server Service Manual • January 2009
Section 7.2, "Removing the DIMMs" on page
Handles
7-4.
