Sun Microsystems SPARC Series Service Manual page 18

Wrist Strap Connection Destination
FIGURE 1-1
Hard disk drive or fan unit:
■
One of 2 thumbscrews on the
front of the server.
Caution – Do not connect the wrist strap cable to the conductive mat. Connect it
directly to the server.
The wrist strap and FRU must have the same level of potential.
1-2 SPARC Enterprise M3000 Server Service Manual • January 2009
FRU other than the units on the left:
■
1 place either at the upper right on the
front of the server or at the upper left at
the back.
