Mounting The Cd-Rw/Dvd-Rw Drive Unit - Sun Microsystems SPARC Series Service Manual

2. While pushing the black lever upward (2 in
RW/DVD-RW drive unit toward the front side to remove it from the server (3
in
3. Place the drive unit on the conductive mat.
Removing the CD-RW/DVD-RW Drive Unit
FIGURE 11-2
Lever
11.3 Mounting the CD-RW/DVD-RW Drive
Unit
Caution – Do not forcibly push the CD-RW/DVD-RW drive unit to insert in the
slot. Forcibly pushing the component in a slot may damage the component or the
server.
1. Align the CD-RW/DVD-RW drive unit with the drive slot, and then slowly
push the unit in until it locks in position.
11-4 SPARC Enterprise M3000 Server Service Manual • January 2009
).
FIGURE 11-2
2
), push the CD-
FIGURE 11-2
1
3
