NetSure™
DC/DC Converter Module
User Manual
Specification Number: 1C48582000P3
Model Number: C48/58-2000P3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetSure and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vertiv NetSure

  • Page 1 NetSure™ DC/DC Converter Module User Manual Specification Number: 1C48582000P3 Model Number: C48/58-2000P3...
  • Page 2 The information contained in this document is subject to change without notice and may not be suitable for all applications. While every precaution has been taken to ensure the accuracy and completeness of this document, Vertiv assumes no responsibility and disclaims all liability for damages resulting from use of this information or for any errors or omissions.
  • Page 3: Table Of Contents

    Vertiv™ NetSure™ DC/DC Converter Module User Manual TABLE OF CONTENTS Admonishments Used in this Document ..........................iv Important Safety Instructions ..............................v Static Warning ....................................vi 1 Introduction ....................................1 1.1 Overview ......................................................... 1 1.2 Specifications ..................................................... 1 1.2.1 DC Output Ratings ..............................................1 1.2.2 DC Input Ratings ..............................................
  • Page 4: Admonishments Used In This Document

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Admonishments Used in this Document will likely DANGER! Warns of a hazard the reader be exposed to that will result in death or serious injury if not avoided. (ANSI, OSHA) could WARNING! Warns of a potential hazard the reader...
  • Page 5: Important Safety Instructions

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Important Safety Instructions Safety Admonishments Definitions Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page iv. General Safety DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
  • Page 6: Static Warning

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Hazardous Voltage DANGER! HAZARD OF ELECTRICAL SHOCK. More than one disconnect may be required to de-energize the system before servicing. Handling Equipment Containing Static Sensitive Components ALERT! Installation or removal of equipment containing static sensitive components requires careful handling. Before handling any equipment containing static sensitive components, read and follow the instructions under “Static Warning”...
  • Page 7: Introduction

    Vertiv™ NetSure™ DC/DC Converter Module User Manual 1 Introduction 1.1 Overview The C48/58-2000P3 is a compact DC/DC converter which offers efficient power conversion. It operates from a nominal -48 VDC source to provide nominal -58 VDC load power. 1.2 Specifications 1.2.1 DC Output Ratings...
  • Page 8 Vertiv™ NetSure™ DC/DC Converter Module User Manual Figure 1.2: Output Voltage vs. Output Current at Maximum Peak Power 2000W Output voltage v.s. Output current at max. peak power Output Current (A) Figure 1.3: Output Power vs. Temperature Output power vs. Temperature at -41VDC ≥Vin ≥ -58VDC Temperature (℃)
  • Page 9: Dc Input Ratings

    Vertiv™ NetSure™ DC/DC Converter Module User Manual • Filtering: Peak-peak voltage is ≤ 250mV at 1-100MHz and normal output voltage. Psophemetic noise voltage is ≤ 2mV between 5-100% of the maximum load (output voltage > 56 VDC). Wideband noise is < 20mV rms between 25HZ-20kHz (test according to ETS300132).
  • Page 10 Vertiv™ NetSure™ DC/DC Converter Module User Manual • Typical Input Data: When equipped with one DC-DC converter. See Table 1.1. Maximum Current: Input current is 53 amperes at -41.0 volts DC input and 2000W peak power. Table 1.1: Typical Input Data...
  • Page 11: Environmental Ratings

    Vertiv™ NetSure™ DC/DC Converter Module User Manual 1.2.3 Environmental Ratings • Operation Temperature Range: -40°C to +80°C (-40°F to +176°F), -20°C to +55°C (-4°F to +131°F) with full performance. • Storage Ambient Temperature Range: -40°C to +70°C (-40°F to +158°F).
  • Page 12: Standard Features

    Vertiv™ NetSure™ DC/DC Converter Module User Manual 1.2.5 Standard Features • Type of Power Conversion Circuit: High Frequency. • Input Voltage Protection: Fusing: A non-user replaceable fuse is located in the negative input lead of each DC-DC converter. High and Low Input Voltage Inhibit: The converter shuts down at low or high input voltage.
  • Page 13: Mechanical Specifications

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Table 1.2: Monitoring Function Commands / signals that can be received Information gathered by the Controller from the by the Converter Module from the Converter Module. Controller. • Turn On/Off • Output Voltage •...
  • Page 14: Converter High Voltage Shutdown And Lockout Restart

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Figure 2.1: Local Indicator Locations Power Indicator (Green) Protection Indicator (Yellow) Alarm Indicator (Red) Table 2.1: DC-DC Converter Indicators Indicator Normal State Alarm State Alarm Cause No input voltage. Power Internal input fuse open.
  • Page 15: Installing Converter Modules

    Vertiv™ NetSure™ DC/DC Converter Module User Manual 2.4 Installing Converter Modules ALERT! This converter module (-58 VDC output) may be installed in a system that can either have +24V DC-DC converters installed or -58V DC-DC converters installed. The system cannot have both types of converters installed at the same time.
  • Page 16: Troubleshooting And Repair

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Figure 2.3: Installing Converter Module Captive Screw Handle Latch 3 Troubleshooting and Repair 3.1 Troubleshooting 3.1.1 Converter Module Current Sharing Imbalanced When multiple converters are operating in parallel and the load is greater than 10%, if the current sharing imbalance among them is greater than 2A, check if the converter is properly seated in the shelf.
  • Page 17: Replacement Procedures

    Vertiv™ NetSure™ DC/DC Converter Module User Manual Table 3.1: Converter Module Troubleshooting Symptom Possible Cause(s) Suggested Action(s) No input voltage. Make sure there is input voltage. Power Indicator (Green) Off Internal input fuse open. Replace the converter. DC input under/over voltage.
  • Page 18 Vertiv™ NetSure™ DC/DC Converter Module User Manual Loosen the captive screw on the module’s handle. Pull the handle down out from the module’s front panel (this will also retract the latch mechanism). See Figure 2.3. Grasp the handle and pull firmly to remove the module from the shelf.
  • Page 19 Vertiv™ NetSure™ DC/DC Converter Module User Manual Connect with Vertiv on Social Media https://www.facebook.com/vertivI https://www.instagram.com/vertiv/ https://www.linkedin.com/company/vertiv/ https://www.twitter.com/vertiv/...
  • Page 20 Vertiv.com | Vertiv Headquarters, 1050 Dearborn Drive, Columbus, OH, 43085, USA © 2020 Vertiv Group Corp. All rights reserved. Vertiv™ and the Vertiv logo are trademarks or registered trademarks of Vertiv Group Corp. All other names and logos referred to are trade names, trademarks or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness here, Vertiv Group Corp.
