SpectraLink 8000 SVP Server: Administration Guide for SIP

The Front Panel of the SVP Server

RS-232
16
The SVP Server's front panel contains ports to connect to power, the
LAN, and to an administrative computer via an RS-232 port. Status
LEDs supply information about the SVP Server's functioning.
L A C
N C O
K
T L
O
NETWORK
K
Port: male DB-9 connector (DTE) used for RS-232 connection to
RS-232
a terminal, terminal emulator, or modem for system administration.
LEDs
: Lit when there is a network connection.
LNKOK
: Lit if there is system activity.
ACT
: Lit if there are network collisions.
COL
: Port to wired (Ethernet) LAN.
NETWORK
: Lit when the system has detected an error.
ERROR
: Indicate system error messages and status.
STATUS
: Heartbeat, indicates gateway is running.
1
: If active calls.
2
SVP Server is locked.
3:
Currently unused.
4:
: This SVP Server is the cluster master.
5
(power jack): Connects to the AC adapter supplying power to the
PWR
system.
Use only the Polycom-provided Class II AC Adapter with output 24V
DC, 1A.
1 2 3 4 5
E
Status
R
R
O
R
PN: 1725-36033-001_G.doc
PWR
