Switch & Sense 8/8 User's Guide

Main connector and pinout

Connector type
Wire gauge range
Pin Signal Name
IP0A Input 0 terminal A
IP0B Input 0 terminal B
IP1A Input 1 terminal A
IP1B Input 1 terminal B
IP2A Input 2 terminal A
IP2B Input 2 terminal B
IP3A Input 3 terminal A
IP3B Input 3 terminal B
0-NO Relay 0 Normally Open contact
0-C Relay 0 Common contact
0-NC Relay 0 Normally Closed contact
1-NO Relay 1 Normally Open contact
1-C Relay 1 Common contact
1-NC Relay 1 Normally Closed contact
2-NO Relay 2 Normally Open contact
2-C Relay 2 Common contact
2-NC Relay 2 Normally Closed contact
3-NO Relay 3 Normally Open contact
3-C Relay 3 Common contact
3-NC Relay 3 Normally Closed contact
NO
C 7
IP7B
NC
IP7A
NO
IP6B
C 6
IP6A
NC IP5B
IP5A
NO
IP4B
C 5
IP4A
NC
NO
4
C
NC
Strain Relief for Field Wiring
Figure 3. Switch & Sense 8/8 screw terminals and relays
Connector specifications
Screw terminal
12 AWG to 20 AWG
Screw terminal pin out
Pin
IP4A
IP4B
IP5A
IP5B
IP6A
IP6B
IP7A
IP7B
4-NO
4-C
4-NC
5-NO
5-C
5-NC
6-NO
6-C
6-NC
7-NO
7-C
7-NC
0
IP0A
IP0B
IP1A
IP1B 1
IP2A
IP2B
IP3A
2
IP3B
3
Signal Name
Input 4 terminal A
Input 4 terminal B
Input 5 terminal A
Input 5 terminal B
Input 6 terminal A
Input 6 terminal B
Input 7 terminal A
Input 7 terminal B
Relay 4 Normally Open contact
Relay 4 Common contact
Relay 4 Normally Closed contact
Relay 5 Normally Open contact
Relay 5 Common contact
Relay 5 Normally Closed contact
Relay 6 Normally Open contact
Relay 6 Common contact
Relay 6 Normally Closed contact
Relay 7 Normally Open contact
Relay 7 Common contact
Relay 7 Normally Closed contact
10
Functional Details
NO
C
NC
NO
C
NC
NO
C
NC
NO
C
NC
