PCI-DAS1602/16 User's Guide
Pinout – main I/O connector
EXTERNAL INTERRUPT
EXTERNAL D/A PACER GATE
D/A INTERNAL PACER OUTPUT
A/D INTERNAL PACER OUTPUT
8-channel differential mode pin out
Signal Name Pin
GND 100
99
N/C 98
97
96
95
N/C 94
N/C 93
-12 V 92
GND 91
+12 V 90
GND 89
N/C 88
N/C 87
N/C 86
N/C 85
N/C 84
N/C 83
N/C 82
N/C 81
N/C 80
N/C 79
N/C 78
N/C 77
N/C 76
N/C 75
FIRSTPORTC Bit 7 74
FIRSTPORTC Bit 6 73
FIRSTPORTC Bit 5 72
FIRSTPORTC Bit 4 71
FIRSTPORTC Bit 3 70
FIRSTPORTC Bit 2 69
FIRSTPORTC Bit 1 68
FIRSTPORTC Bit 0 67
FIRSTPORTB Bit 7 66
FIRSTPORTB Bit 6 65
FIRSTPORTB Bit 5 64
FIRSTPORTB Bit 4 63
FIRSTPORTB Bit 3 62
FIRSTPORTB Bit 2 61
FIRSTPORTB Bit 1 60
FIRSTPORTB Bit 0 59
FIRSTPORTA Bit 7 58
FIRSTPORTA Bit 6 57
FIRSTPORTA Bit 5 56
FIRSTPORTA Bit 4 55
FIRSTPORTA Bit 3 54
FIRSTPORTA Bit 2 53
FIRSTPORTA Bit 1 52
FIRSTPORTA Bit 0 51
↓
PCI slot
Pin Signal Name
■ ■
50 GND
■ ■
49 SSH OUT
■ ■
48 PC +5 V
■ ■
47 N/C
■ ■
46 N/C
■ ■
45 A/D EXTERNAL TRIGGER IN
■ ■
44 D/A EXTERNAL PACER IN
■ ■
43 ANALOG TRIGGER IN
■ ■
42 A/D EXTERNAL PACER
■ ■
41 CTR 4 OUT
■ ■
40 CTR 4 GATE
■ ■
39 CTR 4 CLK
■ ■
38 D/A OUT 1
■ ■
37 D/A GND 1
■ ■
36 D/A OUT 0
■ ■
35 D/A GND 0
■ ■
34 N/C
■ ■
33 N/C
■ ■
32 N/C
■ ■
31 N/C
■ ■
30 N/C
■ ■
29 N/C
■ ■
28 N/C
■ ■
27 N/C
■ ■
26 N/C
■ ■
25 N/C
■ ■
24 N/C
■ ■
23 N/C
■ ■
22 N/C
■ ■
21 N/C
■ ■
20 N/C
■ ■
19 N/C
■ ■
18 LLGND
■ ■
17 CH7 LO
■ ■
16 CH7 HI
■ ■
15 CH6 LO
■ ■
14 CH6 HI
■ ■
13 CH5 LO
■ ■
12 CH5 HI
■ ■
11 CH4 LO
■ ■
10 CH4 HI
■ ■
9 CH3 LO
■ ■
8 CH3 HI
■ ■
7 CH2 LO
■ ■
6 CH2 HI
■ ■
5 CH1 LO
■ ■
4 CH1 HI
■ ■
3 CH0 LO
■ ■
2 CH0 HI
■ ■
1 LLGND
11
