Mechanical

Vibration
Dimensions
Weight

Main connector and pinout

Connector type
Compatible cables (for the 68-pin
SCSI connector)
Compatible accessory products
Pin
Function
68
ACH0
67
AGND
66
ACH9
65
ACH2
64
AGND
63
ACH11
SGND (low level sense – not for general use)
62
61
ACH12
60
ACH5
59
AGND
58
ACH14
57
ACH7
56
NC
55
NC
54
NEGREF (reserved for self-calibration)
53
GND
52
A1
51
A3
50
A5
49
A7
48
B1
47
B3
46
B5
45
B7
44
C1
43
C3
42
C5
41
C7
40
GND
39
CNT1
38
CNT3
37
TMR1
36
GND
35
GND
Table 11. Mechanical specifications
MIL STD 810E cat 1 and 10
165 mm (W) x 15 mm (D) x 108 mm (H) (6.5‖ x 0.6‖ x 4.2‖)
160 g (0.35 lbs)
Table 12. Main connector specifications
68-pin standard "SCSI TYPE III" female connector
HDMI connector (targeted for future expansion)
CA-68-3R — 68-pin ribbon cable; 3 feet.
CA-68-3S — 68-pin shielded round cable; 3 feet.
CA-68-6S — 68-pin shielded round cable; 6 feet.
TB-100 termination board with screw terminals
RM-TB-100, 19-inch rack mount kit for TB-100
Table 13. 16-channel single-ended pinout
Pin
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
40
Function
ACH8
ACH1
AGND
ACH10
ACH3
AGND
ACH4
AGND
ACH13
ACH6
AGND
ACH15
NC
NC
POSREF (reserved for self-calibration)
+5 V (refer to
Note
4)
A0
A2
A4
A6
B0
B2
B4
B6
C0
C2
C4
C6
TTL TRG
CNT0
CNT2
TMR0
XAPCR (input scan clock)
XDPCR (output scan clock)
