SubC Imaging DVRO User Manual page 39

AUTOMATIC OVERLAYS
Date and Time
1. Date and Time
Date: Check this box to show the date on your footage.
Time: Check this box to show the time on your footage.
If desired, modify yyyy/MM/dd
The clock is that of the DVR and can be adjusted via the clock on the Windows taskbar.
2. Display Format
With this group of settings, you can further customize how your date/time overlay looks and its position
on the screen. See Appearance and Positioning Options for details.
3. To Front/To Back
Send the overlay to the front or back of the back-to-front-ordering. Overlays closer to the front of the
order cover up those closer to the back of the order. For example, you can use this positioning to easily
place the current time on top of a custom graphical background.
4. Reset
Clears all settings preset in the current overlay.
and HH:mm:ss to your preferred date and time format.
Page 39
1
1
3
4
7 7
2
3
4
Typical appearance:
2
5
8
