STATIC OVERLAYS
Shapes
The Shape Overlay allows you to place a shape on the video. Several varieties of shapes are available, including
rectangles and ellipses. Among other things, these can be used to supply a uniform background to a group of
other overlays or used to cover up specific segments of a video when recording from an unvarying position.
1. Shape
Select the shape you wish to use.
2. Width/Height
Select the width and height of your shape. It will stay snapped to your anchor point.
3. Fill Color
Select the color to fill the area of the shape.
4. Border Color/Thickness
Select the color and thickness of the border around the shape. The border is drawn towards the inside from the
edge. For no border, set thickness to 0 or negative.
5. Display Format
Further customize how your shape overlay looks and its position on the screen. See Appearance and
Positioning Options for details.
6. To Front/To Back
Send the overlay to the front or back of the back-to-front-ordering. Overlays closer to the front of the order
cover up those closer to the back of the order.
7. Reset
Clears all settings preset in the current overlay.
Page 37
2
1
3
5
2
8
4
7 7
3
4
5
6
7
Examples:
