SubC Imaging DVRO User Manual page 34

OVERLAY MANAGEMENT
WWW Streaming - Display
Add, save, load, hide, and show your overlays here. Videos must be initialized in order to see the
effects of their overlays.
1. Add - Allows you to add a new custom overlay of your choice. Select the type from the dropdown menu
(2). Overlays are added first, then configured.
2. Overlay Types - This dropdown menu displays a list of available overlays. Add the selected overlay by
pressing the Add button (1). Multiple overlays of the same type may be chosen.
3. Save - Saves all overlays that have been created and stores them in a file to be reused in the future.
4. Load - Loads overlays that have been previously saved.
5. Replicate - The overlays displayed in the current active video input will be displayed in all initialized
video inputs.
6. Hide All - Suppresses all overlays on the current video input, allowing you to suspend the application of
your overlays without deleting them (e.g. to take a frame grab of your unadorned video feed).
7. Show All - Reapplies the overlays that were suspended with Hide All (6).
8. Clear - Deletes all overlays for the current video. Be aware that any unsaved overlays will be lost when
choosing this option.
Page 34
1
1
3
3 3 3
6
6 6
7
4
7 7
2
2
5
5
8
8
