Motoalliance Denali Plows MA11743 Manual

23001 Industrial Blvd, Rogers, MN 55374 / 1-866-527-7637

Denali PLOW MOUNT

Thank you for purchasing our Denali plow mount(s). You now own a premium,

custom plow mount to allow you to use your plow with your SxS. Please note the

following instructions and heed all warnings.

• Your UTV/SxS and/or plow system can cause death or injury, please use

caution and common sense when operating your unit.

• Read your Plow Operator's Manual, your Winch Operator's Manual, and all

warning labels before operating your UTV/SxS.

• Operate your SxS at a walking speed with the blade installed. Do not

exceed 5 mph (8 km/h) even with the blade up.

• Do not operate the UTV/SxS on slopes greater than 10 degrees with the

plow installed.

• Always lower the plow to the down position before leaving your UTV/SxS

unattended.

SEVERE INJURY OR DEATH MAY RESULT IF YOU ARE NEGLIGENT.

866.527.7637

www.motoalliance.com

MA11743

Can Am Maverick Trail/Sport

motoinfo@motoalliance.com

Table of Contents

Need help?

Do you have a question about the Denali Plows MA11743 and is the answer not in the manual?

Page 1 23001 Industrial Blvd, Rogers, MN 55374 / 1-866-527-7637 www.motoalliance.com Denali PLOW MOUNT MA11743 Can Am Maverick Trail/Sport Thank you for purchasing our Denali plow mount(s). You now own a premium, custom plow mount to allow you to use your plow with your SxS. Please note the following instructions and heed all warnings.
Page 2 MotoAlliance MA11743 23001 Industrial Blvd Rogers, MN 55374 866.527.7637 Please verify that all hardware and parts are included in your package. Kit Content: Please refer to Figure 1 Item Description MA11743-W1 Plow Mount MA11743-3 MA11743-4 3/8” Flat Washer 3/8”-16 x 3.75 Hex Head Bolt 3/8”-16 Nylock Nut...
Page 3 MotoAlliance MA11743 23001 Industrial Blvd Rogers, MN 55374 866.527.7637 MA11741 Plow Mount Installation 1. Hang the MA11743-3 and MA11743-4 brackets on the frame as shown in Figure 2. Align the front hole of MA11743-3 with the front hole on the frame. Align the hole in MA11743-4 with the back hole on the frame.
Page 4 MotoAlliance MA11743 23001 Industrial Blvd Rogers, MN 55374 866.527.7637 3. Use the provided 3/8”-16 x 1.5” Serrated Flange Bolts and Serrated Flange Nuts to secure the bottom of the MA11743-3 brackets to the MA11743-W1 mount plate. Figure 4 4. Use the pins supplied with your Denali Plow System to attach the plow to the mount.
