23001 Industrial Blvd, Rogers, MN 55374 / 1-866-527-7637

MOTOALLIANCE PLOW MOUNT

Thank you for purchasing our MotoAlliance plow mount. You now own a premium

custom plow mount allowing you to use your plow with your SxS. Please note the

following instructions and heed all warnings.

• Please use common sense when operating your SxS

• Be observant of moving parts causing entanglement use extreme caution!

SEVERE INJURY OR DEATH MAY RESULT IF YOU ARE NEGLIGENT.

866.527.7637

www.motoalliance.com

MA11765

CFMOTO U-Force

motoinfo@motoalliance.com

Table of Contents

Need help?

Do you have a question about the MA11765 and is the answer not in the manual?

Page 1 MOTOALLIANCE PLOW MOUNT MA11765 CFMOTO U-Force Thank you for purchasing our MotoAlliance plow mount. You now own a premium custom plow mount allowing you to use your plow with your SxS. Please note the following instructions and heed all warnings.
Page 2 Please verify that all hardware and parts are included in your package. Kit Content: Item Number Description Quantity MA11765 Main Mounting Plate MA11765-4 Rear Support Bracket 3/8"-16 x 1.00" Serrated Flange Bolt 3/8"-16 Serrated Flange Nut Figure 1 1. Begin by removing the front fascia from the bumper.
Page 3 Figure 2 and set aside for future use. Figure 2 3. Slide the front lip of the MA11765 mount over the front frame crossmember as shown in Figure 3. The mount will remain in place if pushed on fully.
Page 4 4. Hang the two MA11765-4 Rear Support Brackets over the side chassis members toward the rear of the MA11765 Main Mounting Plate as shown in Figure 4. Insert 3/8’’ x 1’’ Serrated Flange Bolts from the top of the Support Brackets and loosely thread the Serrated Flange Nuts on the bolts.
Page 5 23001 Industrial Blvd Rogers, MN 55374 866.527.7637 6. Verify that the MA11765 Main Mounting Plate is pressed firmly to the rear of the vehicle so that the front lip of the MA11765 bracket is against the front crossmember of the vehicle frame.
