- Page 1 CFMoto ZForce 950 Cab Heater HT_CU_469 I N S T A L L A T I O N I N S T R U C T I O N S www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
-
Page 2: Parts List
5-Pin Black Connector Plastic Shut-Off Valve 3-Position Switch 4-Pin White Connector 50mm Vent HT_CU_469-1 Heater Bracket 10" 2" Compressed Duct Hose Hardware Pack 24" 2" Compressed Duct Hose M6-1x18 Hex Bolts Hole Saw Pilot Bit www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN... - Page 3 There are Phillips head screws located on the cab side of the dash. Remove the upper dash. FIGURE 1 Remove plastic rivets on the side of the upper dash to get access to the screws. Remove the bolts on the contactor. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
-
Page 4: Radiator Hose
11. Place the heater unit back into the center cavity and run the radiator hose through the rubber grommets. 12. Run one 5' radiator hose section to the upper factory radiator hose. 13. Run the second 5' radiator hose section to the lower factory radiator hose. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN... - Page 5 Y with the branch facing the front of the machine. Secure using #16 hose clamps. FIGURE 3 15. Run one of the 5' radiator hose sections to the branch of the aluminum Y, cut any excess hose, and secure using a #10 hose clamp. FIGURE 3 www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
- Page 6 17. Run the second 5' radiator hose section to the branch of the aluminum Y, cut any excess hose, then secure using a #10 hose clamp. FIGURE 4 18. Locate an accessible area on the hose running from the heater to the upper factory radiator hose. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
-
Page 7: Switch Wiring
SWITCH WIRING 20. Locate the 36” wiring harness and ensure the wires are correctly connected to the 5-pin black connector as shown in and the 4-pin white connector as shown in FIGURE 6 FIGURE 7 www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN... - Page 8 This can be found by testing wires with a multimeter. 28. Connect the black wire to the negative battery terminal. 29. Test the switch to ensure that it can control the fan speed in all three positions. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
- Page 9 32. Connect the 5" compressed duct hoses to the bottom vent ports on the heater, toward the cab, and secure using zip ties. FIGURE 9 www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
-
Page 10: Vent Installation
FIGURE 10 34. Debur the holes and insert the 50mm vents. 35. Connect the 5" compressed duct hose sections from the bottom vent ports on the heater to the 50mm vents and secure using zip ties. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN... - Page 11 The following procedure is most easily accomplished with the help of a partner. Look at owner's manual for manufacturer- 39. Fill radiator with coolant until radiator is full. approved coolant 40. Open the shutoff valve. www.motoalliance.com motoinfo@motoalliance.com 866.527.7637 Rogers, MN...
-
Page 12: Replacement Parts
46. Use the two self-tapping screws to secure the HT_CU_469-1 heater bracket to the center console. 47. Reinstall the contactor, upper dash, and front hood. REPLACEMENT PARTS Replacement parts can be ordered from motoalliance.com. Enter the associated SKU number into the search bar to find the product. Item Description Item Description 2"...
