Thank you for choosing the Prime Vision ISF fixed frame projection screen! The Prime Vision ISF Series
by EPV Screens® leads the industry in quality fixed frame projection screens. Its design features a
lightweight aluminum frame with velvet coating that frames its ISF Certified ChromaWhite screen
material. The ChromaWhite is specially formulated to provide diffusion uniformity with accurate color
reproduction for a flat spectral response in a controlled room environment.
Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure
a long product life.
In order for the ChromaWhite to maintain its projection qualities and optimum performance please refer to the list
below for proper maintenance and cleaning.
Care & Use Instructions: Dust, dirt and scratches on the projection surface will affect the picture quality,
please take note of the points below to prevent that from occurring:
Use a dry microfiber cloth to remove dust from the screen's surface.
• Do not write or draw on the projection surface
When cleaning, use a damp microfiber cloth with warm water to remove any marks.
Never rub or apply pressure when cleaning the surface.
Never attempt to use any solutions, chemicals, or abrasive cleaners on the screen surface.
To avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any other
sharp or abrasive objects.
05232022JA
Prime Vision ISF Series
Matte White Fixed Frame Screen
www.epvscreens.com
USER'S GUIDE – M Type
U-00221
V 2.0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Prime Vision ISF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EPV Prime Vision ISF Series

  • Page 1 USER’S GUIDE – M Type V 2.0 Thank you for choosing the Prime Vision ISF fixed frame projection screen! The Prime Vision ISF Series by EPV Screens® leads the industry in quality fixed frame projection screens. Its design features a lightweight aluminum frame with velvet coating that frames its ISF Certified ChromaWhite screen material.
  • Page 2 Frame Parts List A. Vertical Frame x 2pcs B. ½ Horizontal Frame x2 pcs C. ½ Horizontal Frame x 2 pcs Hardware Parts List M4*4 D5*4 M4*4 D5*4 Black 110” 120” 135” 150” 138” 158” Item Parts List 2.35:1 16:9 Center Joints- M4 (bottom position) Center Joints-D5 (top position) Elbow Joints M4 (bottom position)
  • Page 3: Frame Assembly

    Frame Assembly Step 1: Place the EPE sponge (foam) sheet on the ground of the area where the screen will be assembled. Step 2: Position the pieces of the frame on the EPE sponge in the arrangement shown below. Step 3: Insert center joint (a/b) connectors into one-half of the horizontal frame (B/C) and secure with the M4x7 screws (g) as shown in the illustration below.
  • Page 4 Step 5. Secure the elbow joints by fastening them with M4x7 screws (g), 4 at each corner. Screen Material Step 6: Put on the white gloves (p) and carefully unroll the screen material on a clean surface from the roller to the other side as shown below.
  • Page 5: Back Side

    Step 8: Insert the rods (r) through the sleeves according to their corresponding lengths on each edge of the screen as shown below. The short rods (top/bottom) will overlap to secure a firm grasp in the middle areas. (Black tips) Back Back Side Side...
  • Page 6 First connect on four corners, steps 1-4. make sure all four corners are fixed before proceeding with next spring. Continue to attach the remaining springs to the material in steps 5-12 in the follow order. 05232022JA www.epvscreens.com U-00221...
  • Page 7: Installation

    Step 10: Insert the Center Support Bar (o) into the upper top groove on the back of the frame with the bottom end near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment with the groove.
  • Page 8 Step 12: Position the fixed frame screen onto the top wall brackets (fig 1) as shown below and push down at the center of the top of the frame (fig 2) to secure. For Technical Support or an EPV Screens contact in your area, visit www.epvscreens.com...
