Matte White Fixed Frame Projection Screen
Prime Vision ISF Series
Thank you for choosing the Prime Vision ISF fixed frame projection screen!
EPV Screens® leads the industry in quality fixed frame projection screens. Its design features a 2.4" wide
frame with velvet coating that frames its ISF Certified ChromaWhite screen material. The ChromaWhite is
specially formulated to provide diffusion uniformity with accurate color reproduction for a flat spectral
response in a controlled room environment.
Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a
long product life.
Care & Use Instructions: Dust, dirt and scratches on the projection surface will affect the picture
quality, please take note of the points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface.
4. Use clean water when dampening the cleaning cloth and do not rub against the material.
5. Do not use chemical cleaning agents or alcohol to clean the screen material.
Hardware and Parts List
A. Frame Parts x 6 pcs
(4 top/bottom frame pcs + 2 side frame pcs)
B. ChromaWhite Screen Material x 1 pc
C. Center joint x 2 pcs
D. Elbow Joint x4 pcs
E. Wall bracket x 4 pcs
F. Wood screw x 8 pcs
G. Hollow wall anchor x 8 pcs
Note: Please make sure all parts are included in your package before assembling your Prime Vision ISF
fixed frame projection screen.
JA-022818
User's Guide
H. M5x15 screw x 16 pcs
I. Center Support Bar x 1 - 2 pcs
(depending on model/size)
J. Support joiner x 2 - 4 pcs (depending on model/size)
(Install into the support bar before shipment)
K. Fix Plates x 60 - 180 pcs
(depending on model/size)
L. Rubber mallet x 1 pc
M. Screw driver x 1 pc
www.EPVscreens.com
The Prime Vision ISF Series by
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EPV Prime Vision ISF Series
Summary of Contents for EPV Prime Vision ISF Series
- Page 1 Thank you for choosing the Prime Vision ISF fixed frame projection screen! EPV Screens® leads the industry in quality fixed frame projection screens. Its design features a 2.4” wide frame with velvet coating that frames its ISF Certified ChromaWhite screen material. The ChromaWhite is specially formulated to provide diffusion uniformity with accurate color reproduction for a flat spectral response in a controlled room environment.
- Page 2 FRAME ASSEMBLY 1. Insert the center joint (c) connector to the horizontal frame piece with bevel connection and flat head, and then fasten it with two M5x15 screws (h). ½ Long Frame M5x15 Screw bevel connection Flat head 2. Insert the other horizontal frame piece to the center joint connector and then fasten it with two M5x15 screws.
- Page 3 Push Push Short frame Short frame (Fig.1.1) Screw M5×15Screws (Fig.1.2) ( fig.3) Join all four frame parts together following the steps shown below. (Fig.2) Note: When assembled, please push simultaneously the two ends of the long frames. Insert the exposed ends of the joint connectors into the short (vertical) frame and align the four corners so that they meet at perfect right angles Push...
- Page 4 Attaching the Screen Material to the Frame 1. Make sure the screen material and frame are both lying face down on a clean, dry, and non-abrasive surface. 2. Carefully unroll the material inside the frame. (Fig.3) Please note the material will be noticeably smaller than the frame, as the material must be stretched to create a sufficient amount of tension for perfect material flatness.
- Page 5 Tip for attaching the last corner (D): 1. Position yourself left of location ①. ③ 2. Pull the material to the corner of the frame with your hand while your left Pull hand snaps in the fix plate on location ① (the third red dot). ④...
- Page 6 Center Support Bar Installation Insert the Center Support Bar into the upper top groove on the back of the frame (not the one where the fix plate inserts) with the bottom end near the approximate center point of the frame and rotate it in at an angle so that both ends of the bar are in alignment with the groove (see Fig.
- Page 7 Installation 1. Locate your desired installation location with a stud finder (recommended) and mark the drill-hole area of where the screen is to be installed. 2. Drill a hole with the proper bit size according to the wood screws included. 3.
