EPV Twilight Electric Series User Manual

Outdoor electric projection screen for 100” and 120” models
Hide thumbs Also See for Twilight Electric Series:
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
_________________________________________________________
Thank you for choosing the Twilight Electric projection screen! Please read through this user guide before utilizing
the screen. Correct usage and maintenance will ensure a long product life.
Product Description:
The Twilight Electric is an outdoor projector screen for wall and patio installations that brings media room quality
to your outdoor spaces. Its sleek aluminum casing beautifully accessorizes your backyard, patio, pool deck or
anywhere a gathering for evening movie time is appropriate.
Outdoor Projection Screen Disclaimer
Never leave your projection screen out and exposed to direct sunlight. Regardless of screen brand, prolonged
exposure to the sun's ultraviolet radiation degrades the chemical bonds causing the material to ultimately
decompose. Photo degradation first causes the material to lose its theater-grade reflective qualities. Eventually
nature will destroy even synthetic materials. For this reason, the Twilight Electric has a retractable design that
allows the material to be drawn up into its protective casing to be shielded from solar radiation.
Care & Use Instructions
◆ Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points
below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆To avoid damage and injury, the screen should only be operated by adults.
Rev.03242022JA
Twilight Electric Series
Outdoor Electric Projection Screen
www.epvscreens.com
For 100" and 120" models
User's Guide
1 | S\N: 203E +

Advertisement

loading
Need help?

Need help?

Do you have a question about the Twilight Electric Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EPV Twilight Electric Series

Summary of Contents for EPV Twilight Electric Series

  • Page 1 Twilight Electric Series Outdoor Electric Projection Screen For 100” and 120” models User’s Guide _________________________________________________________ Thank you for choosing the Twilight Electric projection screen! Please read through this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life.
  • Page 2 Understanding the Ingress Protection Rating IP33 Important Safety & Warning Precautions Make sure to read this user’s guide and follow the procedures below. • Please retain this user’s guide for future reference. • To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the manufacturer.
  • Page 3 The installer must ensure that the fasteners used are of adequate strength and suitable for the installation location. Hardware Parts List for Twilight Electric Series E. M5x15 Screw&...

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS Flush Mount to the Wall 1. Mark the location of where the screen is to be installed, drill your holes and insert the M10Anchors (B). 2. Install the Mounting Brackets (A) to the wall and secure with the M4x50 Screws (B). Mounting Bracket Mounting bracket Fix Plate 1...
  • Page 5 Flush Mount to the Ceiling Note: Please make sure the Mounting Bracket (A) is close to the wall when you install the screen on the ceiling. This is to ensure the weight bar aligns with the magnetic bottom bracket when it comes down. 1.
  • Page 6 Tab and remove the bottom case away from the wall/ceiling followed by the top of the case. Twilight Electric Control System and Operation Twilight Electric Series Controls A. RF Remote Control x1 pc (Battery built-in) B. Wireless trigger x1pc Screen operation Electric Current: 110v.
  • Page 7 2. Wireless trigger (Item B): The wireless trigger allows your screen to synchronize its drop/ rise operation with the projector’s power cycle. [CODE] Button [SET] Button LED indicator light Projector [CODE] Button: For programming the receiver [SET] Button: For setting the trigger feature AC power input 120VAC 60Hz (Optional 220VAC 50Hz)
  • Page 8 Magnetic bottom bracket Installation 1. After the screen is plugged in to a power outlet, press the DOWN button on the RF remote control (F). Install the magnetic bottom bracket (G) so that the weight bar sleeve cradles inside (see picture below). Note: The screen should deploy straight down and align with the magnetic bottom bracket (G).
  • Page 9 Curved Nail (H) to secure screen to the ground and supply adequate tension to the screen. Iron Ring Hook Elastic String Curved Ground Stake For more information, technical support or your local EPV Screens contact, www.epvscreens.com please visit Rev.03242022JA www.epvscreens.com 9 | S\N: 203E +...
