PRODUCT WHITE PAPER
Section 1: Material Design
1.1
What is it for?
The Polar Max Tension is an electric retractable projection screen that utilizes our award
winning, ISF-Certified Polar Star™ ambient light rejecting material. A full IR and RF remote
control kit is included along with a 12volt projector trigger. The retractable design provides a
big screen performance without dedicating wall space to exclusively one purpose, enabling
the viewer to enjoy greater versatility with a disappearing screen when not in use.
1.2
How does it work?
The Polar Max Tension includes a tab-tensioning system that provides a flat, taut surface. The
Polar Star material is a reference quality front projection material precisely formulated for
environments with minimal control over room lighting. It was designed to enhance picture
brightness, offer accurate color fidelity, and improve contrast levels. The Polar Star is best for
family rooms, educational facilities, conference rooms or any applications in which incident
light is a factor.
Section 2: Product Features
2.1
Characteristics
Screen Material
• Polar Star 1.3 Gain Ambient Light Rejecting Material
• Excellent contrast enhancement, color saturation, brightness retention
• Black borders absorb projector over scan while enhancing visual contrast
• 4K/8K Ultra HD, Active 3D, HDR Ready
• ISF Certified for Accurate Color Fidelity
Design and Installation
• Floating brackets permit flush wall or ceiling installation
• Suspended ceiling capable with included hardware
• Tab-tension system provides a flat and taut projection view surface
Control System
• Internal Radio Frequency/Infrared receivers with IR, RF remotes included
• Infrared IR "eye" extension sensor - ideal for concealed installation but still require Infrared
control
Elite Screens Inc. |Elite Screens Europe GmbH | Elite Screens France S.A.S. | Elite Screens India| Elite Screens Japan
Elite Screens China Ltd. | Elite Screens Taiwan Corp. | Elite Screens Australia
http://www.EPVscreens.com
¡ ¢ £ ¤ § £ ¥ © ¦ ¨ ¨
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EPV PMX92HT2-E12
Summary of Contents for EPV PMX92HT2-E12
-
Page 1: Section 1: Material Design
PRODUCT WHITE PAPER http://www.EPVscreens.com ¡ ¢ £ ¤ § £ ¥ © ¦ ¨ ¨ Section 1: Material Design What is it for? The Polar Max Tension is an electric retractable projection screen that utilizes our award winning, ISF-Certified Polar Star™ ambient light rejecting material. A full IR and RF remote control kit is included along with a 12volt projector trigger. -
Page 2: Model Numbers
Gain Dimensions Numbers Size Ratio Material (lbs) (lbs) (inches) (inches) (LxWxH) 16:9 44.9 79.9 Polar Star™ 41.9 60.2 109.1"x8.9"x7.7" PMX92HT2-E12 92" 16:9 52.0 92.3 Polar Star™ 45.9 67.1 121.1"x8.9"x7.7" PMX106HT2-E12 106" 16:9 58.9 104.5 Polar Star™ 51.1 72.8 133.5"x8.9"x7.7" PMX120HT2-E12 120"... - Page 3 PRODUCT WHITE PAPER http://www.EPVscreens.com Features & Benefits • Gain: 1.3 • View Angle: 70° (35° ±LR) • Super color balance, produced film-like quality presentations • Polarized for Passive 3D applications • Active 3D and 4K Ultra HD Ready • Certified by the Imaging Science Foundation (ISF) Specifications Thickness 0.35 mm...
-
Page 4: Section 4: Execution
PRODUCT WHITE PAPER http://www.EPVscreens.com Section 4: Execution Important Safety & Warning Precautions Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black Top Drop in the roller. Please be aware of this as it will void your warranty with Elite Screens. Unapproved changes or modifications (except for cutting the power cord for hardwire installations) to this unit are prohibited and will void your warranty. -
Page 5: Pre-Installation
PRODUCT WHITE PAPER http://www.EPVscreens.com Pre-Installation 1. Carefully unpack the screen. 2. Always handle the screen in a leveled position on a clean surface. 3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign particles such as dust, sawdust, and/or liquids Installation Warning Due to various installation environments, the instructions provided in this user’s guide are for... -
Page 6: Notice To Installer
PRODUCT WHITE PAPER http://www.EPVscreens.com Hardware Parts List Please make sure all parts listed below are included before proceeding with the installation. B. Screwdriver x 1 C. Steel Expansion D. Plastic expansion A. Pair of Bracket Concrete Anchor x 8 dry-wall anchor x 8 E. -
Page 7: Installation Instructions
PRODUCT WHITE PAPER http://www.EPVscreens.com Installation Instructions A. Wall Mount I. Flush mount Side view Screen-to-wall installation Elite Screens Inc. |Elite Screens Europe GmbH | Elite Screens France S.A.S. | Elite Screens India| Elite Screens Japan Elite Screens China Ltd. | Elite Screens Taiwan Corp. | Elite Screens Australia... -
Page 8: Ceiling Mount
PRODUCT WHITE PAPER http://www.EPVscreens.com 1. Determine where the screen will be installed. Then, measure and mark the distance between the top and bottom screw holes from each bracket. 2. Drill a hole on all marked areas and install the brackets on the wall with the screws. Lift the screen up leveled with the brackets, slide the screen in the bracket grooves and push until you hear a “click”... -
Page 9: Operation
PRODUCT WHITE PAPER http://www.EPVscreens.com C. Hidden Mount 1. Refer to the installation procedures for wall mount or ceiling mount for instructions. Standard Accessories A. RF remote B. IR remote C. Extended IR D. 5-12 volt sensor tirgger Operation Electric current: The screen may operate on 100V/110V/220V depending on region. Caution: The screen’s motor is equipped with a thermal heat protector which will cause the motor to stop running and prevent overheating if it is in continuous use for more than four minutes. - Page 10 PRODUCT WHITE PAPER http://www.EPVscreens.com Press the Down button to Drop the screen Press the Stop button to Stop the screen Press the UP button to Retract the screen How to program your RF remote to your screen Press and hold the UP button Stop pressing the UP button upon The receiver will beep hearing a beeping sound.
- Page 11 PRODUCT WHITE PAPER http://www.EPVscreens.com 4. 5-12 volt trigger: Connect the mini jack plug end to the 5-12 volt trigger port (see image above) and the other end to your projector’s output port to synchronize the projector’s power cycle to your screen.
-
Page 12: Section 5: Product Specifications
Model Number Length Distance Width Width Height Height Height Border Diagonal Border (A1) (A2) (A3) (A4) (B1) (B2) (B3) (B4) PMX92HT2-E12 92.0 100.4 76.8 90.9 79.9 94.5 65.1 59.2 44.9 12.0 PMX106HT2-E12 106.0 112.8 89.2 103.3 92.3 106.9 72.2 66.3 52.0... - Page 13 Model Number Length Distance Width Width Height Height Height Border Diagonal Border (A1) (A2) (A3) (A4) (B1) (B2) (B3) (B4) PMX92HT2-E12 2337 2550 1950 2310 2030 2400 1653 1503 1140 PMX106HT2-E12 2692 2865 2265 2625 2345 2715 1833 1683 1320...
- Page 14 PRODUCT WHITE PAPER http://www.EPVscreens.com & ' & ' $ % $ ! " # # Elite Screens Inc. |Elite Screens Europe GmbH | Elite Screens France S.A.S. | Elite Screens India| Elite Screens Japan Elite Screens China Ltd. | Elite Screens Taiwan Corp. | Elite Screens Australia...
- Page 15 PRODUCT WHITE PAPER http://www.EPVscreens.com Pictures Life Style Elite Screens Inc. |Elite Screens Europe GmbH | Elite Screens France S.A.S. | Elite Screens India| Elite Screens Japan Elite Screens China Ltd. | Elite Screens Taiwan Corp. | Elite Screens Australia...
-
Page 16: Section 6: About Elite Prime Vision
PRODUCT WHITE PAPER http://www.EPVscreens.com Section 6: About Elite Prime Vision Company Description Elite Prime Vision, a division of Elite Screens, is dedicated to delivering superior and outstanding products for the custom install and system integration markets. The proprietary product line features a broad, comprehensive range of electric and fixed-frame projection screens in a wide variety of premium, innovative surface materials.
