Twilight Portable Series
Outdoor/Indoor Portable Projection Screen
Thank you for choosing the Twilight Portable projection screen! Please read this user guide before
utilizing the screen. Correct usage and maintenance will ensure a long product life
Care & Use Instructions
◆ Elite highly recommends two people to assemble the Yard Master Pro screen.
◆ Please be sure to distinguish between the front and back of the screen fabric when setting up the
projection screen. CineWhite® UHD (front projection) and Wraith Veil (rear projection) are both labeled
front, back.
◆ Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the
points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or
alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble it and store it in the carrying bag provided.
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Screen Fabric: The screen fabric is attached to the rectangular frame and held in place by several pegs
along the frame, which ensure an evenly stretched and flat surface. The CineWhite® UHD (front
projection) and WraithVeil (rear projection) screen materials are durable and can be folded many times
without causing damage or distortion to the surface.
JA06122018
150"/180" Models
User's Guide
1
www.epvscreens.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EPV POD180H-EPV
Summary of Contents for EPV POD180H-EPV
- Page 1 Twilight Portable Series 150"/180" Models Outdoor/Indoor Portable Projection Screen User’s Guide Thank you for choosing the Twilight Portable projection screen! Please read this user guide before utilizing the screen. Correct usage and maintenance will ensure a long product life Care & Use Instructions ◆...
- Page 2 Twilight Portable Frame Parts and Hardware A. Folding frame x1 B. Left and right folding legs x2 C. Center Support Leg x1 (180” models only) D. Projection screen material x2 E. Screen material bag x2 F. Carrying Bag x1 CineWhite® UHD (front projection) Wraith Veil (rear projection) G.
- Page 3 2. Next, unfold the horizontal sections by separating and pulling the left and right sides outwards. Note: When unfolding the frame and legs, be sure the latches on the hinges "click" into place. Please also make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not bent. Screen Material Attachment 3.
- Page 4 Leg Attachment 4. Carefully take the left and right folding legs (B) out of the carrying bag (F) and place it on a flat surface. Unfold the left and right legs completely as shown. Warning: The additional support sections, located at the middle section of the legs, may unfold on its own. Please be sure to use caution while removing/placing the legs from/to the bag This step is for 180"...
- Page 5 7. Attach the ropes and rings (G) to each side of the legs at the top of the frame (1 at each eye and loop). 8. At least two people are needed for this step. Open the front side of each folding leg (B) and carefully lift the top of the frame to stand up the screen.
- Page 6 Screen Disassembly 1. Remove ropes (G) and stakes (H) from the ground. 2. At least two people are needed for this step. Unscrew the knob screws (I) on the back sections of the legs and fold the hinges so that half of the legs are folded up. Slowly lower the screen to the ground (towards the closed legs).
- Page 7 Be sure to place folding frame, legs, and smaller parts into the carrying bag first and place the material on top to keep material from creasing or tearing. For more information, technical support or your local EPV Screens contact, please visit www.epvscreens.com...
