- Page 1 Electrically Heated Sample Probe Tube ® Series SP SP 30-H../EX2 for Operation in Ex-Zone 2 Instruction Manual Version 1.02.00...
- Page 2 Dear customer, Thank you for buying our product. In this manual you will find all necessary information about this M&C product. The information in the manual is fast and easy to find, so you can start using your M&C prod- uct right after you have read the manual.
-
Page 3: Table Of Contents
Content General information ........................4 Declaration of conformity ......................4 Electrical standards ........................5 Safety instructions ........................5 Information and safety instructions for using the tube in hazardous areas ......6 Warranty ............................6 Used terms and signal indications .................... 7 Application .......................... -
Page 4: General Information
Head Office M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany Telephone: 02102 / 935 - 0 Fax: 02102 / 935 - 111 E - mail: info@mc-techgroup.com www.mc-techgroup.com GENERAL INFORMATION The product described in this instruction manual has been built and tested in our production facility. All M&C products are packed to be shipped safely. -
Page 5: Electrical Standards
ELECTRICAL STANDARDS The electrical standard of electrical equipment corresponds to the safety regulations concerning the EN 60079-15, EN 61010 and the directive 2014/34/EU (equipment group 3 in hazardous areas); Producer : M&C TechGroup Germany GmbH Rehhecke 79 40885 Ratingen Germany SAFETY INSTRUCTIONS Follow these basic safety precautions during installation, commissioning and operation of the device:... -
Page 6: Information And Safety Instructions For Using The Tube In Hazardous Areas
INFORMATION AND SAFETY INSTRUCTIONS FOR USING THE TUBE IN HAZARDOUS AREAS The electrically heated tube is suitable for using in hazardous area category 3G. The explosion proof protection is: II 3G Ex nA IIC temperature class T5 to T2 (temperature class corresponding to your order). Installation and operation have to be done corresponding to the manual. -
Page 7: Used Terms And Signal Indications
USED TERMS AND SIGNAL INDICATIONS This means that death, severe physical injuries and/or important material damages will occur in case the respective safety measures are not fulfilled. D AN G E R ! This means that death, severe physical injuries and/or important material damages may occur in case the respective safety measures are not fulfilled. -
Page 8: Application
Wear protective gloves! Working with chemicals, sharpe objects extremly high temperatures requires wearing protective gloves. Wear safety glasses! Protect your eyes while working with chemicals or sharpe objects. Wear safety glasses to avoid getting something in your eyes. Wear protective clothes! Working with chemicals,... -
Page 9: Temperature Controller
The internal diameter of the version SP30-H1.1-V/EX2 is reduced to 6 mm to optimize the tube dead volume. The sample tubes SP30-H1.1/EX2 and SP30-H1.1-V/EX2 have a temperature sensor Fe-CuNi for max. 320 °C [608 °F] operating temperature. Figure 1 Dimensions SP30-H../EX2 Figure 2 SP30-H1.1-V/EX2 TEMPERATURE CONTROLLER... -
Page 10: Technical Data
TECHNICAL DATA ® Serie SP SP30-H1.1/EX2 SP30-H2/EX2 SP30-H1.1-V/EX2 Temperature sensor Fe-CuNi PT100 2-wire Fe-CuNi Temperature controller external max. 1 m [39.37“] Probe tube length L1 Sample temperature depending on the temperature class (see table temperature class). Please specify with order. Operating temperature depending on the temperature class (see table temperature class). -
Page 11: Preparation For Installation
PREPARATION FOR INSTALLATION Select the optimum sampling point according to the generally applicable guidelines or consult the responsible authorities. Locate the sampling point in such a way that there is adequate space for inserting and removing the probe and pay attention to the insertion length of the probe tube. Make certain that the probe is easily accessible so that you can carry out any subsequent maintenance work without trouble. -
Page 12: Electrical Connections
Figure 3 Mounting of the heated sample tube SP30-H../EX2 ELECTRICAL CONNECTIONS When connecting the equipment, please ensure that the supply voltage is identical with the information provided on the model type W A R N I N G ! plate. Attention must be paid to the requirements of IEC 364 (DIN VDE 0100) when setting high-power electrical units with nominal voltages of up to 1000 V, together with the associated standards and... -
Page 13: Electrical Connection Of The Heated Sample Tube
13.1 ELECTRICAL CONNECTION OF THE HEATED SAMPLE TUBE The used cables for the connection of the heating must have an outer diameter of 6-12 mm corresponding to the clamping range of W A R N I N G ! the cable glands! The max. -
Page 14: Starting
STARTING Before starting up check whether the mains power supply voltage corresponds with the information stated on the nameplate. W A R N I N G ! Start up only the built-in heated probe tube because otherwise W A R N I N G ! there is a risk of burning! Check whether the housing of the heating controller and the connection box of the heated sample tube are earthed. -
Page 15: Maintenance
MAINTENANCE The safety instructions specific to the plant and process are to be consulted prior to any maintenance work! W A R N I N G ! Caution, danger of explosion! D A N G E R ! Under voltage do not take the device off the mains! When working during operation: W A R N I N G ! High surface temperatures! - Page 16 SP30-H../EX2 | 1.02.00 www.mc-techgroup.com...
