Atlantic Ultraviolet Eco-Logic Operation Manual

Download this manual

Operation Manual for Eco-Logic Pond & Lake Restoration System

1) Overview of System Operation

2) Safety Precautions

3) Eco-Logic Unit Specifications / Equipment Installation Recommendations

4) Recommended System Maintenance

5) Aeration Tubing Installation Guidelines

6) Vane Replacement

7) Eco-Logic features

8) Dimensional Data

9) Wiring Diagram

10) Plumbing Diagram

11) Ozone Cell parts Diagram

12) Warranty Card

Eco-Logic Manual.doc

8/12/2002

Need help?

Do you have a question about the Eco-Logic and is the answer not in the manual?

Page 1 Operation Manual for Eco-Logic Pond & Lake Restoration System 1) Overview of System Operation 2) Safety Precautions 3) Eco-Logic Unit Specifications / Equipment Installation Recommendations 4) Recommended System Maintenance 5) Aeration Tubing Installation Guidelines 6) Vane Replacement 7) Eco-Logic features...
Page 2: System Overview
System Overview The Eco-Logic Pond and Lake Restoration Systems are designed to aerate a body of water with a controlled combination of air and ozone. Ozone, a natural occurring form of oxygen, sometimes known as activated oxygen, is a powerful short-lived oxidant, which is primarily used to disinfect drinking water.
Page 3 Eco-Logic Unit Specifications / Equipment Installation Recommendations: Model 4: a) CFM of Unit: 4 CFM b) Maximum PSI of Unit: 15 PSI c) Maximum Depth of Pond: 34 Feet Deep d) Maximum Surface Area Size: 1 Acre or 43,560 Square Feet e) Physical Sizes of Unit: 36 1/4”...
Page 4: Recommended System Maintenance
We recommend the filter be inspected once every 30 days for dirt build-up. The filter can be cleaned using soap and water. Replacement is necessary when cleaning the filter can no longer can be achieved or the filter material breaks down. (See Price Schedule for specific part number and cost for the In-Take Air Filter). Eco-Logic Manual.doc 8/12/2002...
